C5352
Instructions
www.fisher-price.com
Please keep this instruction sheet for future reference, as it contains important information.
Requires three "AA" (LR6) alkaline batteries (not included).
Adult assembly is required.
Tool required for assembly: Phillips screwdriver (not included).
TM
Time to Cook
Barbie
Kitchen
™
™
Advertisement
Related Manuals for Fisher-Price Time to Cook Barbie Kitchen C5352
Summary of Contents for Fisher-Price Time to Cook Barbie Kitchen C5352
- Page 1 C5352 Instructions www.fisher-price.com Please keep this instruction sheet for future reference, as it contains important information. Requires three “AA” (LR6) alkaline batteries (not included). Adult assembly is required. Tool required for assembly: Phillips screwdriver (not included). Time to Cook Barbie Kitchen ™...
- Page 2 Parts CAUTION This product contains small parts ★ ▲ Upper Shelf Oven Housing in its unassembled state. Adult assembly is required. ★ Lower Shelf Oven Door Window Assembly ▲ Base Microwave Housing 2 Refrigerator Sides Plate Shelf Microwave Door Countertop Refrigerator Door Utensil Shelf Serving Tray...
- Page 3 Assembly Refrigerator Side #8 x " Screw - 2 Groove Refrigerator Shelf Tabs • Position refrigerator side with the tabs down. • Insert two #8 x " screws into the refrigerator assembly and tighten. • Slide the refrigerator shelf (ribbed side down) into the groove in the refrigerator side.
- Page 4 Assembly Refrigerator Assembly Lower Shelf ★ ★ Base • Locate the lower shelf, marked with a . Position the lower shelf with the ribbed side down. • Fit the lower shelf onto the base, as shown. • “Snap” the refrigerator assembly into the base. •...
- Page 5 Assembly Oven Housing ★ #8 x " Screw Bottom View • Turn the assembly over so the bottom is facing you. • Insert one #8 x " screw into the post in the base, ★ • “Snap” the oven housing, marked with a , into the lower as shown.
- Page 6 Assembly Upper Shelf ▲ Short Post ▲ Upper Shelf ▲ • “Snap” the short post, marked with a , into the upper shelf. Microwave Housing ▲ • Locate the upper shelf, marked with a . Position the upper shelf with the ribbed side down. •...
- Page 7 Assembly #8 x " Screw - 3 #8 x " Screw - 2 Bottom View • With the front of the assembly facing you, insert three #8 x " screws through the main assembly and into the countertop. • Tighten the screws to secure the countertop. •...
- Page 8 Assembly #8 x " Screw - 2 Window Assembly Refrigerator Door Countertop Refrigerator Handle • Fit the refrigerator handle to the refrigerator door and hold it in place. • Insert two #8 x " screws through the refrigerator door and into the refrigerator handle.
- Page 9 Assembly Microwave Door Oven Door • At an angle, fit the lower microwave door peg into the lower hole in the main assembly • Then, “snap” the upper microwave door peg into the upper hole in the main assembly Refrigerator Door •...
- Page 10 Assembly #8 x 1 " Screw - 2 • Insert a #8 x 1 " screw into each shelf. • Tighten the screws to secure the shelves. • First, “snap” the large flower oven knob into the center hole in the countertop •...
-
Page 11: Battery Installation
Label Decorations • Apply the labels as shown in the illustration. • For best results, wash your hands before applying the labels and make sure the areas to which the labels will be applied are clean and dry. Avoid repositioning a label once it has been applied. -
Page 12: Consumer Information
ASIA Mattel East Asia Ltd, Room 1106, South Tower, World Finance Centre, Harbour City, Tsimshatsui, HK, China. Fisher-Price, Inc., a subsidiary of Mattel, Inc., East Aurora, NY 14052 U.S.A. PRINTED IN MEXICO ©2004 Mattel, Inc. All Right Reserved. ® and ™ designate U.S. trademarks of Mattel, Inc.
