- Page 1 AMP SELECTOR User’s Manual D I G I T A L M U S I C C O R P O R A T I O N...
- Page 2 This publication is protected by copyright and all rights are reserved. No part of it may be reproduced or transmitted by any means or in any form without the express prior consent in writing from Digital Music Corporation. Voodoo Lab is a trademark of Digital Music Corp.
- Page 3 Amp Selectors if you need more than four amps. Voodoo Lab provides tone tools for the serious artist and profession- al player. Your Amp Selector is hand made using the finest possible components and engineered to be rugged, reliable and provide the...
- Page 4 Level Controls: Control output volume to balance amps. Amp Select Buttons: Turn individual amps on/off. Status LEDs: Illuminates to show active amp. POWER Hand made in U.S.A. GROUND The Voodoo Lab Amp Selector’s inputs drive a pair of ultra trans- 9VDC INPUTS TUNER/THRU AMPS LIFT parent buffer amplifiers.
- Page 5 guitar amp. This insures that your guitar pickups will see the correct load and therefore sound their best. Using a buffer amplifier is what allows us to drive multiple amplifiers and a tuner without excessively loading your guitar and destroying your tone. Each amplifier output is coupled using a high quality shielded and sealed transformer.
- Page 6 Power. It will also work fine with other 9VDC regulated adapters such as the Boss PSA. Powering the Amp Selector on and off is done via the input jack, just like most pedal effects. Insert a cable into Input-A to power on.
-
Page 7: Operation
Operation On/off and Exclusive Mode The default switching method of the Amp Selector is what we call on/off mode. In on/off mode, each of the four buttons 1 through 4 simply toggle the corresponding amp output on and off. Using on/off mode is a good choice if you want maximum flexibili- ty to switch or layer amps. - Page 8 Exit programming mode. That’s it! Ground Problems You should always start with all of the Amp Selector’s Grounds Lift switches in the ON position. This means the output is grounded. If the amp is humming, the first place to look is if there is a two or three position ground switch on the amplifier itself.
-
Page 9: Warranty
RMA and given shipping and packaging instructions. How to Reach Us All Voodoo Lab products are manufactured by Digital Music. You can reach us by any of the following: Tel: 707 782 0600...
