OPERATOR MANUAL
IMPORTANT INFORMATION, KEEP FOR OPERATOR
2016 Gees Mill Road, Suite 200, Conyers, GA 30013
888-994-7636, fax 888-864-7636
unifiedbrands.net
THIS MANUAL MUST BE RETAINED FOR FUTURE REFERENCE. READ,
UNDERSTAND AND FOLLOW THE INSTRUCTIONS AND WARNINGS
CONTAINED IN THIS MANUAL.
FOR YOUR SAFETY Instructions to be followed in the event user smells
gas. This information shall be obtained by consulting your local gas
supplier. As a minimum, turn off the gas and call your gas company and
your authorized service agent. Evacuate all personnel from the area.
WARNING Improper installation, adjustment, alteration, service or
maintenance can cause property damage, injury or death. Read the
installation, operating and maintenance instructions thoroughly before
installing or servicing this equipment.
NOTIFY CARRIER OF DAMAGE AT ONCE It is the responsibility of the
consignee to inspect the container upon receipt of same and to determine
the possibility of any damage, including concealed damage. Unified
Brands suggests that if you are suspicious of damage to make a notation
on the delivery receipt. It will be the responsibility of the consignee to file
a claim with the carrier. We recommend that you do so at once.
Manufacture Service/Questions 888-994-7636.
EQUIPMENT DESCRIPTION
The Groen GFK-20 cooker/mixer consists of a water-jacketed kettle with a
motor-driven mixer. The 20 quart tilting kettle is equipped with electronically
controlled electric heaters for the jacket.
The kettle of models GFK-20-110V and GFK-20-220V is constructed of stainless
steel welded into one piece. The body has a reinforced rim and a butterfly-
shaped pouring lip. It is fitted with an integral water jacket. The kettle exterior
has a bright semi-deluxe finish. The kettle's pouring height allows filling pans up
to 4 inches high on a table top.
The kettle's internal electric heaters provide uniform heat in three stages, with
jacket temperature control over the range of 140ºF to 180ºF (60ºC to 80ºC).
In addition to the three-stage adjustable thermostat for operating control, the
unit has a high limit thermostat, as a safety feature, plus an indicator lamp and
water gauge glass, which is used to monitor kettle operation.
The Agitator fits over the agitator post inside the kettle. Mixing is controlled with
a power switch. The switch doubles as a circuit breaker for motor protection.
The agitator continuously sweeps the side and bottom of the kettle.
Electric power for the kettle and mixer is supplied through a plug-in power cord,
which is furnished with the unit.
This manual provides information for:
JACKETED FUDGE KETTLE
MODELS GFK-20-110V, GFK-20-220V
REFERENCES
KLENZADE SALES CENTER ECOLAB, Inc.
370 Wabasha
St. Paul, Minnesota 55102
800/352-5326 or 612/293-2233
NFPA/70 The National Electrical Code
NATIONAL FIRE PROTECTION ASSOCIATION
60 Battery March Park
Quincy, Massachusetts 02269
GFK-20-110V: 6' - 12 AWG cord and 20 amp, 3-wire straight blade plug
GFK-20-220V: 6' - 12 AWG cord and 15 amp, NEMA L6-15 plug
Standard unit operation requires connection to a single phase, 110/115 VAC, 60
Hz, 20A separate, dedicated branch circuit for the 110VAC model and a single
phase, 220VAC 50Hz 15A separate, dedicated branch circuit for the 220VAC
model.
Capacity
Diameter
Depth
Space Required Side to Side
Space Required Vertical
Space Required Front to Back
Back Tilt Clearance
The information in this document is Confidential and shall not be disclosed to any third party without the express written
consent of Unified Brands. Information contained in this document is known to be current and accurate at the time of printing/
creation. Unified Brands recommends referencing our product line websites, unifiedbrands.net, for the most updated product
information and specifications. © 2021 Unified Brands. All Rights Reserved. Unified Brands is a wholly-owned subsidiary
of Dover Corporation.
PART NUMBER 178054, REV. A (02/21)
· Self Contained
· Table Top Mounted
· Electrically Heated
· Tilting
· Tilt Lock Option (left hand only)
· Power Agitator
NSF INTERNATIONAL
798 N. Dixboro Rd.
P.O. Box 130140
Ann Arbor, Michigan 48113-0140
UNDERWRITERS LABORATORIES, INC.
333 Pfingsten Road
Northbrook, Illinois 60062
ZEP MANUFACTURING CO.
1310-T Seaboard Industrial Blvd.
Atlanta, Georgia 30318
20 quarts 18.8 liters
18.25 inches 47 cm
8 inches 20 cm
26 inches 66 cm
36 inches 92 cm
32 inches 82 cm
6 inches 16 cm
