4 Integrated DriveCore TM Technology
Class D and Class I amplifiers are notable for extraordinarily high
efficiency and being well suited for driving difficult reactive loads such
as subwoofers.
Crown engineers developed DriveCore™ Technology – a proprietary
hybrid analog-digital integrated circuit (IC) developed with Texas
Instruments that drives the "front end" of the Class D or Class I output
stage. Over 60 years of Crown's design knowledge and experience
went into the development of this technology resulting in truly
remarkable benefits.
DriveCore™ Technology provides an extremely wide-tolerance with
regards to sagging or "dirty" AC line conditions providing consistent
Figure 4.1 I-Tech HD 2 Channel Front End Board
performance without affecting audio quality. This means that your
performance will not be compromised by fluctuating generator power
or overloading by lighting rigs, backline gear, etc.
07CYDJKL
In addition, DriveCore™ Technology's patented feedback and PWM
SN61112B5
modulation circuits enable fast recovery on peak transients, accurate
Figure 4.2 Ruby Chip (Actual Size)
reproduction of low-level detail, and precise tracking of low-
frequencies at high power levels for maximum subwoofer output.
page 12
I-Tech HD DriveCore Series Power Amplifiers I-Tech HD DriveCore Series Power Amplifiers

5 Powered by Crown

This I-Tech HD Series amplifier is compatible with the Powered by Crown
app. For more information visit:
http://www.crownaudio.com/mobileapplications/index.htm
Operation Manual Operation Manual
iPad iPad
Available right now, download instantly from the Apple App Store.
The New System Control App from Crown,
Available at the Apple App Store.
+ Instantly connect to your Crown networked amps; just plug
your amps into any wireless router, watch the amps
auto-populate, and you have full control of everything
+ Watch over your entire rig using your IPhone or IPad, anywhere
in the venue - intuitive control panels allow you to monitor input
levels, output levels, thermal conditions - anything you need
+ Need to limit control or see something special? Choose any
controls you want using System Architect custom panels; then
easily import them using ITunes
+ Use it with CTs, I-Tech, I-Tech HD, and Macro Tech I series (CTs
requires network PIP)
Input LOW MID HIGH Signal Generator
Levels/Mut Level Levels/Mute s/ e e
Visit crownaudio.com for more information
