• The pool pump circulates the
water through the collectors.
• The collectors absorb the heat
from the sun.
• Warm water is returned to
the pool.
ABOVEGROUND POOLS
Round Oval
Up to 24' Up to 15' x 30'
Up to 33' Up to 21' x 41'
*The S240U can be used but only a S140U is required.

LIST OF COMPONENTS

Item Description
1.5" Stainless Steel Hose Clamp
A
3.75" Rubber Hose Connector
B
PVC Elbow Connector
C
D PVC End Cap
E Teflon Tape
Item Description
A 1.5" Stainless Steel Hose Clamp
B 3.75" Rubber Hose Connector
PVC Elbow Connector
C
PVC End Cap
D
Teflon Tape
E
READ THE ENTIRE MANUAL PRIOR TO THE INSTALLATION AND USE OF THE SUNHEATER SYSTEM.
TOOLS REQUIRED
• Flathead screwdriver or 5/16" (8mm) nut driver
• Plug for return fitting
• For roof or rack mounting:
o Power drill
o 1/8" (3mm) drill bit
o #2 Phillips head drill bit
o Silicone sealant (GEII or equivalent)

HOW SUNHEATER WORKS

S140U S240U
1 Box 1 Box*
2 Boxes 1 Box
S120U
S240 U
SUNHEATER collectors have a web construction designed for
maximum heat absorption regardless of the position of the sun.
SIZING GUIDES
Dimensions
Up to 15' x 30'
Up to 16' x 36'
Up to 20' x 40'
Qty
4
1
2
(x4)
2
1
Qty
4
2
2
Note: An extra rubber hose has been supplied to connect
4
additional SunHeater systems.
1
INSTALLATION
GUIDELINES FOR POSITIONING THE COLLECTOR
• The collector(s) needs at least 6 hours of full sunlight daily.
• For ground installation, ensure the area is free of sharp objects prior
to installation.
• A 1hp pump will handle installations up to 30ft from the pool
equipment and a height of 1 story.
• The collector(s) can be installed on the ground, a roof, a rack or a fence.
Additional plumbing and hardware kits may be required (not included).
3
Collector Cross Section
INGROUND POOLS
S140U
4 Boxes
6 Boxes
8 Boxes
A
B
E
D
(x2)
S240U Kits
2 Boxes 1 SK22U
3 Boxes 1 SK22U
4 Boxes 1 SK22U
C
(x2)
