  • Page 1 Dealer Support Manual V1.2...

  • Page 2: Table Of Contents

    Adjust IR Command Length (Short vs. Long)....................16 IR Control Commands ............................17 RS-232Port IR Memory Write Command ......................19 HDMI Video Resolutions supported: ........................20 NOTES: ..................................25 ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 3: Just Add Power 2G Osd Messages

    - The HDMI source was power cycled or the HDMI cable was unplugged NOTICE: HD over IP and HD/IP are global trademarks or registered trademarks of Just Add Power Cardware Co., Inc. HDMI, the HDMI Logo, and High- Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States and other countries.

  • Page 4: Simple Type 1 Serial Communications Using Rs232 Over Ip Ports

    In the example below we see a HyperTerminal session where I used 2G RS232 Over IP to connect to my Netgear switch RS232 port and issued the SHOW VLAN command. AT THIS POINT I PRESSED CTRL-N to break the session ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 5: Type 2 Binary Serial Communications Using Rs232 Over Ip Ports

    This form of communications is intended for advanced RS232 devices that need to talk to each other in Binary mode. Using an isolated VLAN would be one method of having more specific control over which Receiver(s) can respond to the RS232 transmission. ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 6: Advanced Controls Overview

    2G boards' hostname and IP address. Use mDNS protocol tools. For example: Bonjour: http://developer.apple.com/networking/bonjour/ or http://www.science.uva.nl/research/air/wiki/mDNSResponderInstallation pyZeroConfig: http://sourceforge.net/projects/pyzeroconf/files/ ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 7: Faqs

    5) How do I change the IP Address and Netmask of the Transmitters or Receivers  Use InstallerPro software utilities – InstallerPro is purchased separately and has a one time license fee for authorized dealers. ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 8: Console Apis Description

     To kill a running process by process name:  NAME: pkill  EXAMPLE:  kill a process named "abc"  pkill -9 abc ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 9: Configurations Apis

     Example: set baudrate to 115200  $stty 115200 -F /dev/ttyS0  Reference http://linux.about.com/od/lna_guide/a/gdelna38t01.htm for more details on stty ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 10: Configuration Options List

     DEFAULT: 3 seconds  This variable can be set to whole numbers 1 or higher representing whole second increments  soip_type2_token_timeout 1 $./astparam r ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...
  • Page 11 2G HD over IP Dealer Support Manual – Page 11 ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 12: Example Console Session For Visual Learners

    // enable serial over ip port // “yes” to Type 2 ./astparam s soip_type2 y ./astparam save // save to flash reboot // reboot and load new parameters ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 13: Diagnostic Console Access Without Installerpro Uart2 Console Cables

    WARNING: If you run the diagnostic on multiple transmitters or receivers you should rename DEBUG.TXT to a name that will be easy to associate with the device being analyzed (i.e. call it Bedroom-TV-debug.txt or PS3- debug.txt. ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 14: Using Ir Manager Vbs-Hdmi-Ir104 With 2G Rs232 Ports

    4 TV's. Using 3.5mm splitters and TV’s with different IR commands you can control even more screens with one IR Manager. ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...
  • Page 15 Power LED will flash 6 times, which means this port has not learned any IR data for that command. The IR-1, IR-2, IR-3, and IR-4 LED’s can be disabled by removing the associated jumpers on the IR Manager printed circuit board. ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 16: Vbs-Hdmi-Ir104 Rs232 Command List

    (2) When the IR device key data is set to be Bytes, IR Manager can support keys of IR learning commands (Learn/ Send/ Dump…). (3) The default data length is Short Data. ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 17: Ir Control Commands

    0x00 Group 1 IR Device IR-1 0x01 Group 2 IR Device IR-2 0x02 Group 3 IR Device IR-3 0x03 Group 4 IR Device IR-4 ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...
  • Page 18 0x0E is the rserved code to break a Type 1 connection. + 2G Binary Mode (Type 2) is able to access all 32 IR Keys. ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 19: Rs-232Port Ir Memory Write Command

    APPLICATION SENDS THE COMMAND VBS-HDMI-IR104 RESPONSE [V][0x00][0x0B] [0x04] [00] [01][00][CODE] wait <0xFE> [V][0x00][0x0B] [0x04] [00] [02][00][CODE] wait <0xFE> [V][0x00][0x0B] [0x04] [00] [03][00][CODE] wait <0xFE> ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 20: Hdmi Video Resolutions Supported

    75 PosPolarity PosPolarity Progressive 1024 85 PosPolarity PosPolarity Progressive 1152 75 PosPolarity PosPolarity Progressive 1280 60 PosPolarity NegPolarity Progressive 1280 60 NegPolarity PosPolarity Progressive ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...
  • Page 21 120 PosPolarity NegPolarity Progressive 1280 120 PosPolarity NegPolarity Progressive 1280 1024 120 PosPolarity NegPolarity Progressive 1360 120 PosPolarity NegPolarity Progressive 1366 60 PosPolarity NegPolarity Progressive ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...
  • Page 22 1280 1024 60 PosPolarity NegPolarity Progressive 1280 50 NegPolarity PosPolarity Progressive 1280 60 PosPolarity NegPolarity Progressive 50 NegPolarity PosPolarity Progressive 60 NegPolarity PosPolarity Progressive ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...
  • Page 23 60 PosPolarity NegPolarity Progressive 50 NegPolarity PosPolarity Progressive 60 NegPolarity PosPolarity Progressive 75 NegPolarity PosPolarity Progressive 85 NegPolarity PosPolarity Progressive 60 PosPolarity NegPolarity Progressive ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...
  • Page 24 NegPolarity Progressive 1680 1050 60 NegPolarity NegPolarity Progressive /* GTF */ 1024 75 PosPolarity NegPolarity Progressive 1280 75 PosPolarity NegPolarity Progressive /* CEA-861-D Timing ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...

  • Page 25: Notes

    200 NegPolarity NegPolarity Interlaced 200 NegPolarity NegPolarity Interlaced 240 NegPolarity NegPolarity Progressive 240 NegPolarity NegPolarity Progressive 240 NegPolarity NegPolarity Interlaced 240 NegPolarity NegPolarity Interlaced NOTES: ©2011 Just Add Power Cardware Co, Inc. All rights reserved. Unauthorized use or disclosure prohibited. V1.2...
