To mount this Spinning® Computer to your Spinner® bike, please follow
the steps below. Please ensure that the console is pairing properly with
your cadence sensor and heart rate transmitter before mounting it to
the bike.
1. After successfully pairing with
the cadence sensor and heart
rate transmitter, place the rubber
gasket inlay behind the console,
as shown in Fig. 12.
2. Select the ring or flat bracket
(depending on Spinner bike model
you are using) and secure it to the
back of the console with the three
or four Phillips head screws (the
flat mount bracket is shown in Fig.
13).
3. Mount the console and bracket
assembly just above or on the
center loop of the handlebars
(depending on the Spinner bike
model you are using) and secure it
with the bolts (mounting above the
loop is shown in Fig. 14). This is the
ideal location for a clear view of
the console, and it will not interfere
with any of the hand positions.
S PI N N I N G ® S TU D I O CO M PUTE R OWN E R' S MANUAL
Fig. 12
Fig. 13
Fig. 14
