Sony XM-2002GTW Service Manual page 18

XM-2002GTW
AMPLIFIER
Ref. No. Part No. Description
C915 1-137-194-81 FILM
C916 1-137-372-11 MYLAR
C917 1-131-731-12 ELECT
C918 1-131-731-12 ELECT
C919 1-131-731-12 ELECT
C920 1-131-731-12 ELECT
C921 1-112-811-11 ELECT
C924 1-112-811-11 ELECT
C927 1-115-339-11 CERAMIC CHIP
C928 1-115-339-11 CERAMIC CHIP
C932 1-104-666-11 ELECT
C933 1-104-666-11 ELECT
C934 1-130-495-00 MYLAR
C935 1-130-495-00 MYLAR
C936 1-104-666-11 ELECT
C937 1-104-666-11 ELECT
C938 1-128-576-11 ELECT
C939 1-128-576-11 ELECT
C940 1-115-339-11 CERAMIC CHIP
C941 1-115-339-11 CERAMIC CHIP
C942 1-162-968-11 CERAMIC CHIP
C943 1-162-968-11 CERAMIC CHIP
C950 1-115-339-11 CERAMIC CHIP
< TERMINAL BOARD >
CN801 1-780-337-11 TERMINAL BOARD (3P+FUSE)
CN804 1-694-985-21 TERMINAL BOARD (4P) (SPEAKER OUT)
< CONNECTOR >
* CN803 1-691-785-11 PIN, CONNECTOR (PC BOARD) 4P
CN810 1-506-468-11 PIN, CONNECTOR 3P
< JACK >
CNJ801 1-770-068-21 JACK, PIN 2P (INPUT)
CNJ802 1-770-068-21 JACK, PIN 2P (OUTPUT)
< DIODE >
D104 8-719-083-60 DIODE UDZSTE-174.7B
D106 8-719-082-03 DIODE MM3Z15VT1
D107 8-719-082-03 DIODE MM3Z15VT1
D108 8-719-988-61 DIODE 1SS355TE-17
D109 8-719-988-61 DIODE 1SS355TE-17
D204 8-719-083-60 DIODE UDZSTE-174.7B
D206 8-719-082-03 DIODE MM3Z15VT1
D207 8-719-082-03 DIODE MM3Z15VT1
D208 8-719-988-61 DIODE 1SS355TE-17
D209 8-719-988-61 DIODE 1SS355TE-17
D701 8-719-978-33 DIODE DTZ-TT11-6.8B
D702 8-719-988-61 DIODE 1SS355TE-17
D703 8-719-988-61 DIODE 1SS355TE-17
D801 8-719-988-61 DIODE 1SS355TE-17
D802 8-719-988-61 DIODE 1SS355TE-17
D803 8-719-988-61 DIODE 1SS355TE-17
D820 8-719-988-61 DIODE 1SS355TE-17
D822 8-719-988-61 DIODE 1SS355TE-17
D827 8-719-988-61 DIODE 1SS355TE-17
18
Remark Ref. No.
0.47uF 5% 50V
0.022uF 5% 50V
2200uF 20% 16V
2200uF 20% 16V
2200uF 20% 16V
2200uF 20% 16V
8200uF 50V
8200uF 50V
0.1uF 10% 50V
0.1uF 10% 50V
220uF 20% 25V
220uF 20% 25V
0.1uF 5% 50V
0.1uF 5% 50V
220uF 20% 25V
220uF 20% 25V
100uF 20% 63V
100uF 20% 63V
0.1uF 10% 50V
0.1uF 10% 50V
0.0047uF 10% 50V 0 F901
0 F902
0.0047uF 10% 50V
0.1uF 10% 50V
(REM,+12V,GND,40A,40A)
(HIGH LEVEL INPUT)
Part No. Description
D832 8-719-988-61 DIODE 1SS355TE-17
D901 8-719-978-33 DIODE DTZ-TT11-6.8B
D902 8-719-065-46 DIODE 02DZ16-Z(TPH3)
D905 8-719-079-00 DIODE FCH10A15
D906 8-719-079-01 DIODE FRH10A15
D909 8-719-054-55 DIODE 1SS306-TE85L
D910 8-719-054-55 DIODE 1SS306-TE85L
D911 8-719-079-92 DIODE 1SR159-200TE25
D912 8-719-079-92 DIODE 1SR159-200TE25
D913 8-719-065-46 DIODE 02DZ16-Z(TPH3)
D914 8-719-065-46 DIODE 02DZ16-Z(TPH3)
D915 8-719-065-42 DIODE 02DZ15-Y(TPH3)
D917 8-719-079-92 DIODE 1SR159-200TE25
D918 8-719-079-92 DIODE 1SR159-200TE25
D919 8-719-988-61 DIODE 1SS355TE-17
D920 8-719-988-61 DIODE 1SS355TE-17
D921 8-719-988-61 DIODE 1SS355TE-17
D922 8-719-988-61 DIODE 1SS355TE-17
< FUSE >
1-533-743-11 FUSE (BLADE TYPE) (AUTO FUSE) (40A)
1-533-743-11 FUSE (BLADE TYPE) (AUTO FUSE) (40A)
< IC >
IC101 8-759-710-97 IC NJM4565M-D
IC102 8-759-710-97 IC NJM4565M-D
IC202 8-759-710-97 IC NJM4565M-D
IC301 8-759-909-71 IC BA4558F
IC302 8-759-909-71 IC BA4558F
IC901 6-703-643-01 IC TL594INSR
IC902 6-600-354-01 IC PC-17K1
IC903 6-600-354-01 IC PC-17K1
< JUMPER RESISTOR >
JR101 1-216-296-11 SHORT CHIP
JR102 1-216-296-11 SHORT CHIP
< COIL >
L901 1-456-139-12 COIL, CHOKE
L902 1-410-396-71 INDUCTOR, FERRITE BEAD 0.45uH
L903 1-456-139-12 COIL, CHOKE
L904 1-410-396-71 INDUCTOR, FERRITE BEAD 0.45uH
L905 1-410-396-71 INDUCTOR, FERRITE BEAD 0.45uH
L906 1-410-396-71 INDUCTOR, FERRITE BEAD 0.45uH
L907 1-410-396-71 INDUCTOR, FERRITE BEAD 0.45uH
L908 1-410-396-71 INDUCTOR, FERRITE BEAD 0.45uH
< THERMISTOR (POSITIVE) >
PTH801 1-805-163-21 THERMISTOR, POSITIVE
< TRANSISTOR >
Q101 8-729-034-51 TRANSISTOR KTC3875
Q102 6-550-686-01 TRANSISTOR KTC2875-B-RTK
Q103 6-550-031-01 TRANSISTOR HN4C06J-GRBL(TE85R)
Q104 6-550-032-01 TRANSISTOR HN4A06J-GRBL(TE85R)
Q105 6-550-691-01 TRANSISTOR KTA1045L-Y
Q106 6-550-692-01 TRANSISTOR KTC2025L-Y
Remark
0
0
35uH
35uH
