PLASMA MONITOR

SERVICE MANUAL

CHASSIS : NP-00KB
MODEL : MT/MZ-60PZ12/B
MODEL :
MT/MZ-60PZ14/B
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
website:http://biz.LGservice.com
e-mail:http://www.LGEservice.com/techsup.html

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MZ-60PZ12 and is the answer not in the manual?

Questions and answers

Summary of Contents for LG MZ-60PZ12

  • Page 1: Plasma Monitor

    PLASMA MONITOR SERVICE MANUAL CHASSIS : NP-00KB MODEL : MT/MZ-60PZ12/B MODEL : MT/MZ-60PZ14/B CAUTION BEFORE SERVICING THE CHASSIS, READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
  • Page 2: Table Of Contents

    CONTENTS Contents ......................... 2 Safety Precautions ....................3 Specifications ..................... 4 Control Descriptions ..................5 Adjustment Instructions ................9 T rouble Shooting ....................11 Block Diagram ....................13 Exploded View ....................16 Exploded View Parts List ................17 Replacement Parts List ................18 SVC.
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS IMPORT ANT SAFETY NOTICE Many electrical and mechanical parts in this chassis have special safety-related characteristics. These parts are identified by the Schematic Diagram and Replacement Parts List. It is essential that these special safety parts should be replaced with the same components as recommended in this manual to prevent X-RADIATION, Shock, Fire, or other Hazards.
  • Page 4: Specifications

    SPECIFICA TIONS Note : Specification and others are subject to change without notice for improvement. Video receiving system: RGB Input(PC/DTV) SECAM NTSC-M REsolution H-Freq(hz) V-Freq(hz) Pixel clock Proposed NTSC 4.43 640*350 31.469 70.09 70.09 Input Voltage : AC 110~240V, 50/60Hz(MT-) 640*350 37.861 85.08...
  • Page 5: Control Descriptions

    CONTROL DESCRIPTIONS <Front Panel> ON/OFF INPUT ON/OFF SELECT VOLUME Main power button Power standby indicator Illuminates red in standby INPUT SELECT Illuminates green when the VOLUME Monitor is switched on INPUT SELECT button Sub power button VOLUME ( ) buttons Remote control sensor - 5 -...
  • Page 6: Back Panel

    <Back Panel> AUDIO (MONO) VIDEO AUDIO COMPONENT(480i/480p) RGB-PC INPUT AV INPUT S-VIDEO AUDIO INPUT RS-232C EXTERNAL SPEAKER (8Ω) AC INPUT (VGA/SVGA/XGA/SXGA) (DVD INPUT) VIDEO AUDIO AUDIO (MONO) RGB-PC INPUT COMPONENTI(480i/480p) AV INPUT S-VIDEO AUDIO INPUT RS-232C AC INPUT EXTERNAL SPEAKER 8Ω (VGA/SVGA/XGA/SXGA) (DVD INPUT) POWER INPUT...
  • Page 7 Optional Extras - Optional extras can be changed or modified for quality improvement without any notification new optional extras can be added. - Contract your dealer for buying these items. AP-60WA20M series AP-60WA10 series (Tilt wall mounting bracket) (Wall mounting bracket) AP-60CA10 series AP-60FA10 series (Ceiling mounting bracket)
  • Page 8: Controls Of The Remote Control

    VOLUME ( selects a menu item. INPUT SELECT button on the remote control Each press of this button changes POWER STOP P/STILL the mode as below. VCR BUTTONS PLAY Video Component controls a LG video cassette recorder. - 8 -...
  • Page 9: Adjustment Instructions

    ADJUSTMENT INSTRUCTIONS 1. Application Object (3) Vs Adjustment ¤ Connect pin 9 of P803 to (+) jack of D.M.M. These instructions are applied to all of the PDP monitor, NP- ¤ŁAfter turning the VR804(Vs Adj), voltage of D.M.M 00KB. adjust as same as Vs voltage which indicated on label of panel left/top.(Deviation : ±0.5V) 2.
  • Page 10 4-3. Adjustment of White Balance • Operate the Zero-calibration of the CA—100, then stick sensor to PDP module surface when you adjust. • For manual adjustment, it is also possible by the following sequence. (1) Select WHITE PATTERN of HEAT RUN mode by pressing ADJ button on Remote Control for adjustment then operate HEAT RUN more than 15 minute.
  • Page 11: Troubleshooting

    TROUBLESHOOTING 1. No Video Abnormal Picture Abnormal Check JAGASM Input PC signal. IC501 Normal Check CXA2101 Check SII150 IC203 IC901 Normal Check ADV7123 Check cable of pin 21 IC406 P901 Normal Check FLI2220 IC404 Normal Check FLI2200 IC403 Normal Check VPC3230 IC201 Normal Check Input jack &...
  • Page 12: No Video

    3. No Video Nothing output of image. Abnormal Check Input of AC. Connect plug with the set. (85~225V) Normal Abnormal Check ST-BY LED ON Check AC Line Fuse. Main S/W ON. Normal Abnormal Abnormal Check LED YELLOW Check OPEN with PFC R8301, Replace R8301, R8302, R8303.
  • Page 13: Block Diagram

    BLOCK DIAGRAM 1. VSC Board - 13 -...
  • Page 14: Power Board

    2. POWER Board 5 V mo ni VS on VS on - 14 -...
  • Page 15 MEMO - 15 -...
  • Page 16: Exploded View

    EXPLODED VIEW - 16 -...
  • Page 17: Exploded View Parts List

    EXPLODED VIEW PARTS LIST Part No. Description 5900V08004A FAN,DC F8025L12B2-RG DONG YANG 80MM 1 6348Q-B032D PDP 60” 16:9 1280*720 FOR DND INTE 6871QRH015B PWB ASSY,DISPLAY XRRT ASSY 60HD4(X 6871QTH021A PWB ASSY,DISPLAY ZCNT ASSY 60HD4 2 6871QZH018B PWB ASSY,DISPLAY ZSUS ASSY 60HD4(Z_ 6871QTH022A PWB ASSY,DISPLAY ZCNT ASSY 60HD4 2L 6871QRH014B...
  • Page 18: Replacement Parts List

    REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION IC8104 0ISH121100D IC,PQ12DZ1U 5 SMD R/TP REGULATOR IC8131 0IUN386300B IC,UC3863DW 20PLCC R/TP PFZO CONT 0IDS162100B IC,DS1621V 8P SOIC ST THERMOSTAT IC8201 0ISK615311B IC,STR-G6153T(LF1101) 5PIN BK STR 0IPH743200A IC,74HC32D 14SOP TP QUAD 2-INPUT IC,STR-G6153T(LF1101) 5PIN BK STR IC8202...
  • Page 19 LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION D803 0DZ750009AG DIODE,ZENERS MTZJ7.5B TP ROHM-K DO34 0.5W D8503 0DZ610009AA DIODE,ZENERS P6KE100A TP G.I 1W 100V 1UA D804 0DZ240009CG DIODE,ZENERS MTZJ24B TP ROHM-K DO34 24V D8504 0DD100009AP DIODE,RECTIFIERS EG1ZV(1) TP D805 0DD120000BB DIODE,RECTIFIERSFML-G12S...
  • Page 20 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 21 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 22 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 23 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 24 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 25 6602V39001F CONNECTOR,3.96MM 8P GP390-*P LG PDP AR427 0RRZVTA001A P804B 366-921D AR428 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 OH CONNECTOR,2.5MM 5P GIL-G LG CABLE . P804A 387-A05A CONNECTOR ASSY,5P (L=100) AR501 0RRZVTA001A MNR-14-E0A-J-101 R OHM 100 OH P805A 387-A07A CONNECTOR ASSY,7P (L=100)
  • Page 26 For Capacitor & Resistors, CC, CX, CK, CN : Ceramic RD : Carbon Film the charactors at 2nd and 3rd CQ : Polyestor RS : Metal Oxide Film digit in the P/No. means as CE : Electrolytic RN : Metal Film follows;...
  • Page 27 0RD3301F609 3.3K OHM 1/6 W 5.00% TA52 R8522 0RD1002F609 10K OHM 1/6 W 5.00% TA52 SW001 140-315A SWITCH,TACT SKHV17910B LG C&D NON 12V R8523 0RD1002F609 10K OHM 1/6 W 5.00% TA52 SW002 140-315A SWITCH,TACT SKHV17910B LG C&D NON 12V R8524 0RN5602F409 56K OHM 1/6 W 1.00% TA52...
  • Page 28 RESONATOR,CRYSTAL SUNNY RADIAL 20.250MHZ 3 X601 156-A02M RESONATOR,CRYSTAL KJE RADIAL 18.432MHZ 30P X701 6202VDT002B RESONATOR,CRYSTAL SX-1SMD SUNNY RADIAL 14.318MHZ ACCESSORIES 3828VA0330A MANUAL,OWNERS NP00KB MZ/T-60PZ14/2 LG EN 6710V00067M REMOTE CONTROLLER MT/MZ-60PZ10 MISCELLANEOUS 6410VBH003B POWER CORD,MP5004+V1625 6410VEH003B POWER CORD,M2511A VOLEX 6410VWH005B POWER CORD,SA16A+V1625 SABS 2800MMM...
  • Page 33 PRINTED CIRCUIT BOARD POWER(TOP) MAIN(TOP) POWER(BOTTOM) MAIN(BOTTOM)
  • Page 34 POWER MAIN(TOP) CONTROL(TOP) POWER PFC(TOP) POWER VA(TOP) POWER VS(TOP) CONTROL(BOTTOM) POWER VA(BOTTOM) POWER VS(BOTTOM) POWER PFC(BOTTOM) A/V(TOP) POWER S/W(TOP) POWER S/W(BOTTOM) A/V PACK(TOP) A/V(BOTTOM) A/V PACK(BOTTOM) POWER CONTROL(TOP) FAN CONTROL(TOP) POWER MAIN(BOTTOM) POWER CONTROL(BOTTOM) FAN CONTROL(BOTTOM)
  • Page 35 March,2002 P/NO : 3828VD0113Q Printed in Korea...
