SERVICE MANUAL
Dual Camera
Contents
1. OUTLINE OF CIRCUIT DESCRIPTION ............................... 3
2. DISASSEMBLY ................................................................... 10
3. ELECTRICAL ADJUSTMENT ............................................. 15
5. PARTS LIST ........................................................................ 22
RoHS
•This product does not contain any hazardous substances prohibited by the RoHS
Directive.
WARNING
•You are requested to use RoHS compliant parts for maintenance or repair.
•You are requested to use lead-free solder.
(This product has been manufactured using lead-free solder. Be sure to follow the
warning given on page 2 when carrying out repair work.)
CAUTION : Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type recommended by the
manufacturer.
Discard used batteries according to the manufacturer's instructions.
NOTE : 1. Parts order must contain model number, part number, and description.
2. Substitute parts may be supplied as the service parts.
3. N. S. P. : Not available as service parts.
Design and specification are subject to change without notice.
SG41L/U, U2, EX, EX2, GX, GX2, PX, PX2, TA, TA2 (R)
FILE NO.
VPC-PD2BK
VPC-PD2R
(Product Code : 168 308 01)
(Product Code : 168 308 06)
(U.S.A.) (Canada) (Taiwan)
(General) (South America)
VPC-PD1EXBK
VPC-PD1EXR
(Product Code : 168 308 02)
(Product Code : 168 308 07)
(Europe) (U.K.) (Russia)
(Middle East) (Africa)
(General) (Korea) (Taiwan)
VPC-PD1GXBK
VPC-PD1GXR
(Product Code : 168 308 03)
(Product Code : 168 308 08)
(China) (Hong Kong)
(General) (Korea)
VPC-PD1PXBK
VPC-PD1PXR
(Product Code : 168 308 04)
(Product Code : 168 308 09)
(General) (Korea) (Taiwan)
(South America)
VPC-PD1TABK
VPC-PD1TAR
(Product Code : 168 308 05)
(Product Code : 168 308 10)
(Southeast Asia) (Australia)
(General)
REFERENCE No. SM5310833
