Summary of Contents for TSA model infusion 600N PRO

  • Page 3 While in flight 1: Beginners should obtain safety and technical guidance from an experienced individual, since learning alone to operate this machine is potentially dangerous. 2: Choose a safe flying area that is free of obstruction and people. 3: Do not fly in a potentially dangerous environment. 4: Do not operate while standing on tilted ground to avoid loss of balance.
  • Page 4 After-flight safety inspection 1: Immediately inspect parts after every flight. Be sure to replace, retighten any missing or loose screws and replace any damaged parts. 2. Wipe down grease, oil, dirt and dust with a clean cloth. 3. If the unit is to be stored out of operation for a long period of time, completely drain remaining fuel from the fuel tank and carburetor.

  • Page 5: Swashplate Assembly

    Preassembly precautions 1. Before assembly, read the instruction manual thoroughly and familiarize yourself with the unit's structure and assembly procedures. Failure to assemble the unit properly may not only impair performance but also increases the risk of danger. 2. Before assembly, check description and quantity of parts. In the event of missing or defective items, contact retailer of original purchase where authorized distributor or TSA support department can be located.

  • Page 6: Tools Required For Assembly

    TOOLS REQUIRED FOR ASSEMBLY Metric ruler Cross wrench (Over 30cm) (5.5~12) Universal ball link plier Spanner (6mm/8mm/12mm/21mm) Pitch gauge (Allen head) Screw drivers (1.5mm/2mm/2.5mm/3mm/3.5mm/ 4mm/5mm)
  • Page 7 EQUIPMENT REQUIRED FOR OPERATION Receiver On/off switch Receiver battery 3 Axis gyro system 4.8 V 1800 mA PWOER Transmitter(7 channels) Servos Rudder servo Charger 50 size helicopter engine 50 size helicopter muffler Starter Remote glow Starter shaft 12V Battery plug adapter 1.5V Fuel pump Fuel filter...

  • Page 8: Main Frame Assembly

    T-001-01 T-007-00 Please apply loctite when Main Frame Assembly-1 T-003-00 locking all metal screws . T-005-00 Insert M2-6 retaining blind screws after installing the bearing 37.5mm Canopy rear support M3-6 37.5mm Canopy rear support M2-6 Bind screw 30.5mm Canopy front support M3-8 Bind screw M3-8...
  • Page 9 T-001-00 T-022-00 Please apply loctite when Main Frame Assembly-3 T-003-00 locking all metal screws . T-005-00 37.5mm Canopy rear support M3-8 M3-8 PH screw PH screw Ø5xØ10x4 Flange Brg 37.5mm Canopy rear support 30.5mm Canopy front support 23mm Servo support 23mm Servo support M3-8 PH screw M3-8...

  • Page 10: Fuel Tank Assembly

    T-003-00 Fuel Tank Assembly Please apply loctite when locking all metal screws . M3-5 Stainless steel bind screw To muffler pressure nipple Fuel tube Ø2.5xØ4x90L Hex nut Fuel tube Ø2.5xØ5.5 Fuel tube Ø2.5xØ5.5 Fuel tank grommet Fuel tank nipple 90° fuel fitting Fuel tank pickup Fuel inducer To fuel nipple...
  • Page 11 T-002-00 T-010-00 Main Frame Assembly-5 Please apply loctite when T-006-00 T-016-00 locking all metal screws . T-007-00 M4-5 SS M3-6 Bind screw Ø6xØ15x5 Brg M3-8 Cap screw M3 Nylon nut Ø10xØ19x5 Brg Custom washer M3-8 Custom Washer Cap screw M3-6 Bind screw Custom Washer Grommet...
  • Page 12 RPM Sensor Assembly Please apply loctite when Two means of induced magnet RPM locking all metal screws . Sensor assembly are provided! N pole faces up M2-6 Cap screw Induced Magnet(Not S pole faces up N pole faces up included) S pole faces up M2-10 Cap screw Induced Magnet(Not...

  • Page 13: Engine Assembly

    T-010-00 Engine Assembly Please apply loctite when T-014-00 locking all metal screws . M3-6 Cap screw M2-8 Cap screw Clutch Nut ( supplied with engine ) M3-6 Cap screw Ø6xØ13x2 Spacer Fan hub M3-10 Cap screw M3-10 Cap screw M3-6 Bind screw M3-10 Cap screw Plastic fan...
  • Page 15 T-011-00 Elevator Lever Assembly Please apply loctite when locking all metal screws . M2-8 Cap screw M3-8 PH screw Elevator Lever M3-10 Bind screw M2 Nut M3-4 SS 5.7mm Ball Locating pin Ø2x11 Elevator shaft 5.7mm Ball M2 Nut M3-4 SS Spacer Ø3xØ4.2x2.45 Locating pin Ø2x11 Plastic elevator lever...
  • Page 16 T-011-00 M4-4 SS Servo Assembly Please apply loctite when T-024-00 locking all metal screws . Anti-rotation elevator lever (ARE) M2.6-18 PH screw M3-6 M3-6 Bind screw Bind screw M4-4 SS Servo mounting plate M2.6-18 PH screw Servo plate Servo mounting plate Servo plate M2.6-18 PH screw...
  • Page 17 T-020-00 Servo Support Assembly Please apply loctite when T-022-00 locking all metal screws . T-025-00 M2-8 Cap screw M2.6-12 Bind screw JR x 2 Sets Futaba x 2 Sets M3-12 Bind screw Both JR and Futaba servo horns are provided. Please use the appropriate set for your application.
  • Page 18 T-010-00 Please apply loctite when Fan and Engine Assembly T-014-00 locking all metal screws . M3-6 Bind Screw M3-15 Cap screw Hex insert Fan shroud (right) Fan shroud (left) Diagram of remote glow lead M3-15 Cap screw Not included M3-6 Bind Screw M3-6 Bind Screw...

  • Page 19: Main Gear Assembly

    T-015-00 Main Gear Assembly Please apply loctite when locking all metal screws . Caution Only use long shank M4 mounting screw! Ø16xØ22x16 One way bearing 1 M4-27-6 27mm Cap screw Nylon nut Spacer Ø16xØ23x2.6 Spacer Ø4xØ5.5x3.25 4.5mm M4-27-6 Cap screw Main shaft M3-8 Bind screw M4 Nylon nut...

  • Page 20: Swashplate Assembly

    T-016-00 Swashplate Assembly Please apply loctite when locking all metal screws . M2-4 Bind Screw M2-4 Bind Screw 12mm Ball 12mm Ball 12mm Ball 12mm Ball Assembly Tip 12mm Ball Coupling Pivot ball(Ø12) 12mm Ball Insert pivot ball in the above illustrated 12mm Ball orientation.

  • Page 21: Blade Holder Assembly

    Pitch Arm Assembly Head Block Assembly Please apply loctite when Please apply loctite when locking all metal screws . locking all metal screws . 15mm Ball M3-6 Bind screw T-016-00 T-016-00 M3-12 Bind screw M3-12 Bind screw Plastic blade grip Head button Teeter hub Acetyl bearing...
  • Page 22 T-011-00 Rotor Head Complete Assembly T-016-00 T-020-00 Please apply loctite when locking all metal screws . M3-18 SS M3 Nylon nut M4-5 Bind screw Spacer Ø3xØ5x5.25 M3-15 Cap screw about 73.5mm 50mm M4-5 Bind screw M3-15 Cap screw M4-5 about 27.5mm Bind screw Ball link-long Ball link-long...
  • Page 23 T-016-00 Tail Gearbox Assembly-1 Please apply loctite when locking all metal screws . M3-3 SS Locating pin Ø2x12 M3-5 SS Bevel gear M3-12 Cap screw M3-5 SS Locating pin Ø2x12 Tail output shaft M3 Nylon nut M3-3 SS M3 Nylon nut Bevel gear Ø3xØ6x0.5 Washer Locking collar...
  • Page 24 T-018-01 Tail Gearbox Assembly-3 Please apply loctite when locking all metal screws . M3 Nylon nut M2-8 Cap screw M3-20 Bind screw 5.7mm Ball M2 Nut Spacer Ø3xØ4.5x3 M2 Nut Ø3xØ7x3 Brg M3 Nylon nut Spacer Ø3xØ5x4.5 5.7mm Ball Tail bell crank Spacer Ø3xØ4.5x3 Spacer Ø3xØ5x4.5 M2-8...
  • Page 25 T-016-00 Tail Gearbox Assembly-5 Please apply loctite when T-017-00 locking all metal screws . M4-4 SS M2-8 Cap screw M2 Nut Ø2xØ4.2x0.5 Washer M2 Nut M4-4 SS Caution Tail shaft Use the M4-4SS screw to fasten the tail shaft and spindle. Ensure M4-4 SS M2 Nut grub screws are seated into receiver...
  • Page 26 T-016-00 Tail Boom Support Assembly Please apply loctite when T-026-03 locking all metal screws . T-027-00 T-028-00 M3-25 Bind screw M2 Nut M2.6 Nut M3 Nylon nut M2.6-12-3 Bind screw 61mm Cross member M2-10 Cap screw M4-16 Bind screw M3-5 Bind screw After inserting the tail boom tighten the previously installed retaining screw.
  • Page 27 T-016-00 Rotor Hea d Linkage Assembly Please apply loctite when locking all metal screws . about 81.6mm M2.8*55mm Ball link (23mm) about 35.6mm Ball link(23mm) Ball link(23mm) Caution Measure the pitch angle after assembly of the blades, and then make the adjustment . Ball link(23mm) M2.8*55L M2.8*55L...
  • Page 28 T-020-00 Please apply loctite when Linkage Rod Assembly T-021-00 locking all metal screws . T-024-00 about 78mm M2-8 Cap screw 50mm M2.6-5 Bind screw about 32mm Ball link-long(23mm) Ball link-long(23mm) 5.7mm Ball about 68mm M2 Nut 45mm about 22mm Ball link-long(23mm) Ball link-long(23mm) Screw attached Servo horn...

  • Page 29: Rudder Linkage Assembly

    T-023-00 Rudder Linkage Assembly Please apply loctite when T-024-00 locking all metal screws . T-027-00 T-028-00 M3-18 Bind screw M2-8 M2-8 Cap screw Cap screw Ø3xØ4.5x0.2 Washer 5.7mm Ball Ø3xØ6x2.5 Brg M3-8 Bind screw M2 Nut Tail control arm Spacer Ø3xØ4.5x3 M3-18 Bind screw Ø3xØ6x2.5 Brg SpaceØ3xØ4.2x2.45...
  • Page 30 T-016-00 Main Blade Assembly M4-32-8 Cap screw M4 Nylon nut Caution Only use long shank M4 mounting screw! 32mm M4-32-8 Cap screw Spacer Ø4xØ19.8x1.5 Main blade(not included) Thickness : 12mm M4 Nylon nut Spacer Ø4xØ19.8x1.5...
  • Page 31 Caution Receiver and Gyro Assembly The gyro sensor has a special orientation when installed. Install it according to the gyro's instruction manual . For JR Hook and l oop tape 3 Axis Gyro Double sided Receiver adhesive tape Receiver battery Hook and loop tape (Fuzzy) Hook and loop tape (hooked)
  • Page 32 Electrical Control System Wiring Diagram JR / 7CH receiver wiring Brown Aileron Orange AUX/PIT/RUD D12 /CH7/CH6 ELE/D11 AIL/CH5 Elevator Pitch Throttle Rudder 4.8 V Receiver Battery Brown AUX2 AUX1 GEAR Orange Receiver RUDD ELEV AILE THRO Satellite receiver On/off switch JR / 7CH receiver wiring/Governor Brown Aileron...

  • Page 33: Muffler Assembly

    Muffler Assembly Muffler (not included) T-005-00 Canopy Assembly Optional custom designed canopys are available. Please check website for availability. Canopy grommet While lifting the edge of the installed grommet away from the canopy apply a thin film of CA glue to both sides. Canopy grommet Canopy grommet Canopy grommet...
  • Page 37 In-flight The helicopter's main and tail rotors spin at very high speed. Make sure to follow these instructions to ensure a safe and enjoyable flight. Transporting the unit Check the unit before flight When transporting the unit to an airfield, secure it to prevent the unit from tipping over.

  • Page 38: Spare Parts

    Spare parts Order Number:TPA00100XX(Left) Order Number:TPA00101XX(Right) Order Number:TPA00402XX Order Number:TPA0276000 Order Number:TPA00304XX Order Number:TPA00400XX Cross member Gyro Plate Cross member M3-6 Bind screw Rigidity brace Order Number:TPA0145000 M4-16 Bind screw M3-8 PH screw Grommet Order Number:TPA00500XX Order Number:TPA00600XX Rigidity brace Clutch bearing holder Gyro mount...
  • Page 42 Spare parts Order Number:TPA20900XX Order Number:TPA20500XX Order Number:TPA0302000 Order Number:TPA20800XX Order Number:TPA20600XX Metal Head block Teeter hub Feathering shaft guide Order Number:TPA0140002 Acetyl bearing M4-5 Bind screw Damper60°(Red) Custom washer Order Number:TPA20700XX M3-15 Cap screw Spindle(Ø8*89.9mm) M3-6 Bind screw Order Number:TPA0201000 Spacer(Ø3*Ø4.5*6.2mm) Head button M5-12...
