Aiwa CS-130 Service Manual
Stereo radio
cassette recorder
Hide thumbs
Also See for CS-130:
- Service manual (9 pages) ,
- Service manual (15 pages) ,
- Service manual (15 pages)
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Aiwa CS-130
Summary of Contents for Aiwa CS-130
- Page 1 CS-130 HRJ EZ SERVICE MANUAL STEREO RADIO BASIC TAPE MECHANISM : TN-21ZVC-1727 CASSETTE RECORDER This Service Manual is the "Revision Publishing" and replaces "Simple Manual" (S/M Code No. 09-993-327-20A). S/M Code No. 09-994-327-2R1...
-
Page 2: Specifications
SPECIFICATIONS HRJ MODEL EZ MODEL • Design and specifications are subject to change without notice • Design and specifications are subject to change without notice ACCESSORIES/PACKAGE LIST REF. NO PART NO. KANRI DESCRIPTION 1 87-A80-081-010 AC CORD SET ASSY,EZ BLK 2 8Z-CS4-908-010 IB,EZ(9L)B<EZ>... -
Page 3: Electrical Main Parts List
ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C405 87-010-401-080 CAP, ELECT 1-50V C406 87-010-401-080 CAP, ELECT 1-50V 87-A20-851-040 C-IC,TA2111F C407 87-010-260-080 CAP, ELECT 47-25V 87-A20-569-010 IC,BA3308 C408 87-010-112-080 CAP, ELECT 100-16V 87-017-916-010 IC,BU4066BC C409... -
Page 4: Chip Resistor Part Code
• Regarding connectors, they are not stocked as they are not the initial order items. The connectors are available after they are supplied from connector manufacturers upon the order is received. CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor... -
Page 5: Transistor Illustration
TRANSISTOR ILLUSTRATION IC BLOCK DIAGRAM IC, TA2111N FM RF AM RF IN RF VCC FM OSC AM OSC DET OUT MPX IN LPF2 LPF1 L-OUT R-OUT DECODE BUFF DIVIDE MUTE E C B ST/MO E B C FM/AM LEVEL 2SC1815 SS8050 2SC1740 FM RF IN... - Page 6 WIRING FM ANT MIC1 MAIN BOARD (PARTS SIE) SW401 VR501 SW602 SW202 SW101 Q SOUND FUNCTION FM MODE/OSC BAND LED605 HR:MW PHONES OPE/BATT POWER RADIO FM MONO FM STEREO CNP302 EZ:LW STANDBY TAPE (-6) (-2) (-1) (LCH) HR MODEL (-5) (-3) (-4) (LCH)
-
Page 7: Schematic Diagram
SCHEMATIC DIAGRAM MAIN C.B PVC1 L101 VC1-4 BAR-ANT TC1-4 C138 L107,TC2 0.01 FM SENS. ADJ. L101,TC4 L104,TC102 HR : MW SENS. ADJ. HR : MW FREQ. ADJ. L108,TC1 FM FREQ. ADJ. EZ : LW SENS. ADJ. EZ : LW FREQ. ADJ. EZ MODEL MODEL EZ MODEL... -
Page 8: Voltage Chart
VOLTAGE CHART... -
Page 9: Electrical Adjustment
ELECTRICAL ADJUSTMENT PRACTICAL SERVICE FIGURE < TAPE RECORDER SECTION > < RADIO SECTION > MAIN C.B (ALL MODEL) Sensitivity: (IHF, THD 3%) FM Less than 25dB 8. Tape speed Adjustment (S/N 20dB) MW Less than 60dB Condition: • Test tape: TTA-100 (S/N 20dB) LW Less than 66dB (200kHz) •... -
Page 10: Mechanical Exploded View
MECHANICAL EXPLODED VIEW 1/1 HRJ MODEL EZ MODEL TN-21ZVC-1727 P.C.B... -
Page 11: Mechanical Parts List
CABI,REAR B EZ<131E> 4 8Z-CS4-007-010 CABI,FR B EX<131E> 27 8Z-CS4-013-010 CABI,REAR EZ<130EZ> 4 8Z-CS4-006-010 CABI,FR EX<HRJ,130EZ> 27 8Z-CS4-015-010 CABI,REAR HR<HRJ> 5 84-CD8-083-010 AIWA BADGE 28 8Z-CS3-012-010 BTN,QSOUND 6 8Z-CS3-206-010 SPR,CASS 29 8Z-CS3-013-010 KNOB,RTRY VOL 7 8Z-CS4-001-010 WINDOW,DIR<HRJ,130EZ> 30 8Z-CS3-011-010 KNOB,SL 7 8Z-CS4-040-010 WINDOW,DIR B<131E>... -
Page 12: Tape Mechanism Exploded View
TAPE MECHANISM EXPLODED VIEW 1/1 LUG PLATE... -
Page 13: Tape Mechanism Parts List
TAPE MECHANISM PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 S1-921-030-4A0 HEAD BASE 36 S1-921-140-030 REC BUTTON LEVER 2 S1-821-030-070 AZIMUTH SPRING 37 S1-921-140-170 P.S.LEVER SPRING 3 S1-921-030-090 PANEL P SPRING 38 S1-921-073-040 RF CLUTCH ASSY 4 S1-921-260-050 GEAR PLATE SPRING... - Page 14 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 Printed in Singapore 737004...
