  • Page 1 Tilti Out Drive System Speed Agitator Controls For 40, 60 & 80 Gallon Kettles DEE/4T-(40,60) TA/3 DHT -(40,60) TA/3 D -(40,60,80) TA/3 DHT - TA/3 THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ, UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS CONTAINED IN THIS MANUAL.
  • Page 2 OM/TA/3 IMPORTANT — READ FIRST — IMPORTANT...
  • Page 3 EYES, MUCOUS MEMBRANES AND CLOTHING. READ THE WARNINGS AND FOLLOW DIRECTIONS ON THE CLEANER LABEL. WARNING: USE OF ANY REPLACEMENT PARTS OTHER THAN THOSE SUPPLIED BY GROEN OR THEIR AUTHORIZED DISTRIBUTOR VOIDS ALL WARRANTIES AND CAN CAUSE BODILY INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT.
  • Page 4 OM/TA/3 WARNING DO NOT PLACE HANDS, TOOLS, OR HOSES IN KETTLE WHILE AGITATOR IS MOVING AGITATOR INSTRUCTIONS *WARNING* AGITATOR AREA MUST BE CLEAR OF OBSTRUCTION BEFORE OPERATION TO RUN AGITATOR ENSURE KETTLE IS FULLY UPRIGHT ENSURE MIXER HEAD IS FULLY DOWN AND LATCHED...

  • Page 5: Table Of Contents

    OM/TA/3 Table of Contents IMPORTANT OPERATOR WARNINGS ..........2 REFERENCES .

  • Page 6: Equipment Description

    CHANGE MUST BE APPROVED BY THE GROEN FOOD SERVICE ENGINEERING DEPARTMENT. Your Groen mixer has been test operated at the factory and is furnished with all internal wiring. It is complete and ready for final connection. A WARNING...
  • Page 7 If the unit functions as described above, it is ready for use. If the unit does not function as intended, call your local Groen authorized service agency. For instructions on initial start-up of the kettle component of your cooker/mixer, see the separate kettle manual.

  • Page 8: Operation

    OM/TA/3 Operation WARNING TURN OFF AGITATOR BEFORE ADDING INGREDIENTS OR INSPECTING KETTLE CONTENTS. DO NOT WEAR LOOSE CLOTHING OR JEWELRY AROUND OPERATING MIXER KETTLE. KEEP WELL CLEAR OF ROTATING MIXER ARMS AND PADDLES AT ALL TIMES. 1. Before you operate the mixer, make sure that the agitator is firmly connected with the 5.

  • Page 9: Cleaning

    OM/TA/3 Cleaning A. Suggested Tools & Materials. A good stainless steel cleaner. 2. Stiff brush. 3. Sanitizer Solution B. Precautions Photo 2 WARNING BEFORE CLEANING ANY PART OF THE MIXER, OTHER THAN THE AGITATOR, SHUT OFF ALL ELECTRIC POWER TO THE...
  • Page 10 OM/TA/3 agent from your supplier of sanitation CAUTION products. Following the supplier’s directions, WHEN YOU CONNECT THE SCRAPER WITH apply the sanitizer after the agitator has THE YOKE, MAKE SURE THE SCRAPER IS been washed, then rinse off the sanitizer CURVED THE SAME WAY AS THE KETTLE.

  • Page 11: Maintenance

    Maintenance B. Component Replacement WARNING USE OF ANY REPLACEMENT PARTS WARNING OTHER THAN THOSE SUPPLIED BY GROEN BEFORE REPLACING ANY PARTS, SHUT OR THEIR AUTHORIZED DISTRIBUTOR OFF ALL ELECTRIC POWER SUPPLIES TO VOIDS ALL WARRANTIES AND CAN CAUSE THE COOKER/MIXER.

  • Page 12: Troubleshooting

    OM/TA/3 Troubleshooting Your Groen Mixer will operate smoothly and efficiently if properly maintained. However, the following is a list of checks to make in the event of a problem. If the actions suggested do not solve the problem, call your authorized Groen Service Representative. For the phone number of the nearest agency, check the Groen web site at www.groen.com, ask your area Groen representative or call the Groen Parts and...

  • Page 13: Parts List

    OM/TA/3 Parts List To order parts, contact your authorized Groen Service Agency. Supply the model designation, part description, part number and quantity required. Where applicable, provide the voltage and phase as well. WARNING USE ONLY GROEN-SUPPLIED PARTS. SUBSTITUTION OF UNAUTHORIZED OR GENERIC PARTS CAN RESULT IN BODILY INJURY TO THE OPERATOR AND DAMAGE TO THE EQUIPMENT.
  • Page 14 OM/TA/3 Parts List Description Part No. Description Part No. Switch Assembly Agitator 128485 Handle & Latch Assy 044392 Switch Assembly Speed Control 115341 Bracket Arm Guide 002124 Switch Assembly Emergency Stop 115342 005474 Pin Taper #4 2" Long Enclosure Nema...
  • Page 15 OM/TA/3 Parts List Description Part No. Description Part No. Holder Scraper Blade 001724 010561 Holder Assy Scraper 80 Gal Holder Assy Scraper 60 Gal 010557 Holder Assy Scraper 80 Gal 010563 Clip Hairpin Agitator Secondary 60 Gal 009687 012947 009245...
  • Page 17 SCREW HEX HD CAP 1/4-20 X 5/8" 18-8 S COVER PLATE, TRANSFER CASE, DTA/3 TRANSFER CASE BEAD FINISH POLISHED D-40, TA/3 CAST ALUMINUM SCREW FLAT HD #3/8-16 X 3/4" LONG ZINC PLTD SHAFT 3/4" DIA X 7-5/8" LONG FOR DTA/3 BEARING ROLLER W/O INNER RACE 1"...

  • Page 20: Service Log

    OM/TA/3 Service Log Model No. _______________________________ Purchased From _________________________ Serial No. ______________________________ Location ________________________________ Date Purchased __________________________ Date Installed ____________________________ Purchase Order No. _______________________ For Service Call __________________________ Date Maintenance Performed Performed by...

  • Page 21: Warranty 2

    (“Groen Equipment”) (other than CapKold foodservice equipment) shall be free from defects in material and workmanship for (12) twelve months from the date of installation or fifteen (15) months from date of shipment from Groen, whichever date first occurs (the “Warranty Period”), in accordance with the following terms and conditions: This warranty is limited to replacement parts and related labor for Groen Equipment located at its original place of installation in the United States and Canada.

  • Page 22: Warranty

    FOR THE BREACH OR DELAY IN PERFORMANCE OF THIS WARRANTY. VIII. Groen Equipment is for commercial use only. If sold as a component of another (O.E.M.) manufacturer’s equipment, or if used as a consumer product, such Equipment is sold AS IS and without any warranty.
  • Page 23 1055 Mendell Davis Drive OM/TA/3 Jackson, MS 39212 (Revised 3/03) Telephone 601 372-3903 Part Number 141909 Rev A FAX 601 373-9587...
