- Page 1 RF INTERLINK BASE DS700RFF IMPORTANT: Please read this manual before installation. If installing the alarm for others please leave a copy for the end user. 0086-CPD-517190 EN 14604: 2005...
-
Page 2: Table Of Contents
CONTENTS 1. Introduction 2. Quick installation guide 3. Installation guide 3.1 DS700RF installation and set-up 3.2 Learning in a new system 3.3 Learning in an additional unit to an existing DS700RF system 4. Operating conditions 5. Trouble shooting 6. Disposal 7. -
Page 3: Introduction
1. INTRODUCTION This DS700RF RF interlink base is designed to be used in conjunction with any BRK mains operated Smoke and Heat alarms in the 670, 650, 680 series ONLY. Interlinked Smoke and Heat alarms which utilise RF interlink technology have the benefit of being able to be used in a Grade D or E alarm system without the need for hardwiring connection between each alarm in the system. -
Page 4: Quick Installation Guide
2. QUICK INSTALLATION GUIDE a) Install each DS700RF base in an appropriate position at least 300mm from the nearest light fitting (ref Smoke/ Heat alarm instructions) and connect to the nearest mains circuit. DO NOT SWITCH ON MAINS POWER. b) Learn in each base by pressing the button (See Fig 1) using a small screwdriver. - Page 5 Fig 1. Fig 2. Learn in button...
-
Page 6: Installation Guide
Connect the alarm as late as possible in an installation, particularly in new build, to avoid contamination. Remove the dust cover before applying power. Fig 3. 3.1) DS700RF INSTALLATION AND SETUP Live = Brown Neutral = Blue Earth... - Page 7 Install the DS700RF docking base on the ceiling no closer than 300mm from the nearest light fitting. Always refer to your Smoke/Heat alarm manual for positioning and installation guidance. b) Bring wires through either the YT2 trunking knockout on...
-
Page 8: Learning In A New System
2) A separately electrically protected, regularly used local lighting circuit. For mains powered alarms with no standby supply (Grade E), the mains electricity supply may only take the form of an independent circuit as per 1) above. If it is necessary to use an RCD for protection, it should operate independently of any RCD protection for circuits supplying sockets or portable equipment. - Page 9 NOTE: The system must be learnt in before the alarms are installed on the base. a) Locate the push button on an installed DS700RF and press briefly using a small screwdriver (see Fig 1). The amber LED will illuminate for 3 seconds to indicate that it is activated.
-
Page 10: Learning In An Additional Unit To An Existing Ds700Rf System
Ensure the amber LED on every DS700RF flashes once every three seconds. g) Press the test button on each alarm in the system in turn and ensure 1) the alarm sounds and 2) it links with every other alarm in the system. - Page 11 Restore mains power to all the installed alarms and the new DS700RF. c) Locate the push button on the new DS700RF and press briefly using a small screwdriver. The amber LED will illuminate for 3 seconds to indicate it has been activated.
- Page 12 Install the new Smoke/Heat alarm onto the DS700RF as outlined in the alarm owner’s manual (See Fig 2). h) RESTORE MAINS POWER TO ALL ALARMS. Ensure all Smoke/Heat alarms in the system display a green power light and red operating light as per the user’s manuals.
-
Page 13: Operating Conditions
Amber operating LED: Located on the side of the DS700RF, this LED will remain off during normal working conditions. Any fault with the DS700RF will be indicated by a flash of the LED and a single chirp. Low battery warning: When a low battery condition on the... -
Page 14: Trouble Shooting
5. TROUBLE SHOOTING For queries on Smoke/Heat alarm related issues refer to the specific owner’s manual. Fault Action When I press the learn in Wait for at least 2 minutes to button the amber LED on the allow the system to respond. base does not flash. - Page 15 3.2 & 3.3. If you have any questions about the operation of your Smoke/ Heat alarms or DS700RF RF interlink base please contact the Technical Support line on +44 (0)1452 887570 or email us via the link on our website www.brkelectronics.eu...
-
Page 16: Disposal
6. DISPOSAL This product, the batteries and other accessories must not be disposed of as unsorted municipal waste and must be collected separately at the end of the product’s life. Contact your local authority for information about collection points in your area. -
Page 17: Limited Guarantee
The Distributor shall not be obligated to repair or replace DS700RF bases which are found to be in need of repair because of damage, unreasonable use, modifications or alterations occurring after the date of purchase. - Page 18 In the event of a problem with your DS700RF base or you have any questions concerning its use, care and service please consult this manual.
-
Page 19: Technical Specification
8. TECHNICAL SPECIFICATION Power: Independent 10 year (battery for life) lithium cell. Temperature: (operating):- 0°C - 40°C Humidity: 0-95% (non condensing) Warning: Visual and audible low battery warning Radio Frequency: 868MHz Wireless Range: Minimum 150m open air Dimensions: 140mm (D) x 30mm (H) Approvals: Independently tested and compliant with EMC, Electrical Safety and Radio Regulations to include requirements of the R&TTE Directive. - Page 20 Sprue Safety Products Ltd 6 Carter Court, Davy Way Waterwells Business Park Gloucester GL2 2DE UK A Sprue Safety Products Brand...
