Summary of Contents for Inter-m DSA-100D
- Page 1 Operation anual Digital SR mplifier DS -100D/DV...
- Page 2 Welcome personal welcome to you from the management and employees of Inter-M ll of the co-workers here at Inter-M are dedicated to providing excellent products with inherently good value, and we are delighted you have purchased one of our products.
-
Page 3: Table Of Contents
DIGIT L SR MPLIFIER Contents Contents Unpacking ............................2 Installation Environment............................2 Important Safety Instructions......................2 Features ............................3 Front Panel ............................4 Rear Panel ............................6 Installation of Caution ........................9 pplications ..........................10 Block Diagram ..........................11 Specifications ..........................13 How to install the rack ........................17 Service ............................17 Warranty ............................17 DS -100D/DV... -
Page 4: Unpacking
DIGIT L SR MPLIFIER Unpacking Unpacking lthough your DS -100D/DV is neither complicated nor difficult to operate, we recommend you take a few minutes to read this brief manual and familiarize yourself with the important information regarding product features, setup and operation. s with most electronic devices, we strongly recommend you to retain the original packaging. -
Page 5: Features
DIGIT L SR MPLIFIER Features Features - Compact Design The DS Series is a amplifier 100 watts x 2 of Power that is housed in half rack 1 RU compact chassis. Ideal for applications where high power stereo amplification is required such as board room and class rooms. - Professional Grade D-Class mplifier and Switch Mode Power Supply (SMPS) Class D amplifier offer improved total harmonic distortion with an increased signal to noise ratio of professional grade sound quality. -
Page 6: Front Panel
DIGIT L SR MPLIFIER Front Panel Front Panel 100D DIGITAL SR AMPLIFIER CLIP PROT POWER CH 1 CH 2 STAND BY 1. VOLUME CONTROL Turn the volume controls clockwise to increase gain and counterclockwise to decrease gain against each channel. 2. - Page 7 DIGIT L SR MPLIFIER 5. POWER LED INDIC TOR - POWER LED illuminates green when the rear power selection switch is selected as ON or the remote power contact is triggered when the rear power selection switch is selected as REMOTE. The unit turns into PD ( uto Power Down) mode, the power LED will turns off.
-
Page 8: Rear Panel
DIGIT L SR MPLIFIER Rear Panel Rear Panel BRIDGE 8Ω CH 2 CH 1 4Ω 4Ω VCA CONTROL INPUT 1 CLASS 2 WIRING REMOTE POWER POWER MODE GAIN -20dBu +4dBu REMOTE BRIDGE AC INPUT INPUT 2 SPEAKER OUT C INLET It accepts a standard IEC mains cable, provided. - Page 9 DIGIT L SR MPLIFIER Bridge connection: wire the “hot”/positive lead to the “+” terminal of CH1, the “common”/negative lead to the “-” terminal of CH2. NOTE : Before connecting speakers to the unit, be sure to disconnect the C power cable. Make certain that the total impedance is not less than the rated impedance indicated.
- Page 10 DIGIT L SR MPLIFIER 7. MODE SWITCH Mode selection switch for either CH1/CH2 stereo or BRIDGE mono mode (1) CH1/CH2 MODE Input signal of each channel will drive each channel independently. Input signal of CH1 drives output of CH1, Input signal of CH2 drives mp output of CH2.
-
Page 11: Installation Of Caution
DIGIT L SR MPLIFIER Installation of Caution installation of Caution The Cooling Vents are provided for ventilation and to ensure reliable operation of the unit and to protect it from overheating. These openings must not be blocked or covered. The unit should not be placed in a built-in installation unless proper ventilation is provided. -
Page 12: Pplications
REMOTE POWER POWER MODE GAIN -20dBu +4dBu REMOTE BRIDGE AC INPUT INPUT 2 SPEAKER OUT SPEAKER DSA-100D/DV Bridged Mono Installation Bridged Mode MIXER CD PLAYER BRIDGE 8Ω 4Ω CH 2 CH 1 4Ω VCA CONTROL INPUT 1 CLASS 2 WIRING... -
Page 13: Block Diagram
DIGIT L SR MPLIFIER Block Diagram Block Diagram DS -100D DS -100D/DV... - Page 14 DIGIT L SR MPLIFIER Block Diagram Block Diagram DS -100DV DS -100D/DV...
-
Page 15: Specifications
DIGIT L SR MPLIFIER Specifications Specifications DSA-100D DSA-100DV 20kHz LPF, 4Ω More than 100W 2 Channel Rated Output UX-0025. 8Ω More than 55W Power @ 1kHz. Bridged 8Ω More than 200W @ THD + N = 1%. Peak Power Bridged 4Ω 1kHz 10cycle... - Page 16 DIGIT L SR MPLIFIER ※ DIMENSIONS DS -100D/DV...
-
Page 17: How To Install The Rack
DIGIT L SR MPLIFIER How to install the rack How to install the rack MP & BL NK MOUNT DS -100D/DV... - Page 18 DIGIT L SR MPLIFIER MP & OPT R CK MOUNT DS -100D/DV...
-
Page 19: Service
To obtain specific warranty information and available service locations, contact Inter-M directly or the authorized Inter-M Distributor for your specific country or region. - Page 20 Inter-M, Ltd. (Korea) began operations in 1983. Since then, Inter-M has grown to become one of the largest manufacturers of professional audio and commercial sound electronics equipment in the world. Inter-M has gained worldwide recognition for its own branded products, as well as private label manufacturing of electronics sold under other names (OEM).
