Functions - ADA INSTRUMENTS ROBOT-60 Operating Manual

ROBOT 60

FUNCTIONS

Addition / Subtraction
Distance measuring.
Press button (3): next measurement is added to the previous one. Press button (3): next measurement is substracted from the previous one.
The result is displayed in the second line. Previous value is displayed in the previous line.
Area
Press the button () once.The symbol is displayed.
Press button to take the second measurement (for example, width). Measured value is displayed in the second line. First measurement is displayed in
Addition / Subtraction of areas
Area measuring – see Area.
Press button (3) to enter into the Addition / Subtraction mode. Area value is displayed in the second line.
After the completion of area, press button (1), the result of substraction of areas is displayed in the main display area.
Volume
For volume measurements, press button () twice until the indicator for volume measurement appears on the display.
Press button (1) to take the second measurement (for example, width). Measured value is displayed in the second line. First measurement is displayed
7
MEASUREMENT FOUNDATION
