Page 2
Endurance, UNI/O, WiperLock and ZENA are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. SQTP is a service mark of Microchip Technology Incorporated in the U.S.A. All other trademarks mentioned herein are property of their respective companies.
Chapter 1. Product Overview 1.1 Introduction ..................... 5 1.2 What is the MCP23X17 Evaluation Board? ............ 5 1.3 What the MCP23X17 Evaluation Board Kit Includes ........5 Chapter 2. Installation and Operation 2.1 Introduction ..................... 7 2.2 Features ......................7 2.3 Getting Started ....................
• Customer Support • Document Revision History DOCUMENT LAYOUT This document describes how to use the MCP23X17 Evaluation Board as a develop- ment tool to emulate and debug firmware on a target board. The manual layout is as follows: • Chapter 1. “Product Overview” – Important information about the MCP23X17 Evaluation Board.
MCP23X17 Evaluation Board User’s Guide CONVENTIONS USED IN THIS GUIDE This manual uses the following documentation conventions: DOCUMENTATION CONVENTIONS Description Represents Examples Arial font: ® Italic characters Referenced books MPLAB IDE User’s Guide Emphasized text ...is the only compiler... Initial caps...
MCP23X17 EVALUATION BOARD USER’S GUIDE Chapter 1. Product Overview INTRODUCTION This chapter provides an overview of the MCP23X17 Evaluation Board and covers the following topics: • What is the MCP23X17 Evaluation Board? • What the MCP23X17 Evaluation Board kit includes...
• Headers for the MCP23X17 pins to allow evaluation in a user defined application. • Jumpers (not populated, but shorted by a trace on the bottom of the PCB) to isolate the MCP23X17 from the LEDs and buttons, so they can be evaluated in a custom circuit.
MCP23X17 Evaluation Board User’s Guide GETTING STARTED The MCP23X17 Evaluation Board is a fully functional, assembled and tested board for evaluation of the MCP23017 (I C interface) and MCP23S17 (SPI interface) general purpose I/O expanders. The following describes the basic setup and operation (see Figure 2-1): 1.
5. Headers - There are two headers which are connected to the MCP23X17 pins to allow off-board connections. 6. Jumpers - The jumpers are used to isolate the MCP23X17 pins so they can be connected to an off-board circuit. The jumpers are not populated, however, they are shorted by a trace on the bottom of the PCB.
Page 14
MCP23X17 Evaluation Board User’s Guide FIGURE 2-2: MAIN FIRMWARE FLOW Start Init_MCU Init_MCP Check Device Selector Switch Set Serial Mode to MCP23017 or Set Serial Mode to 23017 23S17 MCP23S17? C™ Configure Configure MCP23S17 to MCP23017 to inputs so it does...
