SETUP

Enable MIDI Messages

You can select whether HEX responds to MIDI Program Change (PC), Control
Change (CC), both message types, or none.
NOTE: When using Voodoo Lab Ground Control Pro or Commander, you must
disable both PC and CC.
The default is both PC and CC are disabled.
1) Apply power while holding down button #1. The LEDs will flash until you
release the button.
2) Press buttons #1 and #2 to select message types:
MIDI Message Type
None*
PC only
CC only
Both PC and CC
*None is the correct setting for Voodoo Lab controllers only.
3) Remove power when finished.

Set MIDI Channel

MIDI Program Change and Control Change messages include a channel
number, 1-16. HEX will only respond to messages received on its specified
channel.
The default MIDI channel is 1.
NOTE: When HEX is being controlled by a Voodoo Lab Ground Control Pro or
Commander the MIDI channel setting is ignored.
1) Apply power while holding down button #2. The LEDs will flash until you
release the button.
2) Press buttons #1 through #4 to select the MIDI channel:
LED #1 LED #2
OFF OFF
ON OFF
OFF ON
ON ON
7
