FEATURES

KNOW YOUR COMPOUND MITER SAW

See Figure 1.
The safe use of this product requires an understanding of
MITER LOCK
LOCK
UNLOCK
the information on the tool and in this operator's manual as
LEVERS
well as a knowledge of the project you are attempting. Before
use of this product, familiarize yourself with all operating
features and safety rules.

12 AMP MOTOR

Your saw has a powerful 12 amp motor with sufficient
power to handle tough cutting jobs. It is made with all ball
bearings, and has externally accessible brushes for ease
of servicing.
10 in. BLADE
A 10 in. saw blade is included with your compound miter saw.
It will cut materials up to 2 in. thick or 6 in. wide, depending
upon the angle at which the cut is being made.
MITER LOCK LEVERS
See Figure 2.
The miter lock levers securely lock the saw table at the
desired miter angles.
Fig. 2
SPINDLE LOCK BUTTON
SWITCH
TRIGGER
See Figure 3.
A spindle lock button has been provided for locking the
spindle which keeps the blade in your saw from rotating.
Depress and hold the lock button while installing, changing,
SPINDLE
or removing blade. LOCK BUTTON
SWITCH TRIGGER
See Figure 4.
To prevent unauthorized use of your compound miter saw,
we suggest that you disconnect it from the power supply and
lock the switch in the off position. To lock the switch, install a
padlock (not included) through the hole in the switch trigger.
A lock with a long shackle up to 9/32 in. diameter may be
used. When the lock is installed and locked, the switch is
inoperable. Store the padlock key in another location.
Fig. 3
SWITCH
TRIGGER
PADLOCK
Fig. 4
11
