4
Setting a Paper Size, Fold Type, and
Quantity
Press the "SIZE SELECT" button located on the operator interface to specify your
paper size.
Press the "FOLD SELECT" button and choose the fold type you wish from the
selection.
Press the "QUANTITY" button, input the numbers of pages to fold, and
then press the enter button.
You are now ready to begin folding paper.
5
Folding Paper
Pressing the "RUN" button will initiate folding. Folding will continue until one of
the follow conditions is met:
1. The Stop button is pressed,
2. The Feed Table becomes empty of paper,
3. A folding error is encountered, or
4. The programmed quantity reaches 0 (zero).
In case of emergency, press the "STOP" button to
automatically stop the machine.

Operator Interface

Memory
Display
Control
Fold
Types
Paper Sizes
Fold Select
M-S027126
Incremental
2nd Fold
Stack
Adjustment
Table
Wheels
Size Select
Display Contrast
Enter
Quantity
Custom Paper
Test
Clear
Length
Entry
1

Setting up the Machine

2
Fold Table Installation
3

Loading the Paper

1st Fold
Table
Setting a Paper Size, Fold Type, and
4
Folder
Quantity
Speed
Run
5
Folding Paper
Stop
"For important safety instructions and warnings, refer to the
Rev. 2 8/16/13
2051 SmartFold™
Quick Start Instructions
User Manual."

Advertisement

loading
Need help?

Need help?

Do you have a question about the 2051 SmartFold and is the answer not in the manual?

Questions and answers

Summary of Contents for Martin Yale 2051 SmartFold

  • Page 1: Setting Up The Machine

    Setting a Paper Size, Fold Type, and Quantity 2051 SmartFold™ Press the "SIZE SELECT" button located on the operator interface to specify your paper size. Quick Start Instructions Press the "FOLD SELECT" button and choose the fold type you wish from the selection.
  • Page 2 Extension De-jam Handle Fold Table Installation Storage Feed Table Top Cover 1st Fold Table Step 1: slide the front slot opening of the fold table onto the inner set of pins (closest to the folding rollers). Step 2: lower the fold table onto the outer set of pins. Repeat Steps 1 & 2 for 2nd Fold Table installation (see illustration below).
