Summary of Contents for PRO Intellect Technology PRO 57
- Page 1 User manual Currency counters 57 / 57U / 57UM/S / 55R / 55S / 55E PRO 57 SERIES...
-
Page 2: Main Functions
• Audio confirmation of operation modes • External display Specification • Counting speed PRO 57 series ....800/1200/1500 banknote/min PRO 55 ............. 1000 banknote/min •... -
Page 3: Control Panel Functions
Appearance Figure 1 1. Control panel 2. Cover 3. Hopper 4. Stacker 5. External display port 6. Power cord 7. Paper thickness adjustment screw 8. Carrying handle 9. Power switch Control panel functions 1. Main count display The main count display depicts counting results and operational information in case of changes in the following parameters: - Counting speed - Sensitivity level of magnetic sensor... - Page 4 -continues counting and clears error messages on display 2 -clearing counting result on the main display 1 -storing changes to the counter settings 4. “ADD” button ON/OFF summation mode. Pressing the button once switches ON the summation mode (indicator lights up). Pressing the button a second time switches OFF the mode. 5.
- Page 5 Figure 2...
-
Page 6: Counterfeit Detection
result in damage to the device or injury to the operator. Contact a licensed service cen- ter in case of failure • Do not turn on the counter if the power cord is damaged • If the device was exposed to cold for an extensive period of time, it is necessary to keep it at the room temperature for no less than 4 hours Remember! The producer is in no way responsible for damage to the device or injury to the operator in the event of incorrect operation /care of the device. - Page 7 The PRO 57 series operates differently than other types of counters. When banknotes are passed through the device, they are drawn from the top of the stack, not from the bottom. Special attention should be paid to the correct stacking of the banknotes before attempting any operations.
- Page 8 30 degrees. 8.2. Change of settings of PRO 57 model 8.2.1. Changing the magnetic detection sensitivity level Hold “E$” button for 4 seconds. “En” sign will be seen on the display 2. The main dis- play will show the sensitivity level of the detector.
- Page 9 from 0 to 9 (high sensitivity level) by using digital buttons 0-9. Press “START” button to enter a new figure in the data store and exit sensitivity level change mode. Technical maintenance In order to provide the best functioning of the device, it is necessary to comply with the following simple requirements: Switch off the device, when not in use Use protective cover, when not in use...
- Page 10 System errors. Service Error Code Ursache Fehlerbeseitigung Switch on/off the power, clean the Left sensor is either blocked or failed. sensor or contact service centre. Switch on/off the power, clean the Right sensor is either blocked or failed. sensor or contact service centre. Sensor in the stacker is blocked by Remove banknotes from the stacker, banknotes or is dirty.
-
Page 11: Warranty
Warranty Manufacturer guarantees proper functioning of the device during the warranty period since the date of sale under condition of compliance with maintenance and storage procedures described in this manual. After unpacking the device please keep the package and technical description. Warranties are canceled in the event that the device was not transported in the original packaging or maintenance procedures were violated.
