LST SIM016-3 Specification Sheet

Serial Interface Module
SIM016-3
• Extends the fi re detection control
panel Series BC016 by an INFO bus
interface
• Adjustable baud rate
• Monitoring of the data line
• Connection of fi re brigade control
units, remote tableaus, etc.
Description
The Serial Interface Module SIM016-3 provides fi re de-
tection control panels Series BC016 with an INFO bus
interface. Fire brigade control units or remote tableaus,
for example, can be connected to this interface. The
Specifi cations
Current consumption at 24V
Interface
Connection type
Ambient temperature
Dimensions L × W × H
Weight
Part No.
Order name
Building Safety. Building Security.
© LABOR STRAUSS SICHERUNGSANLAGENBAU GMBH • A-1231 WIEN • WIEGELESTRASSE 36 • TEL +43 1 52114-0 • FAX +43 1 52114-27
OFFICE@LST.AT • WWW.LST.AT • ALL RIGHTS RESERVED
transfer rate can also be adjusted, if required. The
SIM016-3 module occupies the slot for serial interfaces
in fi re detection control panels Series BC016.
typ. 22mA
20mA current loop
Screw terminals
-5°C to +50°C
70 × 45 × 20 (mm)
50g
210112
Serial Interface Module SIM016-3
A
SIM016-3_DBL_LST_EN_0804.PDF • PAGE 1
