- Page 1 PCT2785 Touch LED LCD Monitor USER'S GUIDE www.planar.com...
-
Page 2: Table Of Contents
Rear View of the Product ..............................7 Quick Installation ................................8 Webcam Installation...............................9 Basic Operation and Calibration/Reset Instructions..................10 Advanced Operation—OSD Menu......................... 12 Supporting Timing Modes ............................15 Technical Information ..............................16 Wall-Mount Installation Instructions........................17 Troubleshooting................................18 Planar Support ................................19... -
Page 3: Operation Instructions
According to WEEE regulation, this Touch LED LCD Monitor can't be handled as normal trash in Europe when it is out of usage. Please refer to the recycle information on Planar’s website to handle it. For more information on how to recycle your product, please visit http://www.planar.com/about/green/... - Page 4 COMMUNIQUE D’AVERTISSEMENT DE LA FCC CONCERNANT LES INTERFERENCE DE FREQUENCE RADIO: (SEULEMENT POUR MODELES CERTIFIE PAR LA FCC) Ce moniteur a été testé et à été trouvé conforme aux limites pour un appareil numérique de Classe B, suivant la partie 15 des règlements de la FCC. Ces limites ont été développées pour offrir une protection satisfaisante contre les interférences nuisibles dans une installation résidentielle.
-
Page 5: Unpacking Instructions
Unpacking Instructions Remove the Touch LED LCD Monitor out of the package and take off the plastic bag and Polystyrene Foam. Pull the base from Parallel versus Panel to Vertical. Adjust the Panel between 15° leaning forward and 70° leaning backward. Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. -
Page 6: Consignes De Sécurité
Consignes de sécurité Respectez tous les avertissements, les précautions et conseils d’entretien recommandés dans ce manuel de l’utilisateur pour maximiser la durée de vie de votre appareil. A faire : Éteindre le produit avant de le nettoyer. La surface de l'écran tactile peut être nettoyée avec un chiffon doux et propre imprégné d’un nettoyant doux du commerce pour vitres ou d'un mélange à... -
Page 7: Package Overview
Package Overview Touch LED LCD Monitor Power Cord VGA Signal Cable Audio-in Cable USB Cable (A to B) HDMI Cable Touch Pen Cable Wrap User’s Guide Cleaning Cloth... -
Page 8: Front View Of The Product
Front View of the Product ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ① Webcam LED indicator ② Webcam ③ Microphone ④ OSD Turn On/ Off ⑤ Scroll Down/ Adjust Decrease/ Audio Adjust/ Auto * ⑥ Scroll UP/ Adjust Increase/ Picture Mode * ⑦... -
Page 9: Rear View Of The Product
Rear View of the Product ① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨ ① Power Input ② Up-stream USB 3.0 port (to PC) ③ USB port-A (support USB 3.0 plug play device) ④ USB port-B (support USB 3.0 plug play device) ⑤... -
Page 10: Quick Installation
Quick Installation Connect either VGA, HDMI or DisplayPort Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. Please note. The monitor ships with only VGA and HDMI cables. DisplayPort cable may be sourced separately from a cable supplier. -
Page 11: Webcam Installation
Webcam Installation Download the free “Instant messaging software” such as Yahoo Messenger, or Skype from the Internet. Complete the installation. Use the USB 3.0 cable (included with the monitor) to connect the monitor to one of the USB 3.0 ports of the computer. Windows will automatically search for the camera, and proceed with the installation of the driver. -
Page 12: Basic Operation And Calibration/Reset Instructions
Basic Operation and Calibration/Reset Instructions Before using the Touch LED LCD Monitor: Connect external equipment properly. Insert the power plug, and the power LED indicator will light orange. Power On/Off To turn the Touch LED LCD Monitor on/off: Press button on the front. The power LED indicator light will be blue when the Touch LED LCD Monitor is on. - Page 13 Repeat this step to unlock. PCT2785 Calibration/Reset Instructions: The PCT2785 is available with USB connection. It is Microsoft® Windows® 7, 8 HID (Human Interface Device) compatible if you use the USB touch screen interface. No additional software driver is required. Calibration is a simple process and can be invoked by running Tablet PC Settings from Control Panel and clicking the Calibrate button.
-
Page 14: Advanced Operation-Osd Menu
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your Touch LED LCD Monitor. Press the 1 button to display the OSD Menu, and use ▲ or ▼ to select the desired OSD menu. Short Cuts Function from the button(s) AUTO IMAGE ADJUST: To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H. - Page 15 INPUT SELECT: When Input Select is pressed, change Input signal to VGA, HDMI, DISPLAYPORT or AUTO. AUDIO ADJUST: To adjust the audio functions. VOLUME: To adjust the volume of speaker output. MUTE: To turn the Mute ON/OFF. AUDIO INPUT: When in HDMI input, select where the audio source comes from AUDIO IN or HDMI.
- Page 16 VIDEO MODE ADJUSTMENT: To select the video mode from Full Screen or ASPECT RATIO. SETUP MENU: To set up LANGUAGE SELECT, OSD POSITION, OSD TIME OUT, OSD BACKGROUND and LED mode. LANGUAGE SELECT: To allow users to choose from available languages. Press ▲...
-
Page 17: Supporting Timing Modes
Supporting Timing Modes STANDARD RESOLUTION 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA... -
Page 18: Technical Information
Technical Information Panel 27” TFT (with LED backlight) Power Management On: 45 Watts (typical), 60 Watts (maximum) Standby Mode: < 2.4 Watt (USB 3.0) Off: < 2.4 Watt (USB 3.0) Displayable Resolution Full HD 1920 x 1080 max. Vertical Frequency 60Hz max. Pixel Dimension 0.31125 x 0.31125 mm Display Color... -
Page 19: Wall-Mount Installation Instructions
Wall-Mount Installation Instructions Wall Mount Arm not included Turn the power OFF then disconnect the cables from the Touch LED LCD Monitor before performing the procedure below. 1. Lay the Touch LED LCD Monitor face down on a soft surface. 2. -
Page 20: Troubleshooting
Troubleshooting No power Make sure A/C power cord is securely connected to the power adapter and the power supply is firmly connected to the Touch LED LCD Monitor . Plug another electrical device into the power outlet to verify that the outlet is supplying proper voltage. -
Page 21: Planar Support
Planar Support Cables and Accessories To find cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com. Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touchscreen drivers, warranty information and access to Planar's Technical Library for online trouble shooting. - Page 22 2015 2001132483T 020-1193-00F...
