Sony Ericsson W205 User Manual
  1. Manuals
  2. Brands
  3. Sony Ericsson Manuals
  4. Cell Phone
  5. WALKMAN W205
  6. User manual
Sony Ericsson W205 User Manual

Sony Ericsson W205 User Manual

Hide thumbs Also See for W205:
Table of Contents

Advertisement

Quick Links

User guide
W205

Advertisement

Table of Contents
loading

Related Manuals for Sony Ericsson W205

Summary of Contents for Sony Ericsson W205

  • Page 1 User guide W205...

  • Page 2: Instruction Symbols

    Thank you for purchasing the Sony Ericsson W205 Walkman™. For additional phone content, go to www.sonyericsson.com/fun. Register now to get a suite of tools, free online storage, special offers, news and competitions at www.sonyericsson.com/myphone. For product support, go to www.sonyericsson.com/support.

  • Page 3: Preparing The Phone

    Preparing the phone SIM card The SIM (Subscriber Identity Module) card, which you get from your network operator, contains information about your subscription. Always turn off your phone and detach the charger and battery (if inserted) before you insert or remove the SIM card. You may need a PIN (Personal Identification Number) to activate the services and functions in your phone.

  • Page 4: Memory Card

    1 Press the centre of the battery cover and slide to remove it. Remove the battery, if inserted. 2 Press the right edge of the SIM card and slide to remove Do not use any sharp objects to remove the battery cover.

  • Page 5: Turning On The Phone

    1 Open the cover of the memory card slot. 2 Insert the memory card with the gold-coloured contacts facing down. To remove a memory card 1 Open the cover of the memory card slot. 2 Press the edge of the memory card to release and remove it.
  • Page 6 To charge the battery 1 Connect the charger to the phone with the power icon on the charger facing upwards. It takes approximately 3 hours to fully charge the battery. Press a key to view the screen. 2 To remove the charger, tilt the plug upwards. The phone battery is partly charged when you buy it.

  • Page 7: Phone Overview

    Phone overview Ear speaker Screen Selection keys Call key Shortcut key WALKMAN™ shortcut key Navigation key/ Walkman™ player controls Memory card slot End key, on/off key C key (Clear) Silent key...
  • Page 8 Camera Strap hole Volume key Connector for charger, handsfree and USB cable Loudspeaker...

  • Page 9: Menu Overview

    Menu overview Entertainment Camera Calls Vodafone live! Messaging Contacts Organiser & Tools WALKMAN Settings...
  • Page 10 Navigation The main menus are shown as icons. Some submenus include tabs. To access the main menu • When Menu appears on the screen, press the centre selection key to select Menu. • When Menu does not appear on the screen, press the end key and then press the centre selection key to select Menu.

  • Page 11: Entering Text

    To go back one step in the menu • Select Back. To delete an item • Scroll to the item and press Shortcuts You can use the navigation key shortcuts from standby or use the shortcut menu to get quick access to certain functions.
  • Page 12 • If the word shown is the one you want, press accept and add a space. To accept a word without adding a space, press • If the word shown is not the one you want, press repeatedly to view alternative words. To accept a word and add a space, press •...
  • Page 13 To make a call 1 Enter a phone number (with international country code and area code, if applicable). 2 Press You can call numbers from your contacts and call list. See Contacts on page 14, and Call list on page 14. To end a call •...

  • Page 14: Emergency Calls

    Call list You can view information about recent calls. To call a number from the call list 1 Press 2 Scroll to a name or a number and press To clear the call list 1 Press 2 In the All tab, select Options > Delete all. 3 To confirm, select Yes.
  • Page 15 Default contacts You can choose which contact information is shown as default. If Phone contacts is selected as default, your contacts show all the information saved in Contacts. If you select SIM contacts as default, your contacts show names and numbers saved on the SIM card. To select default contacts 1 Select Contacts >...

  • Page 16: Phone Contacts

    You can select this mode if the phone is used by more than one person. See the phonebook setup wizard for first time use. The setup wizard will appear again if being ignored. To change phonebook mode 1 Select Contacts > Options > More > Phonebook mode.
  • Page 17 2 Select Last name:, enter the last name and select OK. 3 Select First name:, enter the first name and select OK. 4 Select New number:, enter the number and select OK. 5 Select a number type. 6 Scroll between tabs and select the fields to add information.

  • Page 18: Text Messages (Sms)

    2 Scroll to a contact and select Options > Edit contact. 3 Scroll between the tabs, edit information and select Save. To copy contacts to or from the SIM card 1 Select Contacts > Options > More > Advanced. 2 Select Copy to SIM or Copy from SIM. Messaging Text messages (SMS) You must have a valid service centre number in your phone.
  • Page 19 You need the correct Internet settings in your phone to use multimedia messages. See Internet on page 28. You must set an MMS profile and the address of your message server. If no MMS profile or message server exists, you can receive all the settings automatically from your network operator or at www.sonyericsson.com/support.

  • Page 20: Transferring Music

    Walkman™ To play music 1 Press and select Options > My music. 2 Browse by artist, album, track or playlist. Scroll to a list and select Open. 3 Scroll to a title and select Play. To stop playing music • When in Play view, press Transferring music You can transfer music from your computer to your phone memory or Memory Stick Micro™...
  • Page 21 To transfer files in file transfer mode using a USB cable Do not remove the USB cable from the phone or computer during transfer, as this may corrupt the memory card and the phone memory. You cannot view the transferred files in your phone until you have removed the USB cable from the phone.
  • Page 22 To add tracks to a playlist 1 Press and select Options > My music > My Playlists. 2 Open a playlist and select Options > Add media. 3 Mark the tracks you want and select Add. You can also add all the tracks in a folder to a playlist by marking the folder and then selecting Options >...

  • Page 23: Video Player

    TrackID™ TrackID™ is a music recognition service. You can search for title, artist and album name for a track you hear playing through a loudspeaker or on the radio. You need the correct settings for Java and Internet in your phone to use this function. See Internet on page 28.
  • Page 24 Do not use your phone as a radio in places where this is prohibited. To turn on the radio 1 Connect a handsfree to the phone. 2 Select Menu > Entertainment > Radio. To search for channels automatically • When the radio is playing, press To search for channels manually •...

  • Page 25: Camera And Video Recorder

    To record from the radio 1 To set record quality, select Menu > Entertainment > Radio > Options > Settings > Record quality and select an option. 2 Select Options > Record radio to start. 3 Select Save to save the recording. 4 To access the radio recordings, select Options >...
  • Page 26 2 Select TakePic. The photo is automatically saved in JPEG format. To avoid a blurred photo, use a support or the self- timer. To change camera settings 1 Select Camera > Options. 2 Select an item and change settings. To send a saved photo 1 Select Menu >...

  • Page 27: Transferring Photos And Video Clips

    Transferring photos and video clips You can use Bluetooth™ wireless technology and the USB cable to transfer photos and video clips between your computer and phone. For more information, see Bluetooth™ wireless technology on page 27 and To transfer files in file transfer mode using a USB cable on page 21.
  • Page 28 To pair the phone with a device 1 To search for available devices, select Menu > Settings > Connectivity > Bluetooth > My devices > New device. 2 Select a device from the list. 3 Enter a passcode, if required. Make sure that the device you want to pair your phone with has the Bluetooth™...

  • Page 29: Vodafone Live! Services

    www.sonyericsson.com/support on a computer for more information. Make sure you have a phone subscription that supports data transmission in your phone. Vodafone live! Vodafone live! has everything you need, full of information, games, music, ringtones and other entertainment. It is easy to use and can be “always on”, so there is no wait for dialling up.

  • Page 30: More Features

    • Vodafone Mail – a single mailbox for all your email messages, voicemail and faxes. • Messenger – instant messaging on your mobile phone. • News – get the latest news reports and weather forecasts. • Sport – news, results, and latest scores. •...
  • Page 31 To copy or move a file in the file manager 1 Select Menu > Organiser & Tools > My Files. 2 Find a file in a folder and select Options > Manage file. 3 Select Copy or Move. To view the memory status •...

  • Page 32: Ringtones And Themes

    4 Select Save. Keep the handsfree inserted when you select radio as alarm signal. The radio signal sounds through the loudspeaker. To silence the alarm 1 When the alarm sounds, press any key. 2 To repeat the alarm, select Snooze. Torch To use the torch •...

  • Page 33: Keypad Lock

    To set a theme 1 Select Menu > Settings > Display > Themes. 2 Scroll to a theme and select Set. To use a photo as wallpaper 1 Select Menu > Organiser & Tools > My Files > Camera album. 2 Scroll to a picture and select Options >...

  • Page 34: Phone Lock

    2 Enter a new PIN and select OK. 3 To confirm, re-enter the new PIN and select OK. To use the SIM card lock 1 Select Menu > Settings > General > Security > PIN codes > SIM protection > Protection > On. 2 Enter your PIN and select OK.

  • Page 35: Troubleshooting

    4 Repeat the code and select OK. To unlock the phone 1 Select Menu > Settings > General > Security > PIN codes > Phone protection > Protection > Off. 2 Enter your phone lock code and select OK. Troubleshooting Some problems require you to call your network operator, but you can correct most problems yourself.

  • Page 36: Legal Information

    Bluetooth is a trademark or a registered trademark of Bluetooth SIG Inc. and any use of such mark by Sony Ericsson is under license. The Liquid Identity logo and TrackID are trademarks or registered trademarks of Sony Ericsson Mobile Communications AB.
  • Page 37 TrackID™ is powered by Gracenote Mobile MusicID™. Gracenote and Gracenote Mobile MusicID are trademarks or registered trademarks of Gracenote, Inc. WALKMAN, WALKMAN logo, Sony, Memory Stick Micro™ and M2™ are trademarks or registered trademarks of Sony Corporation. Ericsson is a trademark or registered trademark of Telefonaktiebolaget LM Ericsson.
  • Page 38 Any rights not expressly granted herein are reserved. All illustrations are for illustration only and may not accurately depict the actual phone.
  • Page 39 Sony Ericsson Mobile Communications AB SE-221 88 Lund, Sweden 1224-6945.1...

Table of Contents
