- Page 1 All manuals and user guides at all-guides.com CS-131 SERVICE MANUAL STEREO RADIO BASIC TAPE MECHANISM : TN-21ZVC-1727 CASSETTE RECORDER S/M Code No. 09-994-327-2N1...
-
Page 2: Specifications
All manuals and user guides at all-guides.com SPECIFICATIONS • Design and specifications are subject to change without notice ACCESSORIES/PACKAGE LIST REF. NO PART NO. KANRI DESCRIPTION 1 87-A80-081-010 AC CORD SET ASSY,EZ BLK 2 8Z-CS4-910-010 IB,V(ER)B... -
Page 3: Electrical Main Parts List
All manuals and user guides at all-guides.com ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C404 87-010-545-080 CAP, ELECT 0.22-50V C405 87-010-401-080 CAP, ELECT 1-50V 87-A20-851-040 C-IC,TA2111F C406 87-010-401-080 CAP, ELECT 1-50V 87-A20-569-010 IC,BA3308 C407... -
Page 4: Chip Resistor Part Code
All manuals and user guides at all-guides.com • Regarding connectors, they are not stocked as they are not the initial order items. The connectors are available after they are supplied from connector manufacturers upon the order is received. CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code... -
Page 5: Transistor Illustration
All manuals and user guides at all-guides.com TRANSISTOR ILLUSTRATION IC BLOCK DIAGRAM IC, TA2111N FM RF MPX IN AM RF IN RF VCC FM OSC AM OSC DET OUT LPF2 LPF1 L-OUT R-OUT DECODE BUFF DIVIDE MUTE E C B ST/MO E B C FM/AM... - Page 6 All manuals and user guides at all-guides.com WIRING FM ANT MIC1 MAIN BOARD (PARTS SIDE) SW401 VR501 SW602 SW202 SW101 BAND Q SOUND FUNCTION FM MODE/OSC LED605 PHONES OPE/BATT POWER RADIO FM MONO FM STEREO CNP302 STANDBY TAPE (-6) (-2) (-1) (LCH) (-5)
-
Page 7: Schematic Diagram
All manuals and user guides at all-guides.com SCHEMATIC DIAGRAM MAIN C.B L106,TC1 FM 2 SENS. ADJ. PVC101 TC1-4 VC1-4 TUNING 47/25 L102,TC3 AF AMP MW FREQ. ADJ. SW101 Q SOUND L103,TC105 BAND FM 1 FREQ. ADJ. L105,TC107 FM 1 SENS. ADJ. L101,TC4 AM SENS. -
Page 8: Voltage Chart
All manuals and user guides at all-guides.com VOLTAGE CHART... -
Page 9: Electrical Adjustment
All manuals and user guides at all-guides.com ELECTRICAL ADJUSTMENT PRACTICAL SERVICE FIGURE < TAPE RECORDER SECTION > < RADIO SECTION > MAIN C.B 8. Tape speed Adjustment Sensitivity: Condition: • Test tape: TTA-100 (IHF, THD 3%) FM1 Less than 25dB •... -
Page 10: Mechanical Exploded View
All manuals and user guides at all-guides.com MECHANICAL EXPLODED VIEW 1/1 TN-21ZVC-1727 P.C.B... -
Page 11: Mechanical Parts List
CABI,REAR B V 3 8Z-CS4-031-010 BOX,CASS B 28 8Z-CS3-012-010 BTN,QSOUND 4 8Z-CS4-007-010 CABI,FR B EX 29 8Z-CS3-013-010 KNOB,RTRY VOL 5 84-CD8-083-010 BADGE,AIWA 30 8Z-CS3-011-010 KNOB,SL 6 8Z-CS3-206-010 SPR,CASS 31 8Z-CS3-627-010 ANT,ROD ZCS-3/4 7 8Z-CS4-040-010 WINDOW,DIR B 32 8Z-CS3-207-010 SPR,BATT -... -
Page 12: Tape Mechanism Exploded View
All manuals and user guides at all-guides.com TAPE MECHANISM EXPLODED VIEW 1/1 LUG PLATE... -
Page 13: Tape Mechanism Parts List
All manuals and user guides at all-guides.com TAPE MECHANISM PARTS LIST 1/1 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 1 S1-921-030-4A0 HEAD BASE 36 S1-921-140-030 REC BUTTON LEVER 2 S1-821-030-070 AZIMUTH SPRING 37 S1-921-140-170 P.S.LEVER SPRING 3 S1-921-030-090 PANEL P SPRING 38 S1-921-073-040... - Page 14 All manuals and user guides at all-guides.com 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 Printed in Singapore 737004...
