Welcome to the TSA family and
congratulations on your new purchase.
Please read this instruction manual carefully
to ensure you understand every step of the
build process. Most of all happy building
and we look forward to seeing you around
the world at many events.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the infusion 700E and is the answer not in the manual?

Questions and answers

Related Manuals for TSA model infusion 700E

Summary of Contents for TSA model infusion 700E

  • Page 1 All manuals and user guides at all-guides.com Welcome to the TSA family and congratulations on your new purchase. Please read this instruction manual carefully to ensure you understand every step of the build process. Most of all happy building and we look forward to seeing you around the world at many events.
  • Page 2 All manuals and user guides at all-guides.com Contents 1~2. Introduction Safety instructions prior to assembly Tools required for assembly 5~26. Parts assembly Blade tracking adjustment 28~29. Operation mode Flying notes 31~36. Parts package list www.tsamodel.com...
  • Page 3 All manuals and user guides at all-guides.com While in flight 1: Beginners should obtain safety and technical guidance from an experienced individual, since learning alone to operate this machine is potentially dangerous. 2: Choose a safe flying area that is free of obstruction and people. 3: Do not fly in a potentially dangerous environment.
  • Page 4 All manuals and user guides at all-guides.com After-flight safety inspection 1: Immediately inspect parts after every flight. Be sure to replace, retighten any missing or loose screws and replace any damaged parts. 2. Wipe down grease, oil, dirt and dust with a clean cloth. 3: If not fly in long time, please take out the connector between the end of battery and the end of motor.
  • Page 5 All manuals and user guides at all-guides.com Preassembly precautions 1. Before assembly, read the instruction manual thoroughly and familiarize yourself with the unit's structure and assembly procedures. Failure to assemble the unit properly may not only impair performance but also increases the risk of danger.

  • Page 6: Tools Required For Assembly

    All manuals and user guides at all-guides.com TOOLS REQUIRED FOR ASSEMBLY Metric ruler Cross wrench (Over 30cm) (5.5~12) Universal ball link plier Spanner (6mm/8mm/12mm/21mm) Pitch gauge (Allen head) Screw drivers (1.5mm/2mm/2.5mm/3mm/3.5mm/ 4mm/5mm)

  • Page 7: Equipment Required For Assembly

    All manuals and user guides at all-guides.com Equipment required for assembly Receiver battery 3 Axis gyro system Receiver 4.8 V 1800 mA Transmitter( 7 channels ) On/off switch Servos Rudder servo Charger ＿ ＿ ＋ ＋ ＋ Battery ＿ 4500~11000W / SBH-120A Brushless ESC x1 6S LiPo 4000~5000mAh x2 500~550KV...
  • Page 8 All manuals and user guides at all-guides.com T-002-07 T-022-02 Please apply loctite when Main Frame Assembly-2 T-005-01 locking all metal screws . T-009-02 M3-6 23mm Bind screw Servo support 61mm Cross member 61mm Cross member M3-6 Bind screw M3-10 23mm Servo support Bind screw M3-6 Cap screw...
  • Page 9 All manuals and user guides at all-guides.com T-001-20 Please apply loctite when Main Frame Assembly-3 T-005-01 locking all metal screws . T-022-02 M3-6 Cap screw 37.5mm 37.5mm Canopy rear support Canopy rear support Ø5xØ10x4 Flange Brg 30.5mm Canopy front support 23mm Servo support 23mm Servo support...

  • Page 10: Landing Gear Assembly

    All manuals and user guides at all-guides.com T-012-00 Landing Gear Assembly-1 T-013-01 M3-18 Cap screw M3 Nylon nut Plastic Skid Mount M3 Nylon nut Landing skid M4-4 SS M4-4 SS Landing skid cap Ø3xØ8x0.8 Washer Ø3xØ8x0.8 Washer M3-18 Cap screw Landing skid tube Landing skid cap T-002-07...
  • Page 11 All manuals and user guides at all-guides.com T-011-11 Elevator Lever Assembly Please apply loctite when locking all metal screws . M2-7 Cap screw Anti-Rotation Elevator Lever (ARE) M3-6 Bind screw Ø3xØ6x2.5 Brg ARE pivot block Spacer M3-8 Bind screw M3-8 Ø3xØ4.2x1.25 Bind screw ARE supports...
  • Page 12 All manuals and user guides at all-guides.com T-024-01 Servo Assembly Caution Note the orientation of the servos as both the elevator and throttle servo are mounted inside the main frames M2.6-18 PH screw M2.6-26 PH screw Servo mounting plate Aileron / Pitch Servo plate M2.6-18 PH screw...
  • Page 13 All manuals and user guides at all-guides.com T-020-03 Servo Support Assembly Please apply loctite when T-022-02 locking all metal screws . T-025-00 M2-8 Cap screw M2.6-12 Bind screw JR x 2 Sets Futaba x 2 Sets M3-6 Bind screw Both JR and Futaba servo horns are provided. Please use the appropriate set for your application.

  • Page 14: Main Gear Assembly

    All manuals and user guides at all-guides.com T-007-05 Please apply loctite when Main Gear Assembly T-015-09 locking all metal screws . Caution Only use long shank M4 mounting screw! Spacer Ø15xØ23x11 One way bearing 1 Ø4xØ5.5x3.25 27mm 4.5mm M4-27-6 Magnet Cap screw Nylon nut Ø15xØ21x4 Brg...

  • Page 15: Swashplate Assembly

    All manuals and user guides at all-guides.com T-016-07 Swashplate Assembly Please apply loctite when locking all metal screws . M2-4 Bind Screw M2-4 Bind Screw 12mm Ball 12mm Ball 12mm Ball 12mm Ball Assembly Tip 12mm Ball Coupling Pivot ball(Ø12) 12mm Ball Insert pivot ball in the above illustrated 12mm Ball...
  • Page 16 All manuals and user guides at all-guides.com Pitch Arm Assembly Head Block Assembly Please apply loctite when Please apply loctite when locking all metal screws . locking all metal screws . M3-6 Bind screw M4-10 Cap screw T-016-07 T-016-07 M3-12 Bind screw 11mm Ball M3-12 Metal blade grip...
  • Page 17 All manuals and user guides at all-guides.com T-011-11 Rotor Head Complete Assembly T-016-07 T-020-03 Please apply loctite when M3-18 SS locking all metal screws . M3 Nylon nut M4-5 Bind screw Spacer Ø3xØ5x3.37 M3-15 Cap screw About 74mm M4-5 50mm Bind screw M3-15 Cap screw...
  • Page 18 All manuals and user guides at all-guides.com T-016-07 Tail Gearbox Assembly-1 Please apply loctite when locking all metal screws . M3-3 SS M3-6 Bind screw M3-5 SS Ø6xØ12x4 Brg Tail case left M3-5 SS Bevel gear Ø6xØ12x4 Brg Ø2x12 M3-6 Bind screw Locating pin Ø12xØ18x4 Brg M3-12 Cap screw...
  • Page 19 All manuals and user guides at all-guides.com T-018-00 Tail Gearbox Assembly-3 Please apply loctite when locking all metal screws . M2-8 Cap screw M3-18 Bind screw 5.7mm Ball Spacer Ø3xØ4.5x3 M2 Nut M2 Nut Ø3xØ7x3 Brg Spacer Ø3xØ5x4.5 Tail bell crank 5.7mm Ball Spacer Ø3xØ4.5x3 Spacer...
  • Page 20 All manuals and user guides at all-guides.com T-016-07 Tail Gearbox Assembly-5 Please apply loctite when T-017-02 locking all metal screws . M4-4 SS M2-6 Bind Screw Spacer Ø2xØ3.2x0.9 Spacer Ø2xØ3.2x0.9 M4-4 SS Caution Use the M4-4SS screw to fasten Tail shaft M2-6 the tail shaft and spindle.
  • Page 21 All manuals and user guides at all-guides.com T-002-07 Tail Boom Support Assembly Please apply loctite when T-016-07 locking all metal screws . T-026-01 T-027-02 T-028-22 M2.6-12-3 Bind screw M2 Nut M2.6 Nut M3 Nylon nut M2-10 Cap screw 61mm Cross member M3-5 Bind screw M3-6 Bind screw After inserting the tail boom tighten the...
  • Page 22 All manuals and user guides at all-guides.com T-016-07 Rotor Hea d Linkage Assembly Please apply loctite when locking all metal screws . About 87mm M2.8*65mm Ball link (23mm) About 42mm Ball link (23mm) Ball link (23mm) Caution Measure the pitch angle after assembly of the blades, and then make the adjustment .

  • Page 23: Rudder Linkage Assembly

    All manuals and user guides at all-guides.com T-024-01 Rudder Linkage Assembly Please apply loctite when T-027-02 locking all metal screws . T-028-22 M2-8 Cap screw M2 Nut 5.7mm Ball 5.7mm Ball M2-8 Cap screw M2 Nut Screw attached Futaba Futaba x 1 JR x 1 Both JR and Futaba servo horns are provided.
  • Page 24 All manuals and user guides at all-guides.com T-016-07 Main Blade Assembly M5-32-6 Cap screw M5 Nylon nut Caution Only use long shank M5 mounting screw! 32mm M5-32-6 Cap screw Spacer Ø5xØ22x1.5 Main blade(not included) Thickness : 12mm M5 Nylon nut Spacer Ø5xØ22x1.5...
  • Page 25 All manuals and user guides at all-guides.com T-024-01 Receiver and Gyro Assembly Hook and For JR l oop tape 3 Axis Gyro Double sided adhesive tape Receiver Receiver battery Hook and loop tape (hooked) Satellite receiver Hook and loop tape (Fuzzy) Hook and loop tape (hooked)
  • Page 26 All manuals and user guides at all-guides.com Electrical Control System Wiring Diagram JR / 7CH receiver wiring Aileron Brown Orange AUX/PIT/RUD D12 /CH7/CH6 Elevator ELE/D11 AIL/CH5 Pitch Rudder Brown AUX2 AUX1 GEAR Orange Receiver RUDD 4.8V Receiver Battery ELEV AILE THRO On/off switch Satellite...

  • Page 27: Battery Assembly

    All manuals and user guides at all-guides.com T-029-01 Battery Assembly Mounting bracket Battery mounting plate M3-8 M4-8 Bind screw Hook and loop tape TM Screw (hooked) Hook and loop tape M4-8 (Fuzzy) M3-8 TM Screw Bind Screw Battery M4-8 Bind Screw 90°...

  • Page 28: Canopy Assembly

    All manuals and user guides at all-guides.com T-005-01 Canopy Assembly Optional custom designed canopys are available. Please check website for availability. Canopy grommet Canopy Canopy grommet Canopy front support While lifting the edge of the installed grommet away from the canopy apply a thin film of CA glue to both sides.
  • Page 29 All manuals and user guides at all-guides.com Flybarless gyro setup-3 Axis gyros Caution Pleasa refer to the Flybarless gyro instruction manual for setting up the cyclic and tail servo along with the rotor head. This will be specific for each system. Main blade adjustment Caution Precaution during initial setup is for the safety of yourself and others, so...
  • Page 30 All manuals and user guides at all-guides.com...
  • Page 31 All manuals and user guides at all-guides.com...
  • Page 32 All manuals and user guides at all-guides.com In-flight The helicopter's main and tail rotors spin at very high speed. Make sure to follow these instructions to ensure a safe and enjoyable flight. Transporting the unit Check the unit before flight When transporting the unit to an airfield, secure it to prevent the unit from tipping over.

  • Page 33: Spare Parts

    All manuals and user guides at all-guides.com Spare parts Order Number:TPA00129XX (Left) Order Number:TPA00130XX (Right) Order Number:TPA00302XX Order Number:TPA05804XX Order Number:TPA06101XX Order Number:TPA0145000 M4-4 SS Grommet Spur gear Cross member (12T) Gyro plate ESC plate Order Number:TPA05806XX Order Number:TPA00400XX Cross member M3-6 Bind screw Inside nut...
  • Page 34 All manuals and user guides at all-guides.com Spare parts Order Number:TPA01601XX Order Number:TPA0043002 Order Number: Order Number: TPA0121003 Order Number:TPA01400XX TPA01501XX Plastic main gear (126T) Order Number:TPA03600XX Landing skid Plastic tail drive gear (113T) M4-4 SS Spacer Landing skid tube (Ø4xØ5.5x3.25mm) Order Number:TPA03800XX Order Number:TPA01900XX...
  • Page 35 All manuals and user guides at all-guides.com Spare parts Order Number: Order Number:TPA04101XX Order Number:TPA04611XX Order Number:TPA04002XX TPA04201XX ARE pivot arm Elevator lever M3 Nylon nut Spacer Elevator shaft (Ø3xØ5x3.37mm) M4-4 SS M4-4 SS M2-7 5.7mm Ball M3-6 Spacer M3-8 Cap screw M3-18 SS Bind screw...
  • Page 36 All manuals and user guides at all-guides.com Spare parts Order Number:TPA20901XX Order Number:TPA20501XX Order Number:TPA0302001 Order Number:TPA20801XX Order Number:TPA20601XX Metal Head block Teeter hub Feathering shaft guide Order Number:TPA0141001 Acetyl bearing M4-5 Bind screw Damper50°(black) Custom washer Order Number:TPA20700XX M3-15 Cap screw M3-6 Bind screw Spindle(Ø10*111.2mm) Order Number:TPA0201001...
  • Page 37 All manuals and user guides at all-guides.com Spare parts Order Number: Order Number:TPA41200XX Order Number:TPA42101XX Order Number: TPA40900XX TPA41301XX M3-6 Bind screw M3-18 Bind screw Tail case right Tail case left Tail spacer M3-6 Bind standoff spacer screw (29.5mm) (Ø3*Ø4.5*3mm) M3-12 Order Number: Order Number:...
  • Page 38 All manuals and user guides at all-guides.com Spare parts Order Number:TPA05500XX Order Number: Order Number: Order Number:TPA05300XX TPA05400XX TPA05701XX Servo horn (JR) Ball link Servo mounting plate 5.7mm Ball Lever(JR) Lever(JR) M2-8 13mm Ball M2 Nut Cap screw Servo mounting plate Ball link-long Order Number: Order Number:TPA05501XX...

  • Page 39: Specifications

    All manuals and user guides at all-guides.com Specifications Full length of fuselage ---------------------------- 1368mm Full width of fuselage ----------------------------- 215mm Height ------------------------------------------------ 410mm Flying weight ----------------- 5390g (12s5000mAh approx) Main rotor diameter ------------------------------- 1580mm Tail rotor diameter --------------------------------- 262mm Engine class ---------------------------------------- 4,500~11,000W/500~550KV Gear ratio -------------------------------------------- 9.0/9.69/10.5/11.45:1:4.52...
  • Page 40 Use only TSA Model genuine parts, failure to do so could result in damage to both the aircraft and personal in the area. TSA Model takes no responsibility for the operational 2012 TSA MODEL CORPORATION use of the aircraft.
