Use and Care Manual
ELECTRIC DRYER INSTALLATION INSTRUCTIONS
27" WIDE MODELS - U.S.A. ONLY
Para obtener acceso al manual de uso y cuidado en español, o para obtener información adicional acerca de su producto, visite:
Tenga listo su número de modelo completo. Puede encontrar el número de modelo y de serie dentro de la cavidad superior de la puerta.
W10755020A
W10755021A-SP
www.whirlpool.com
Table of Contents
DRYER SAFETY......................................................................... 2
INSTALLATION REQUIREMENTS ........................................... 3
Tools and Parts ...................................................................... 3
Location Requirements ......................................................... 4
ELECTRICAL REQUIREMENTS ............................................... 5
INSTALL LEVELING LEGS ....................................................... 6
ELECTRICAL CONNECTION ................................................... 6
VENTING .................................................................................. 12
Venting Requirements ......................................................... 12
Plan Vent System ................................................................. 13
Venting Kits .......................................................................... 14
Install Vent System .............................................................. 14
Connect Vent ........................................................................ 15
LEVEL DRYER ......................................................................... 15
COMPLETE INSTALLATION CHECKLIST ............................ 16
REVERSE DOOR SWING (OPTIONAL) .................................. 16
TROUBLESHOOTING .........................................BACK COVER
INSTALLATION NOTES
_________________________________
Date of purchase:
_______________________________
Date of installation:
________________________________________
Installer:
___________________________________
Model number:
___________________________________
Serial number:
1
Advertisement
Table of Contents
Related Manuals for Maytag MEDP475EW
Summary of Contents for Maytag MEDP475EW
-
Page 1: Table Of Contents
ELECTRIC DRYER INSTALLATION INSTRUCTIONS 27" WIDE MODELS - U.S.A. ONLY Para obtener acceso al manual de uso y cuidado en español, o para obtener información adicional acerca de su producto, visite: www.whirlpool.com Tenga listo su número de modelo completo. Puede encontrar el número de modelo y de serie dentro de la cavidad superior de la puerta. Table of Contents DRYER SAFETY................. -
Page 2: Dryer Safety
DRYER SAFETY... -
Page 3: Installation Requirements
INSTALLATION REQUIREMENTS Tools and Parts Gather the required tools and parts before starting installation. Read and follow the instructions provided with any tools listed here. Adjustable wrench that Utility knife Tools needed: opens to 1" (25 mm) or hex-head socket wrench Flat-blade screwdriver #2 Phillips screwdriver Tape measure... -
Page 4: Location Requirements
Dryer Dimensions Parts needed: Check local codes. Check existing electrical supply and venting, 27" and read “Electrical Requirements” and “Venting Requirements” (686 mm) before purchasing parts. Mobile home installations require metal exhaust system hardware, available for purchase from the dealer from whom you purchased your dryer. -
Page 5: Electrical Requirements
Mobile home - Additional installation requirements A UL listed strain relief. ■ This dryer is suitable for mobile home installations. The If your outlet looks like this: installation must conform to the Manufactured Home Then choose a 4-wire power supply cord Construction and Safety Standard, Title 24 CFR, Part 3280 with ring or spade terminals and UL listed (formerly the Federal Standard for Mobile Home Construction... -
Page 6: Install Leveling Legs
INSTALL LEVELING LEGS ELECTRICAL CONNECTION Power Supply Cord Prepare dryer for leveling legs To avoid damaging floor, use a large flat piece of cardboard from dryer carton; place under entire back edge of dryer. Electrical Connection Options Firmly grasp dryer body (not console panel) and gently lay dryer down on cardboard. -
Page 7: Power Supply Cord Connection
Power Supply Cord Connection Direct Wire Power supply cord strain relief Attach power supply cord strain relief Remove the screws from a 3/4" (19 mm) UL listed strain relief (UL marking on strain relief). Put the tabs of the two clamp sections (C) into the hole below the terminal block opening (B) so that one tab is pointing up (A) and the other is pointing down (D), and hold in place. - Page 8 4-wire Power Supply Cord Connection Connect ground wire IMPORTANT: A 4-wire connection is required for mobile homes and where local codes do not permit the use of 3-wire connections. 4-wire receptacle (NEMA 4-prong plug type 14-30R) Connect ground wire (F) (green or bare) of power supply cord to external ground conductor screw (A).
-
Page 9: Direct Wire Connection
Direct Wire Connection Remove center screw Direct wire strain relief Attach direct wire strain relief Remove center terminal block screw (B). Connect neutral wire Unscrew the removable conduit connector (A) and any screws from a 3/4" (19 mm) UL listed strain relief (UL marking on strain relief). -
Page 10: 3-Wire Direct Wire Connection
4-wire Direct Wire Connection Connect ground wire IMPORTANT: A 4-wire connection is required for mobile homes and where local codes do not permit 3-wire connections. Prepare your 4-wire cable for direct connection Connect ground wire (green or bare) (F) of direct wire cable to external ground conductor screw (A). - Page 11 Optional 3-wire Connection Remove center screw IMPORTANT: You must verify with a qualified electrician that this grounding method is acceptable before connecting. Prepare to connect neutral ground wire and neutral wire Remove center terminal block screw (B). Connect neutral wire Remove center terminal block screw (B).
-
Page 12: Venting
Rigid metal vent: Connect external ground wire Recommended for best drying performance and to avoid ■ crushing and kinking. Flexible metal vent: (Acceptable only if accessible to clean) Must be fully extended and supported in final dryer location. ■ Remove excess to avoid sagging and kinking that may result ■... -
Page 13: Plan Vent System
Clamps: Optional exhaust installations: Use clamps to seal all joints. ■ Exhaust can be converted out the right side, left side, or through Exhaust vent must not be connected or secured with screws the bottom (4-way vent kit). Each kit includes step-by-step ■... -
Page 14: Venting Kits
Determine vent length and elbows needed for best Venting Kits drying performance: Use following Vent System Chart to determine type of vent For more information, call 1-800-901-2042, or visit us at ■ material and hood combinations acceptable to use. www.applianceaccessories.com. In Canada, call 1-800-807-6777 or visit us at www.whirlpoolparts.ca. -
Page 15: Connect Vent
LEVEL DRYER Connect vent to exhaust hood Level Dryer Vent must fit over the exhaust hood. Secure vent to exhaust hood with 4" (102 mm) clamp. Run vent to dryer location using straightest path possible. Avoid 90° turns. Use clamps to seal all joints. -
Page 16: Complete Installation Checklist
COMPLETE INSTALLATION 27" Wide Model Side-Swing Door CHECKLIST Place towel on dryer Check that all parts are now installed. If there is an extra part, go back through steps to see what was skipped. Check that you have all of your tools. Dispose of/recycle all packaging materials. - Page 17 Remove screws from hinges Flip door over Flip door over so handle side is down. Attach door hinges Remove screws attaching hinges to door. Remove screws from door Remove screws at top, bottom, and side of door (6 screws). Keep door screws separate from hinge screws as they are different sizes.
- Page 18 Insert screws in hinge holes on Remove bottom screws dryer cabinet Open dryer door. Remove bottom screws from dryer cabinet side of hinges. Loosen (do not remove) top screws from dryer cabinet side of hinges. NOTE: 2 people may be needed to reinstall door. Insert screws into the bottom holes on left side of dryer cabinet.
- Page 19 Rotate outer door Flip door over Flip door over so handle side is down. Rotate outer door 180º and set it back down on inner door. Be certain to keep cardboard spacer centered between Remove screws from door doors. Reattach outer door panel to inner door panel so handle is on the side where hinges were just removed.
-
Page 20: Troubleshooting
Remove door strike and door Insert screws in hinge holes on strike label dryer cabinet Door strike Door strike label NOTE: 2 people may be needed to reinstall door. Remove door strike and door strike label from dryer cabinet. Insert the door strike into hole where door strike label was Insert screws into the bottom holes on left side of dryer removed and secure with screw.
