TSA model Infusion 700n Platinum Instruction Manual

Hide thumbs Also See for Infusion 700n Platinum:
Table of Contents

Advertisement

Quick Links

Download this manual
Welcome to the TSA family and
congratulations on your new purchase.
Please read this instruction manual carefully
to ensure you understand every step of the
build process. Most of all happy building
and we look forward to seeing you around
the world at many events.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Infusion 700n Platinum and is the answer not in the manual?

Questions and answers

Related Manuals for TSA model Infusion 700n Platinum

Summary of Contents for TSA model Infusion 700n Platinum

  • Page 1 Welcome to the TSA family and congratulations on your new purchase. Please read this instruction manual carefully to ensure you understand every step of the build process. Most of all happy building and we look forward to seeing you around the world at many events.
  • Page 2 Contents 1~2. Introduction Safety instructions prior to assembly 4~5. Tools required for assembly 6~31. Parts assembly Blade tracking adjustment 33~34. Operation mode Flying notes 36~42. Parts package list www.tsamodel.com...

  • Page 3: Preflight Inspection

    While in flight 1: Beginners should obtain safety and technical guidance from an experienced individual, since learning alone to operate this machine is potentially dangerous. 2: Choose a safe flying area that is free of obstruction and people. 3: Do not fly in a potentially dangerous environment. 4: Do not operate while standing on tilted ground to avoid loss of balance.
  • Page 4 After-flight safety inspection 1: Immediately inspect parts after every flight. Be sure to replace, retighten any missing or loose screws and replace any damaged parts. 2. Wipe down grease, oil, dirt and dust with a clean cloth. 3. If the unit is to be stored out of operation for a long period of time, completely drain remaining fuel from the fuel tank and carburetor.

  • Page 5: Swashplate Assembly

    Preassembly precautions 1. Before assembly, read the instruction manual thoroughly and familiarize yourself with the unit's structure and assembly procedures. Failure to assemble the unit properly may not only impair performance but also increases the risk of danger. 2. Before assembly, check description and quantity of parts. In the event of missing or defective items, contact retailer of original purchase where authorized distributor or TSA support department can be located.

  • Page 6: Tools Required For Assembly

    TOOLS REQUIRED FOR ASSEMBLY Metric ruler Cross wrench (Over 30cm) (5.5~12) Universal ball link plier Spanner (6mm/8mm/12mm/21mm) Pitch gauge (Allen head) Screw drivers (1.5mm/2mm/2.5mm/3mm/3.5mm/ 4mm/5mm)
  • Page 7 EQUIPMENT REQUIRED FOR OPERATION Receiver On/off switch Receiver battery 3 Axis gyro system 4.8 V 1800 mA PWOER Transmitter(7 channels) Servos Rudder servo Charger 90 size helicopter engine 90 size helicopter muffler Starter Remote glow Starter shaft 12V Battery plug adapter 1.5V Fuel pump Fuel filter...

  • Page 8: Main Frame Assembly

    T-001-15 T-007-05 Please apply loctite when Main Frame Assembly-1 T-003-00 locking all metal screws . T-005-01 M2-4 Bind screw Insert M2-4 retaining blind screws after installing the bearing 37.5mm Canopy rear support 37.5mm Canopy rear support 30.5mm Canopy front support M3-6 M3-6 Cap screw...
  • Page 9 T-001-14 T-022-02 Please apply loctite when Main Frame Assembly-3 T-003-00 locking all metal screws . T-005-01 37.5mm Canopy rear support M3-6 M3-6 Cap screw Cap screw 37.5mm Canopy rear support 30.5mm Canopy front support Ø5xØ10x4 Flange Brg 23mm Servo support M3-6 Cap screw 23mm Servo support Fuel tank damper...

  • Page 10: Fuel Tank Assembly

    T-003-00 Fuel Tank Assembly Please apply loctite when locking all metal screws . M3-5 Stainless steel bind screw To muffler pressure nipple Fuel tube Ø2.5xØ4x90L Hex nut Fuel tube Ø2.5xØ5.5 Fuel tube Ø2.5xØ5.5 Fuel tank grommet Fuel tank nipple 90° fuel fitting Fuel tank pickup Fuel inducer To fuel nipple...
  • Page 11 T-002-05 T-010-02 Main Frame Assembly-5 Please apply loctite when T-006-01 T-016-05 locking all metal screws . T-007-05 M4-5 SS M3-6 Bind screw Ø6xØ15x5 Brg M3-8 Cap screw Custom washer Ø10xØ19x5 Brg M3-8 M3-6 Custom Washer Cap screw Bind screw Grommet M3-6 Bind screw M3-8...
  • Page 12 RPM Sensor Assembly Please apply loctite when Two means of induced magnet RPM locking all metal screws . Sensor assembly are provided! N pole faces up N pole faces up M2-6 Cap screw S pole faces up Induced Magnet(Not S pole faces up included) Induced Magnet(Not M2-7 Cap screw...

  • Page 13: Engine Assembly

    T-010-02 Engine Assembly Please apply loctite when T-014-01 locking all metal screws . M4-8 Cap screw Clutch M2-8 Cap screw Nut ( supplied with engine ) M3-10 Cap screw Ø8.2xØ15x1 Spacer Fan hub M4-8 Cap screw M3-10 Cap screw M3-6 Bind screw M3-10 Cap screw Plastic fan...
  • Page 14 T-012-00 Landing Gear Assembly-2 Please apply loctite when T-014-01 locking all metal screws . M3-10 Cap screw M3-12 PH screw Custom washer M3-12 PH screw M3-10 Cap screw Custom washer M3-12 PH screw M3-10 Cap screw Custom washer M3-12 PH screw M3-12 Screw tightly after the fan shroud PH screw...
  • Page 15 T-011-05 Elevator Lever Assembly Please apply loctite when locking all metal screws . M2-7 Cap screw M3-6 Bind screw Elevator Lever M3-8 Bind screw M4-4 SS M3-10 Bind screw M4-4 SS M2-7 Cap screw 5.7mm Ball Elevator shaft Spacer Ø3xØ4.2x1.25 Metal elevator lever Spacer Ø3xØ4.2x2.45 5.7mm Ball...
  • Page 16 M4-4 SS T-011-05 Servo Assembly Please apply loctite when T-024-00 locking all metal screws . Anti-rotation elevator lever (ARE) Spacer Ø5xØ7x16.55 M2.6-18 PH screw M3-6 M3-6 Bind screw Bind screw M4-4 SS Spacer Ø5xØ7x16.55 Servo mounting plate M2.6-18 PH screw Servo plate Servo mounting plate Servo plate...
  • Page 17 T-020-05 Servo Support Assembly Please apply loctite when T-022-02 locking all metal screws . T-025-00 M2-8 Cap screw M2.6-12 Bind screw JR x 2 Sets Futaba x 2 Sets Both JR and Futaba servo horns are provided. Please use the M3-6 Bind screw appropriate set for your application.
  • Page 18 T-010-02 Please apply loctite when Fan and Engine Assembly T-014-01 locking all metal screws . Caution M2-6 Bind Screw Fan shroud insent is only for YS engine, it is not necessary for OS engine. M3-6 Bind Screw M4-16 Cap screw Hex insert Fan shroud (right) M2-6...

  • Page 19: Main Gear Assembly

    T-015-03 Main Gear Assembly Please apply loctite when locking all metal screws . Caution Only use long shank M4 mounting screw! Ø15xØ23x11 One way bearing 1 27mm M4-27-6 Cap screw Nylon nut Ø15xØ21x4 Brg Spacer Ø4xØ5.5x3.25 4.5mm M4-27-6 Cap screw Main shaft M2-6 Cap screw M3-8 Bind screw...

  • Page 20: Swashplate Assembly

    T-016-05 Swashplate Assembly Please apply loctite when locking all metal screws . M2-4 Bind Screw M2-4 Bind Screw 12mm Ball 12mm Ball 12mm Ball 12mm Ball Assembly Tip 12mm Ball Coupling Pivot ball(Ø12) 12mm Ball Insert pivot ball in the above illustrated 12mm Ball orientation.

  • Page 21: Blade Holder Assembly

    Pitch Arm Assembly Head Block Assembly Please apply loctite when Please apply loctite when locking all metal screws . locking all metal screws . M3-6 Bind screw M4-10 Cap screw T-016-05 T-016-05 M3-12 Bind screw 11mm Ball M3-12 Metal blade grip Bind screw Head button Teeter hub...
  • Page 22 T-011-05 Rotor Head Complete Assembly T-016-05 T-020-05 Please apply loctite when locking all metal screws . M3-18 SS M3 Nylon nut M4-5 Bind screw Spacer Ø3xØ5x3.37 M3-15 Cap screw about 75mm 50mm M4-5 Bind screw M3-15 Cap screw M4-5 about 29mm Bind screw Ball link-long Ball link-long...
  • Page 23 T-016-05 Tail Gearbox Assembly-1 Please apply loctite when locking all metal screws . M3-3 SS M3-6 Bind screw M3-5 SS Ø6xØ12x4 Brg Tail case left M3-5 SS Bevel gear Ø6xØ12x4 Brg Ø2x12 M3-6 Bind screw Locating pin Ø12xØ18x4 Brg M3-12 Cap screw M3-6 Locating pin Ø2x12 Tail cross member...
  • Page 24 T-018-00 Tail Gearbox Assembly-3 Please apply loctite when locking all metal screws . M2-8 Cap screw M3-18 Bind screw 5.7mm Ball Spacer Ø3xØ4.5x3 M2 Nut M2 Nut Ø3xØ7x3 Brg Spacer Ø3xØ5x4.5 Tail bell crank 5.7mm Ball Spacer Ø3xØ4.5x3 Spacer Ø3xØ5x4.5 M2-8 Ø3xØ7x3 Brg Ø3xØ7x3 Brg...
  • Page 25 T-016-05 Tail Gearbox Assembly-5 Please apply loctite when T-017-02 locking all metal screws . M4-4 SS M2-6 Bind Screw Spacer Ø2xØ3.2x0.9 Spacer Ø2xØ3.2x0.9 M4-4 SS Caution Tail shaft Use the M4-4SS screw to fasten the tail shaft and spindle. Ensure M4-4 SS grub screws are seated into receiver M2-6...
  • Page 26 T-016-05 Tail Boom Support Assembly Please apply loctite when T-026-01 locking all metal screws . T-027-02 T-028-18 M2.6-12-3 Bind screw M2 Nut M2.6 Nut M3 Nylon nut M2-10 Cap screw 61mm Cross member M3-5 Bind screw M3-6 Bind screw After inserting the tail boom tighten the previously installed retaining screw.
  • Page 27 T-016-05 Rotor Hea d Linkage Assembly Please apply loctite when locking all metal screws . about 86mm M2.8*65mm Ball link (23mm) about 40mm Ball link(23mm) Ball link(23mm) Caution Measure the pitch angle after assembly of the blades, and then make the adjustment . Ball link(23mm) M2.8*65L M2.8*65L...

  • Page 28: Setup Tips

    T-020-05 Please apply loctite when Linkage Rod Assembly T-021-01 locking all metal screws . T-024-00 M2-8 Cap screw about 89.5mm 60mm M2.6-5 Bind screw about 43.5mm Ball link-long(23mm) Ball link-long(23mm) 5.7mm Ball M2 Nut about 86mm 60mm about 40mm Ball link-long(23mm) Ball link-long(23mm) Screw attached Servo horn...

  • Page 29: Rudder Linkage Assembly

    T-023-01 Rudder Linkage Assembly Please apply loctite when T-024-00 locking all metal screws . T-027-02 T-028-18 M3-15 M2-7 Cap screw M2-7 Cap screw Bind screw Ø3xØ4.5x0.2 Washer 5.7mm Ball M2-8 Cap screw Ø3xØ6x2.5 Brg Tail control arm 5.7mm Ball M3-5 Bind screw Spacer Ø3xØ4.5x3 M2-7 Cap screw Ø3xØ6x2.5 Brg...
  • Page 31 Caution Receiver and Gyro Assembly The gyro sensor has a special orientation when installed. Install it according to the gyro's instruction manual . For JR Hook and l oop tape 3 Axis Gyro Double sided adhesive tape Receiver Receiver battery Hook and loop tape (hooked) Hook and loop tape (Fuzzy)
  • Page 32 Electrical Control System Wiring Diagram JR / 7CH receiver wiring Brown Aileron Orange AUX/PIT/RUD D12 /CH7/CH6 ELE/D11 AIL/CH5 Elevator Pitch Throttle Rudder 4.8 V Receiver Battery Brown AUX2 AUX1 GEAR Orange Receiver RUDD ELEV AILE THRO Satellite receiver On/off switch JR / 7CH receiver wiring/Governor Brown Aileron...

  • Page 33: Muffler Assembly

    Muffler Assembly Muffler (not included) T-005-01 Canopy Assembly Optional custom designed canopys are available. Please check website for availability. Canopy grommet While lifting the edge of the installed grommet away from the canopy apply a thin film of CA glue to both sides. Canopy grommet Canopy grommet Canopy grommet...
  • Page 34 Flybarless gyro setup-3 Axis gyros Caution Pleasa refer to the Flybarless gyro instruction manual for setting up the cyclic and tail servo along with the rotor head. This will be specific for each system. Main blade adjustment Caution Precaution during initial setup is for the safety of yourself and others, so please make sure the heli is flying at least 10m away from any person.
  • Page 35 Explanation diagram of operating mode Beginners should know the designated operating mode of 700N-3D before operating to avoid accidents Caution (Mode 1) Throttle / Pitch Ascend Descend PWOER Pushing the pitch control upward will Push the pitch control down, then the cause the unit to ascend.
  • Page 36 Explanation diagram of operating mode Beginners should know the designated operating mode of 700N-3D Caution before operating to avoid accidents (Mode 2) Throttle / Pitch Ascend Descend PWOER Pushing the pitch control upward will Push the pitch control down, then the cause the unit to ascend.

  • Page 37: Transporting The Unit

    In-flight The helicopter's main and tail rotors spin at very high speed. Make sure to follow these instructions to ensure a safe and enjoyable flight. Transporting the unit Check the unit before flight When transporting the unit to an airfield, secure it to prevent the unit from tipping over.

  • Page 38: Spare Parts

    Spare parts Order Number:TPA00120XX(Left) Order Number:TPA00121XX(Right) Order Number:TPA00500XX Order Number: Order Number:TPA00301XX Order Number:TPA00400XX TPA0276001 Gyro mount Cross member Cross member Rigidity brace * 2 Battery mount M3-6 Bind screw M3-8 PH screw M3-10 Bind screw Gyro Plate M3-8 PH screw M3-12 PH screw M4-18 Cap screw Order Number:TPA00601XX...
  • Page 39 Spare parts Order Number:TPA01601XX Order Number: Order Number:TPA01801XX Order Number:TPA01700XX Order Number:TPA01400XX TPA01501XX Fan shroud Hex insert fan shroud insert M3-6 Bind screw M2-6 Bind screw Order Number:TPA02200XX Landing skid Fuel fitting M4-4 SS Fuel tank Landing skid tube grommet Hex nut Order Number:TPA02010XX Order Number:TPA01900XX...
  • Page 40 Spare parts Order Number:TPA02901XX Order Number:TPA03001XX Order Number:TPA03401XX Starter coupling M3-6 Bind screw Clutch Clutch shaft Order Number:TPA0325001 M3-10 Cap screw Fan hub M4-5 SS Spacer Ø8.2*Ø15*1 M4-8 Cap screw Plastic fan Order Number: Order Number: Order Number: Order Number:TPA03302XX TPA03102XX TPA03201XX TPA0380001...
  • Page 41 Spare parts Order Number: Order Number:TPA04605XX Order Number:TPA04001XX Order Number:TPA04101XX TPA04201XX Metal Pivot Arm Metal elevator lever M3-18 SS M4-4 SS Elevator shaft 5.7mm Ball M4-4 SS M3-6 Bind screw Spacer(Ø3*Ø5*3.37) M3-10 Bind Spacer(Ø3*Ø4.2*2.45) M2-7 Cap screw screw Order Number: Order Number: Order Number: M3 Nylon nut...
  • Page 42 Spare parts Order Number:TPA20901XX Order Number:TPA20501XX Order Number:TPA20801XX Order Number:TPA20601XX Order Number:TPA0302001 Metal head block Teeter hub Feathering shaft guides Order Number:TPA0141001 Acetyl bearing M4-5 Bind screw Damper50°(black) Custom washer Order Number:TPA20700XX M3-15 Cap screw M3-6 Bind screw Spindle(Ø10*111.2mm) Order Number:TPA0201001 Spacer(Ø3*Ø4.5*6.2mm) Head button M6-12 Cap screw...
  • Page 43 Spare parts Order Number:TPA41200XX Order Number:TPA02300XX Order Number:TPA40900XX Tail case left Tail spacer standoff(29.5mm) Bevel gear Bevel gear M3-6 Bind Tail case right screw Order Number:TPA41301XX M3-5 Bind screw Order Number:TPA40800XX Order Number:TPA41100XX Pivot mount Locking collar M3-6 Bind screw Metal tail output shaft spacer(Ø3*Ø4.5*3mm) Locating pin...
  • Page 44 Spare parts Order Number: Order Number: Order Number: Order Number: Order Number:TPA05202XX TPA05400XX TPA05700XX TPA06500XX TPA05300XX Wire clamp Rod (M2.2*50mm) Wire clamp Lever(JR) Servo mounting plate Wire clamp 13mm Ball Rod (M2.2*60mm) Ball link Order Number: Order Number: TPA05401XX TPA0333000 Servo mounting plate Rod (M2.8*65mm) Ball link-long...

  • Page 45: Specifications

    Specifications Full length of fuselage ---------------------------- 1368mm Full width of fuselage ----------------------------- 215mm Height ------------------------------------------------ 419mm Flying weight (approx) --------------------------- 4390g Main rotor diameter ------------------------------- 1580mm Tail rotor diameter --------------------------------- 262mm Engine class ---------------------------------------- 90~120 Nitro Gear ratio -------------------------------------------- 8.0~8.4:1:4.52 Main gear ratio ------------------------------------- 15T:120T/126T Tail gear ratio ---------------------------------------...
  • Page 46 Use only TSA Model genuine parts, failure to do so could result in damage to both the aircraft and personal in the area. TSA Model takes no responsibility for the operational 2012 TSA MODEL CORPORATION use of the aircraft.
