- Page 1 3-D Step-counter with wireless data transfer User Manual Please read this user manual thoroughly before first using this device HMM Diagnostics GmbH D-69221 Dossenheim, Germany www.hmm.info...
-
Page 2: Table Of Contents
Content I. Introduction II. Your smartLAB walk P+ ® Display & functions Specifications III. Setup & Functions Inserting the battery Mounting the carrying cord Before first use Setting weight, step length, signal tone und time Manually transfer Not Sent data... -
Page 3: Introduction
I. Introduction Thank you for using the smartLAB ® walk P+ 3-D step counter. Because of its small and handy form and its appealing design, this device suits best your needs for the control of walked distances. Because of the integrated 3-D sensor technology, this device counts normal steps as well as lunges or backward steps. -
Page 4: Your Smartlab Walk P
II. Your smartLAB walk P+ ® Display & functions Select Settings, Change Settings Key Lock Symbol Mute Symbol On/Off, Select Clock Menu, Display Steps Pic. 1 Walked steps Symbol wireless data transfer Specifications 7. Unit for distance: km 1. Name: smartLAB ®... -
Page 5: Setup & Functions
III. Setup & Functions Inserting the battery In order to change/ insert the battery, you need to unscrew the battery lid on the back of the device. Place the coin cell with the plus side to top into the opening. If you change the battery, use the screwdriver to lever off the battery. -
Page 6: Mounting The Carrying Cord
Mounting the carrying cord You can wear your smartLAB walk P+ with the carrying cord included in the set. To ® do so, you will have to connect the cord to the device by doing the following steps: Push the thin end of the cord through the two tiny eyes at the back side of the device. -
Page 7: Before First Use
Before first use: Before first using your smartLAB walk P+ step counter, please hold the „Disp/Set“ ® button pressed for more than 3 seconds. The device will go on and enters the setting mode. The smartLAB ® walk P+ step counter has an automatic setup function (Heart Beat). - Page 8 With the “M/” button you can adjust your weight. You can only increase the value. After reaching the maximum level of 200 kg, smartLAB walk P+ will start ® with 30 kg again. By keeping the “M/” button pushed, the weight value increases faster. After having set your personal weight, press „Disp/ Set“...
- Page 9 Note: Setting your weight and step length is essential for the display of walked distances and burned calories. You need to enter correct values for both parameters. Otherwise it is impossible for smartLAB walk P+ to correctly display your walked ®...
- Page 10 Otherwise, measured data can not be assigned accordingly. ANT settings: ANT is a wireless data transfer standard. In order to use it, transmitting- and receiving device must be equipped with a specific module. Your smartLAB ® walk P+ step counter has an integrated ANT module, making it possible to transfer measured data to a PC, laptop or a mobile phone (e.g.
- Page 11 1. Per 10 minutes mode (recommended) 2. Heart Beat mode Setting the Per 10 minutes ANT mode: In this mode data will be sent out every 10 minutes to the accordant receiving device. All data which was stored during the last time interval will be sent out then. You can see the automatic mode in picture 5.
- Page 12 Setting the Heart Beat mode: If this mode is (ON), which is the factory setting, the step counter will try to communicate every minute with receivng device. Is there any receiving device in reach which supports this function, the step counter will be set automatically. After the step counter was set, the heart beat function will start again every 30 minutes.
-
Page 13: Manually Transfer Not Sent Data
Manually transfer Not Sent data You can also manually trigger data transfer to the receiving device. To do so, you first have to turn on SEND mode on your smartLAB ® walk P+ device. Please quickly press and release the “Disp/ Set” button, and then press it again for 6 seconds. -
Page 14: Manually Transfer All Data
Manually transfer all data You can also manually trigger all data transfer to the receiving device. To do so, you first have to turn on Send mode on your smartLAB walk P+ device. ® Please quickly press and release the “Disp/ Set” button, and then press it again for 6 seconds. - Page 15 pict. 09 pict. 10 pict. 11...
-
Page 16: Starting Up
Starting up After having set time and step length, you can use your smartLAB • walk P+ ® step counter. Just take the device and start walking. The device will turn on automatically when it registeres a movement. The display will read “HELLO”... -
Page 17: Additional Functions
Note: Once you have walked 99999 steps, the device stops counting your steps. The LCD display will start twinkling and reset after the time setting was set back to 0:00. Additional functions Battery-display: appears in the display, your smartLAB When the low battery symbol walk P+ ®... -
Page 18: Maintenance
Locking your device: If no button is pushed for 30 seconds, your smartLAB ® walk P+ automatically activates key lock. This is shown by the according display symbol. By pushing the „Disp/ Set“ button, you can unlock the device. Display-power-off: When you are in user mode, your device automatically turns off after 1 minutes of non-use. - Page 19 Regularity and Safety Notice Declaration of Conformity This product is compliant with the EC Directives: -1999/5/EC Safety Statement This product has been verified to conform to the safety certification in accordance with the specification of EN Standards: EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 WEEE note The WEEE (Waste Electrical and Electronic Equipment) Directive, that came into effect as...
- Page 20 The WEEE logo on the product and the packaging indicates that it is not allowed to dispose of the product in the ordinary household waste. It is your responsibility to deliver all the disused electri- cal and electronic equipment to the respective collection points. A separate collection and proper recycling of electronic waste helps dealing economically with natural resources.
-
Page 21: Warranty
Warranty HMM Diagnostics GmbH products need to fulfill high quality requirements. Because of this reason, HMM Diagnostics GmbH gives a 2-year warranty by purchasing this smartLAB product. You can even extend the warranty from 3 to 5 years without ®... - Page 22 Hersteller/Manufacturer: HMM Diagnostics GmbH Friedrichstr. 89 D-69221 Dossenheim, Germany E-mail: info@hmm.info www.hmm.info Weitere Informationen zu den smartLAB Produkten / ® More information on our smartLAB products: ® www.smartlab.org...
