Service Manual
MODEL:
DC-A84D1D
DC-A84D1P
DC-A84D1S
DC-A83D1D
DC-A83D1P
DC-A83D1S
DC-A24D1D
DC-A24D1S
DC-A23D1D
DC-A23D1S
DVH-56J
Caution :
In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the latest
parts information,please refer to PPL(Parts Price List) in Service
Information Center (http://svc.dwe.co.kr).
DAEWOO ELECTRONICS Corp.
http : //svc.dwe.co.kr
S/M No. : VTBA84PET0
July. 2003
