14
COMPUTER MOUNTING
The Spinning® Studio Computer was designed to fit all commercial
Spinner® bikes. Use the brackets listed below based on the Spinner bike
you are using. Instructions for mounting the console appear on the next
page.
The following bikes can have the Spinning Studio Computer
installed using the flat mount bracket as shown in Fig. 9.
Manufacturer
SKU
7170
7180
7190
7160
7230
7240
The following bikes can have the Spinning Studio Computer
installed using the ring mount bracket as shown in Fig. 10.
Manufacturer
SKU
7150
The following bikes can have the Spinning Studio Computer
installed using the flat mount bracket as shown in Fig. 11.
Manufacturer
SKU
7090
7000
7070
7080
NOTE: The manufacturer SKU can be found on the bike serial number sticker.
©2015 Mad Dogg Athletics, Inc. All rights reserved. Spin®, Spinner®, Spinning®, Spin Fitness® and the Spinning logo
Spinner
Bike Name
Spinner NXT
Spinner NXT
Spinner BLADE
Spinner PRO+
Spinner NXT Black Belt
Spinner BLADE Belt
Spinner
Bike Name
Spinner VELO
Spinner
Bike Name
Spinner NXT
Spinner NXT
Spinner PRO
Spinner ELITE
registered trademarks that are owned by Mad Dogg Athletics, Inc.
sr
TM
Fig. 9
c á Ö K = N=
Fig. 10
c á Ö K = O=
Fig. 11
c á Ö K = P =
® are
