Norcold N300 Service Manual
2.7 cu. ft.
Hide thumbs
Also See for N300:
- Installation and owner's manual (21 pages) ,
- Service manual (16 pages) ,
- Parts list (11 pages)
Related Manuals for Norcold N300
Summary of Contents for Norcold N300
- Page 1 Service Manual For model N300 - a 2.7 cu. ft., 2-way refrigerator. For model N300.3 - a 2.7 cu. ft., 3-way refrigerator. NORCOLD, Inc. P.O. Box 4248 Sidney, OH 45365-4248 Part No. 619127A (6-98)
-
Page 2: Table Of Contents
1-800-444-7210. - Do not bypass or change the refrigerator’s electrical components or features. Only use genuine Norcold replacement parts on the refrigera- tor. Generic parts do not meet Norcold’s specifications for reliability, performance, and safety and will void the Norcold Limited Warranty. -
Page 3: Specifications
3 Amp Type 3AG (1 1/4” x 1/4”) gloves. Norcold P/N: 61654622 - Make sure all fasteners and connections are tight. DC Circuit: 20 Amp Type 3AG (1 1/4” x 1/4”) Norcold P/N: 61440522 Service Manual N300 Models - 3... -
Page 4: Ventilation Requirements
If this air flow is blocked or decreased, the manual shutoff valve of the refrigerator before the test. refrigerator may not cool correctly. Each NORCOLD model is certified by AGA and CGA for correct ventilation. 4 - Service Manual N300 Models... -
Page 5: Electrical Components
NOTE: This in-line fuse is necessary for added safety, even though the refrigerator has a DC fuse in the control assembly. Service Manual N300 Models - 5... -
Page 6: Ignition And Start Up
- Turn the thermostat to the 1 position. - Remove the flare nut from the orifice assembly [1] (See Art00956). - Remove the orifice assembly from the burner [2] 6 - Service Manual N300 Models... -
Page 7: Diagnosing Cooling Problems
14 ..........DC heater (3-way models) touch any tubes of the cooling unit. 15 ........... -12 VDC Com(3-way models) 17 ..............Selector switch - Within 20 minutes of starting the refrigerator, touch the outside of the insulation sleeve. Service Manual N300 Models - 7... -
Page 8: Troubleshooting Charts
8 - Service Manual N300 Models... -
Page 9: Refrigerator Will Not Operate On Dc (3-Way Models)
Service Manual N300 Models - 9... -
Page 10: Burner Ignites But Does Not Maintain Flame
10 - Service Manual N300 Models... -
Page 11: Part Replacement
OFF ( ) position. 3. Remove the two blue wires that connect the AC heater to the terminal block. 4. Using a utility knife, vertically cut through the insulation that surrounds the flue tube. Service Manual N300 Models - 11... -
Page 12: Thermocouple
8. To install the refrigerator, do steps 1-7 in reverse. 10. Open the valve at the main propane gas tank(s). 9. Examine all the gas connections for leaks. 11. Examine all the gas connections for leaks. 12 - Service Manual N300 Models... - Page 13 Service Manual N300 Models - 13...
- Page 14 14 - S ervice Manual N300 Models...
