Summary of Contents for Planar PXL2430MW
- Page 1 PXL2430MW LED Touch Monitor USER'S GUIDE www.planar.com Planar utilizes HDMI® standards in this product. The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
-
Page 2: Table Of Contents
Basic Operation and Calibration/Reset Instructions ................... 9 Advanced Operation—OSD Menu ......................... 11 Supporting Timing Modes ............................14 Technical Information ..............................15 Wall-Mount Installation Instructions ........................16 Troubleshooting................................16 Troubleshooting................................17 Planar Support ................................18... -
Page 3: Operation Instructions
Operation Instructions Thank you for purchasing the PXL2430MW dua -touch LED monitor. Please read this guide thoroughly before installation. FCC RADIO FREQUENCY INTERFERENCE STATEMENT WARNING: (FOR FCC CERTIFIED MODELS) This LED Monitor has been tested and found compliant with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. - Page 4 Please recycle or dispose of all electronic waste in accordance with local, state, and federal laws. Additional resources can be found online at http://www.planar.com/about/green/ The crossed-out wheelie bin symbol is to notify consumers in areas subject to Waste Electrical and Electronic Equipment (WEEE) Directive 2012/19/EU that the product was placed on the market after August 13, 2005 and must not be disposed of with other waste.
-
Page 5: Unpacking Instructions
Unpacking Instructions Move the LED Monitor out of the package and take o the plastic bag and Polystyrene Foam. Pull the base from Parallel versus Panel to Vertical. Adjust the Panel between 0° leaning forward and 20° leaning backward. Safety Precautions Follow all warnings, precautions and maintenance as recommended in this user’s manual to maximize the life of your unit. - Page 6 Consignes de sécurité Respectez tous les avertissements, les précautions et conseils d’entretien recommandés dans ce manuel de l’utilisateur pour maximiser la durée de vie de votre appareil. A faire : Éteindre le produit avant de le nettoyer. La surface de l'écran tactile peut être nettoyée avec un chi on doux et propre imprégné d’un nettoyant doux du commerce pour vitres ou d'un mélange à...
-
Page 7: Package Overview
Package Overview Touchscreen LED Monitor Power Cord s ’ r... -
Page 8: Front View Of The Product
Front View of the Product ① ② ③ ④ ⑤⑥⑦ ① Touch Pen Slot ② OSD Turn On/ O ③ Volume Adjust/ Scroll Down/ Adjust Decrease ④ Preset Mode/ Scroll UP/ Adjust Increase ⑤ Input select/ Con rm Selection ⑥ LED Indicator ⑦... -
Page 9: Rear View Of The Product
Rear View of the Product ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑧ Power Input ⑨ USB - Type A to B ⑩ Headphone Jack ⑪ Audio Input ⑫ HDMI input (HDMI 19 pin) ⑬ DVI Input (DVI 24 pin) ⑭... -
Page 10: Quick Installation
Quick Installation Connect either VGA, DVI or HDMI Video Source from the monitor to the computer. Make sure both monitor and computer are powered OFF. Connect the audio cable from audio output of computer to the audio input of the monitor. Connect the USB cable from the computer to the monitor. -
Page 11: Basic Operation And Calibration/Reset Instructions
Basic Operation and Calibration/Reset Instructions Before using the Touchscreen LED Monitor: Connect external equipment properly. Insert the power plug, and the power LED indicator will light orange. Power On/O To turn the Touchscreen LED Monitor on/o : Press POWER button on the front. The power LED indicator light will be blue when the Touchscreen LED Monitor is on. - Page 12 The Touchscreen LED Monitor will show a “Lock Out” message for 3 seconds and the message will disappear automatically. Repeat this step to unlock. PXL2430MW Calibration/Reset Instructions: The PX2430MW is available with USB connection. It is Microsoft® Windows® 7 HID (Human Interface Device) compatible if you use the USB touch screen interface. No additional software driver is required.
-
Page 13: Advanced Operation-Osd Menu
Advanced Operation—OSD Menu You can use the OSD menu to adjust various settings for your Touchscreen LED Monitor. Press the 1 button to display the OSD Menu, and use ▲▼ to select the desired OSD menu. Short Cuts Function from the button(s) Auto Image Adjust: To auto adjust Horizontal Position, Vertical Position, Phase (Fine Tune) and Clock (H. - Page 14 Input Select: When Input Select is pressed, change Input signal to VGA, DVI, HDMI or Auto. Audio Adjust: To adjust the audio functions. Volume: To adjust the volume of speaker output. Mute: To turn the Mute ON/OFF. Audio Input: When in HDMI input, select where the audio source comes from Line-In or HDMI.
- Page 15 or ▲ button. Video Mode Adjust: To select the video mode from Full Screen or Aspect Ratio. Aspect Ratio: To select input timing image size. Full Screen: To select full-screen size image. BLUE LIGHT REDUCER: To decrease the blue light emitted from the display to reduce the risk of blue light exposure to your eyes.
-
Page 16: Supporting Timing Modes
Supporting Timing Modes STANDARD RESOLUTION 720 x 400 @ 70Hz 640 x 480 @ 60Hz 640 x 480 @ 67Hz VESA 640 x 480 @ 72Hz VESA 640 x 480 @ 75Hz VESA 800 x 600 @ 56Hz VESA 800 x 600 @ 60Hz VESA 800 x 600 @ 72Hz VESA... -
Page 17: Technical Information
Technical Information Panel 23.6” TFT (with LED backlight) Power Management On: 21 Watts (typical), 40 Watts (maximum) Standby Mode: < 0.5 Watt O : < 0.5 Watt Displayable Resolution Full HD 1920 x 1080 max. Vertical Frequency 60Hz max. Pixel Dimension 0.2715 x 0.2715 mm Display Color 16.7M... -
Page 18: Wall-Mount Installation Instructions
Wall-Mount Installation Instructions Wall Mount Arm not included Turn the power OFF then disconnect the cables from the Touchscreen LED Monitor before performing the procedure below. 1. Lay the Touchscreen LED Monitor face down on a soft surface. 2. Remove 2 screws holding the stand to the hinge. 3. -
Page 19: Troubleshooting
Troubleshooting No power Make sure A/C power cord is securely connected to the power adapter and the power supply is rmly connected to the Touchscreen LED Monitor . Plug another electrical device into the power outlet to verify that the outlet is supplying proper voltage. -
Page 20: Planar Support
Planar Support Cables and Accessories To nd cables and accessories for your Planar monitor, touch screen or other Planar products visit our online store at www.PlanarOnline.com. Technical Support Visit Planar at http://www.planar.com/support for operations manuals, touchscreen drivers, warranty information and access to Planar's Technical Library for online trouble shooting. - Page 21 Hours: 24 hours a day, 7 days a week 03/2020 Planar Systems, Inc. © Planar is a registered trademark of Planar Systems, Inc. Other brands and names are the property of their respective owners. Technical information in this document is subject to change without notice.
