Page 1: Service Manual
website:http://biz.LGservice.com e-mail:http://www.LGEservice.com/techsup.html PLAZMA MONITOR SERVICE MANUAL CHASSIS : NP-00KA MODEL : MT/MZ-60PZ10 CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. -
Page 2: Table Of Contents
CONTENTS Contents ......................... 2 Safety Precautions ....................3 Specifications ..................... 4 Control Descriptions ..................5 Adjustment Instructions ................9 T rouble Shooting ....................11 Block Diagram ....................13 Wiring Diagram ....................15 Exploded View ....................16 Exploded View Parts List ................17 Replacement Parts List ................ -
Page 3: Safety Precautions
SAFETY PRECAUTIONS IMPORT ANT SAFETY NOTICE General Guidance lsola Leakage Current Hot Check circuit AC Volt-meter Good Earth Ground such as WATER PIPE, CONDUIT etc. To Instrument's exposed METALLIC PARTS 1.5 Kohm/10W Leakage Current Cold Check(Antenna Cold Check) Leakage Current Hot Check Do not use a line Isolation Transformer during this check. -
Page 4: Specifications
SPECIFICA TIONS Note : Video receiving system: RGB Input(PC/DTV) Pixel clock Input Voltage Component Video Input Pixel clock H-Freq(Khz) V-Freq(hz) - 4 -... -
Page 5: Control Descriptions
CONTROLS DESCRIPTION <Front Panel> ON/OFF INPUT ON/OFF SELECT VOLUME Main power button Power standby indicator Illuminates red in standby INPUT SELECT Illuminates green when the VOLUME Monitor is switched on INPUT SELECT button Sub power button VOLUME ( ) buttons Remote control sensor - 5 -... -
Page 6: Back Panel
<Back Panel> AUDIO (MONO) VIDEO AUDIO COMPONENT (480i/480p) RGB-PC INPUT AV INPUT AUDIO INPUT S-VIDEO EXTERNAL SPEAKER (8Ω) AC INPUT (DVD INPUT) (VGA/SVGA/XGA/SXGA) AUDIO VIDEO (MONO) AUDIO COMPONENT (480i/480p) RGB-PC INPUT AV INPUT AUDIO INPUT AC INPUT EXTERNAL SPEAKER (8Ω) S-VIDEO (VGA/SVGA/XGA/SXGA) (DVD INPUT) - Page 7 Optional Extras - Optional extras can be changed or modified for quality improvement without any notification new optional extras can be added. - Contract your dealer for buying these items. AP-60WA20M AP-60WA10 (Wall mounting bracket) (Tilt wall mounting bracket) AP-60CA10 (Ceiling mounting bracket) AP-60FA10 (Floor type stand) AP-60DA10 (Desktop stand) AP-60SA10 (Speakers)
-
Page 8: Controls Of The Remote Control
VOLUME ( selects a menu item. INPUT SELECT button on the remote control Each press of this button changes POWER STOP P/STILL the mode as below. VCR BUTTONS PLAY Video Component controls a LG video cassette recorder. - 8 -... -
Page 9: Adjustment Instructions
ADJUSTMENT INSTRUCTIONS 1. Application Object (3) Vs Adjustment ¤ Connect pin 9 of P803 to (+) jack of D.M.M. These instructions are applied to all of the PDP monitor, NP- ¤ŁAfter turning the VR804(Vs Adj), voltage of D.M.M 00KA. adjust as same as Vs voltage which indicated on label of panel right/bottom.(Deviation : ±0.5V) 2. - Page 10 4-3. Adjustment of White Balance • Operate the Zero-calibration of the CA—100, then stick sensor to PDP module surface when you adjust. • For manual adjustment, it is also possible by the following sequence. (1) Select WHITE PATTERN of HEAT RUN mode by pressing ADJ button on Remote Control for adjustment then operate HEAT RUN more than 15 minute.
-
Page 11: Troubleshooting
TROUBLESHOOTING 1. No Video Abnormal Picture Abnormal Check JAGASM Input PC signal. IC501 Normal Check CXA2101 Check SII150 IC203 IC901 Normal Check ADV7123 Check cable of pin 21 IC406 P901 Normal Check FLI2220 IC404 Normal Check FLI2200 IC403 Normal Check VPC3230 IC201 Normal Check Input jack &... -
Page 12: No Video
3. No Video Nothing output of image. Abnormal Check Input of AC. Connect plug with the set. (85~225V) Normal Abnormal Check ST-BY LED ON Check AC Line Fuse. Main S/W ON. Normal Abnormal Abnormal Check LED YELLOW Check OPEN with PFC R8301, Replace R8301, R8302, R8303. -
Page 13: Block Diagram
BLOCK DIAGRAM 1. VSC Board PC_V,H STB_Y,Pb,Pr DTV_R,G,B,V,H R,G,B PIP_Y,U,V R,G,B STB_R,G,B,H,V S_Y/ C DTV_Y,Pb,Pr RGB- PC/ RGB INPUT/ AUDIO COMPONENT AC INPUT RGB- DTV CONTROL INPUT - 13 -... -
Page 14: Power Board
2. POWER Board 5 V mo ni VS on VS on - 14 -... -
Page 15: Wiring Diagram
Wiring Diagram P8011 P8012 P8013 P803B P807A P804B P830A P808B P840A P200 P803A P801 P802 P808A P801 P001B P806B P806A P805A P601A P901 P1720 P002B P102 P806A+P601A - 15 -... -
Page 16: Exploded View
EXPLODED VIEW - 16 -... -
Page 17: Exploded View Parts List
EXPLODED VIEW PARTS LIST Part No. Description 5900V08004A FAN,DC F8025L12B2-RG DONG YANG 80MM 12V 120MA 2300RPM 79G L 300MM 3210V00054C FRAME, FRONT TOP MP-60PZ10, MT-60PZ10, MZ-60PZ10” 3210V00055C FRAME, FRONT TOP MP-60PZ10, MT-60PZ10, MZ-60PZ10” 3210V00056A FRAME, FRONT RIGHT FD-60X3 . 3210V00057A FRAME, FRONT LEFT FD-60X3 . -
Page 18: Replacement Parts List
REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION IC8131 0IUN386300B UC3863DW 20PLCC R/TP PFZO CONT TNY255P 8DIP ST LOW POWER OFF- IC8201 0IPF255000A IC101 0IAL242110A AT24C21-10SI-2.5 8P,SOP TP 1K IC8202 0IPF255000A TNY255P 8DIP ST LOW POWER OFF- IC102 0IMCRMI006A M52758FP MITSUBISHI 36PIN, R/T... - Page 19 LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION Q301 0TR387500AA CHIP 2SC3875S(ALY) KEC Q8505 0TR322709AA KTC3227-Y,TP(KTC1627A),KEC Q302 0TR387500AA CHIP 2SC3875S(ALY) KEC Q8601 0TR150400BA CHIP 2SA1504S(ASY) KEC Q303 0TR150400BA CHIP 2SA1504S(ASY) KEC Q8602 0TR150400BA CHIP 2SA1504S(ASY) KEC Q304 0TR387500AA CHIP 2SC3875S(ALY) KEC Q8604 0TR150400BA...
- Page 20 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 21 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 22 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 23 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 24 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 25 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 26 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
- Page 27 PRINTED CIRCUIT BOARD POWER(TOP) MAIN(TOP) POWER(BOTTOM) MAIN(BOTTOM)
- Page 28 POWER MAIN(TOP) CONTROL(TOP) POWER PFC(TOP) POWER VA(TOP) POWER VS(TOP) CONTROL(BOTTOM) POWER VA(BOTTOM) POWER VS(BOTTOM) POWER PFC(BOTTOM) A/V(TOP) POWER CONTROL(TOP) POWER CONTROL(BOTTOM) A/V(BOTTOM) POWER MAIN(BOTTOM)
- Page 37 Aug.,2001 P/NO : 3828VD0070L Printed in Korea...
