WRC-1
Wireless Remote Control Instruction Manual
As of: June 2000
A
,
-
.
LL ARTWORK
PICTURES AND TEXTS ARE COVERED BY OUR COPY
RIGHT
T
(
.
.
CD-ROM
I
-
)
.
HEY MUST NOT BE COPIED FOR REPRODUCTION
E
G
ON
DISKS OR
NTERNET
SITES
OR USED IN THEIR ENTIRE FORM OR IN EXCERPTS WITHOUT OUR PREVIOUS WRITTEN AGREEMENT
I
PDF-
I
-
,
.
F YOU ARE DOWNLOADING
FILES FROM OUR
NTERNET HOME
PAGE FOR YOUR PERSONAL USE
MAKE SURE TO CHECK FOR UPDATED VERSIONS
W
,
.
E CANNOT TAKE ANY LIABILITY WHATSOEVER FOR DOWNLOADED FILES
AS TECHNICAL DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE

Advertisement

Table of Contents
loading

Related Manuals for ARRI WRC-1

Summary of Contents for ARRI WRC-1

  • Page 1 WRC-1 Wireless Remote Control Instruction Manual As of: June 2000 LL ARTWORK PICTURES AND TEXTS ARE COVERED BY OUR COPY RIGHT CD-ROM HEY MUST NOT BE COPIED FOR REPRODUCTION DISKS OR NTERNET SITES OR USED IN THEIR ENTIRE FORM OR IN EXCERPTS WITHOUT OUR PREVIOUS WRITTEN AGREEMENT...
  • Page 2 IRIS sliding switch WRC/CAM sliding switch READY-LED SEL button MODE button OPEN/PHASE button rotary switch handwheel RUN-LED RELEASE button radio channel ON button SET button RF-LED RAMP button CAL-LED CAL button COMPENSATION rotary switch READY-LED BAT-LED RUN-LED RUN button...

  • Page 3: Table Of Contents

    3.2.2.2 Overview of the settings available with the COMPENSATION rotary switch ... 15 4. Setup ... 17 WRC-1 in wireless mode ... 17 Required system components ... 17 4.1.1 Mounting the WRC-1 on the Wireless Main Unit (WMU-1) ... 18 4.1.2...
  • Page 4 5. Operation ... 25 Operating modes ... 25 5.1.1 CAM mode ... 25 5.1.2 WRC mode ... 26 Switching on ... 27 Important instructions ... 28 Using the menus ... 31 5.4.1 Main menu ... 31 5.4.2 Submenus ... 33 5.4.2.1 Limit values ...
  • Page 5 Controlling the mirror shutter angle (master value: Shutter angle) ... 77 5.6.1 Shutter angle / compensation off ... 78 5.6.2 Shutter angle / compensation iris ... 80 5.6.3 Shutter angle / compensation user ... 84 5.6.4 Ramp shutter angle / compensation off ... 88 5.6.5 Ramp shutter angle / compensation iris ...
  • Page 6 7.2.1 CAM mode ... 172 7.2.2 WRC mode ... 172 IRIS ON/OFF ... 172 Operation ... 173 7.3.1 Iris control ... 174 7.3.2 Entering values ... 177 8. Glossary ... 183 9. ARRI Service ... 185 10. Index ... 187...

  • Page 7: Safety Instructions

    2. Safety Instructions • The WRC-1 has been thoroughly tested for quality of workmanship and operating functions before leaving the factory. • To ensure optimal performance, it is essential that you acquaint yourself with this instruction manual and that you follow the operating instructions described.

  • Page 9: Introduction

    The range of functions offered by the WRC-1 is automatically adapted to the limits of the camera and the lens control motor to which it is connected. The large handwheel...

  • Page 10: Some Typical Applications

    Altering the depth of field Intentional adjustment of the depth of field at a constant camera speed is another option available with the WRC-1. In this case the mirror shutter angle is adjusted, using the WRC-1, and the resulting difference in exposure is...

  • Page 11: Speed Ramps

    The WRC-1 allows the camera speed to be changed while simultaneously retaining a constant exposure. Several different compensation methods can be selected.

  • Page 12: Functions

    A RUN LED is also integrated. In the CAM mode, the OPEN button on the WRC-1 serves as the PHASE button on the camera. In CAM mode the WRC-1 serves purely as a camera remote control unit, without any wider programming options.

  • Page 13: Wrc Mode

    Example: the WRC rotary switch is set to fps, the COMPEN- SATION rotary switch is set to Iris. The camera speed is adjusted with the handwheel, while the WRC-1 automatically keeps the film exposure constant, adjusting the iris of the lens.

  • Page 14: Overview Of The Settings Available With The Wrc Rotary Switch

    3.2.2.1 Overview of the settings available with the WRC rotary switch • fps In the ‘FPS’ mode the camera speed can be adjusted by turning the handwheel. The end-stops of the handwheel can be defined by the user within the limits of the attached camera model.

  • Page 15: Overview Of The Settings Available With The Compensation Rotary Switch

    3.2.2.2 Overview of the settings available with the COMPENSATION rotary switch • off In the ‘OFF’ position there is no exposure compensation for the programmed ramp functions or the handwheel adjustments. (no slave values) • Iris In the ‘IRIS’ position the handwheel adjustments or the pro- grammed ramp functions are compensated for by automati- cally adjusting the iris of the lens for a constant exposure.
  • Page 16 BAT RDY WMU-1 + WRC-1 CLM-2 UC-C1 LENS CONTROL SYSTEM UC-R1 UMC-1 + URM-1 535, 535B, 435, 16 SR3...

  • Page 17: Setup

    4. Setup 4.1 WRC-1 in wireless mode In order to be able to use the WRC-1 in wireless mode, it must be mounted on a Wireless Main Unit (WMU-1). The Wireless Main Unit supplies the WRC-1 with power and establishes the radio link with the camera.

  • Page 18: Mounting The Wrc-1 On The Wireless Main Unit (Wmu-1)

    Swing out the unit and then remove it by pulling it upwards. • With the wide black pin photo insert the WRC-1 into the free space on the Wireless Main Unit WMU-1. Then press the WRC-1 onto the WMU-1 until the module audibly snaps into position. Note: The WRC-1 cannot be mounted on a WMU-1 together with other modules.

  • Page 19: Attaching The Umc-1 And Urm-1 To The Camera

    4.1.2 Attaching the UMC-1 and URM-1 to the camera For wireless operation the UMC-1 must be equipped with an URM-1. • Screw the antenna into the threaded photo bushing on the URM-1. • Unscrew the two allen screws photo cover of the UMC-1 and then remove the cover. from the allen screw antenna...
  • Page 20 plug • Place the URM-1 onto the UMC-1, align both plugs with each other and do not tilt them while photo attaching. • Screw the URM-1 tight to the UMC-1 with the two allen screws. • Attach the Universal Motor Controller UMC-1 with the URM-1 to the camera using the dovetail adapter with a 3/8"...
  • Page 21 • Connect the CCU socket on the camera with the CCU socket on the UMC-1 using the UC-R1 cable. • Select the same radio channel on the UMC-1 as is set on the WMU-1 (see LCS Instruction Manual, photo chapter 5.1.2.1). If several lenses are to be remotely controlled independently of each other, the radio channels 0 and 5, 1 and 6, and 3 and 7 can not be used simultaneously.

  • Page 22: Setup With Iris Control

    Setup with Iris control tube A CLM-2 motor must be mounted if the iris of the lens is to be controlled by the WRC-1. Mounting the CLM-2 motor with/without console Console order number: K2.52035.0 • Flip up the locking lever the ballcatch disappears completely in the bracket.
  • Page 23 • Connect the CLM-2 motor to the iris socket of the UMC-1. Note: All iris-related functions of the WRC-1 are not available if the CLM-2 motor is not connected. The WRC-1 then displays the ‘NO IRIS’ warning.

  • Page 24: In Cable Mode

    • If a control unit is already attached remove it by pressing the release button. Swing out the unit and then remove it by pulling it upwards. • Insert the WRC-1 into the available free space on the WHA-1 (Wireless Handgrip Attachment) with the wide black pin pointing forward press the WRC-1 onto the WHA-1 until the module audibly snaps into position.

  • Page 25: Operation

    The display of the WRC-1 shows the same information as the camera display in this operating mode. Note: If the WRC-1 is only to be used in this operating mode, it is advisable to set the WRC/CAM sliding switch to CAM before the WRC-1 is switched on.

  • Page 26: Wrc Mode

    WRC/CAM sliding switch READY-LED OPEN/PHASE- button 5.1.2 WRC mode In this mode the WRC-1 offers convenient and quick access to camera functions and additional programming options. • Set the sliding switch on the camera from NORM to PS/CCU photo. The display of the WRC-1 flashes with the warning ‘not PSCCU’...

  • Page 27: Switching On

    5.2 Switching on The WRC-1 does not have its own ON/OFF switch. In wireless mode it is switched on by pressing the ON button on the Wireless Main Unit (WMU-1) mode it is supplied with power via the cable from the camera as soon as this is switched on.

  • Page 28: Important Instructions

    WRC-1. The WRC-1 is an active unit and its settings have priority over those of the camera. The camera retains the last settings sent by the WRC-1 in its memory.
  • Page 29 PS/CCU to NORM. The shutter angle is not automatically reset to 180 ! • All programs set using the WRC-1 are only stored in the WRC-1 itself, and not in the camera. The RAMP function of the WRC-1 therefore is not identical with the camera’s own program function.
  • Page 30 • If exposure compensation is not possible with the set options – e.g. adjusting the iris cannot be compensated for at the same time by the iris – the WRC-1 displays the message ‘NO FUNC’ (no function) in the main menu.

  • Page 31: Using The Menus

    The submenus are only used to define all relevant values. READY IRIS black bar PROG symbol PROG OPEN MODE SEL/ SET/ RAMP PHASE ramp Iris Iris ramp Iris ramp Iris Iris user WRC-1 handwheel fps, ,Iris...
  • Page 32 If exposure compensation is not possible with the set options – e.g. adjusting the iris cannot be compensated at the same time by the iris – the WRC-1 displays the message ‘NO FUNC’ (no function) in the main menu.

  • Page 33: Submenus

    WRC-1. If a ramp function has been selected, the duration of the ramp must also be entered.
  • Page 34 PHASE ramp Iris ramp ramp Iris WRC-1 fps, • Press the MODE button to change from the main menu to a submenu. Each further press of the MODE button takes the user to the next submenu, until the main menu mode reappears.
  • Page 36 Iris Iris comp. off comp. < ) Iris ramp Iris comp. user comp. off PROG PROG PROG PROG ramp Iris ramp Iris comp. < ) comp. user PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG...

  • Page 37: Controlling The Iris (Master Value: Iris)

    5.5 Controlling the iris (master value: Iris) If the aperture of the lens (iris) is to be controlled by the WRC-1, a lens motor CLM-2 must be mounted on the camera and connected to the UMC-1/URM-1. Note: The iris can only be adjusted using CLM-2 motors.

  • Page 38: Assigning The T-Stops

    – ‘IRIS TBL’ – when the WRC-1 is switched on with the IRIS sliding switch set to the position ‘ON’. Press the MODE button once to enter the input mode.
  • Page 39 SEL button. For the Zeiss Ultra Primes, the Variable Primes, the High- speed set, and the Standard set iris tables are already programmed in the WRC-1. For other lenses iris tables can be stored. 10 memory areas are available.

  • Page 40: Loading Iris Tables For Zeiss Ultra Primes, Variable Primes, High-Speed, Standard Or User-Defined Lenses ('Tbl Load')

    The pre-defined iris tables are loaded as follows: • If ‘IRIS TBL’ flashes on the display when the WRC-1 is switched on, the MODE button must be pressed once to enter the ‘TBL LOAD’ mode.
  • Page 41 Display: Lens set: ARRI Zeiss Ultra Primes VAr P ARRI Zeiss Variable Primes HS 35 ARRI Zeiss High-speed lenses for 35mm film Std35 ARRI Zeiss Standard lenses for 35mm film HS 16 ARRI Zeiss High-speed lenses for 16mm film User lens previously defined by the user •...
  • Page 42 • ‘ADJ’ now flashes in the first line of the display. A T-stop value is shown in the second line. • Adjust the iris ring to the displayed value using the handwheel. • The T-stop is assigned by pressing the SET button. This is indicated in the first line with an ‘I’...
  • Page 43 • Press the MODE button to go back to the table menu (TBL LOAD, TBL DEL, TBL EDIT, TBL STORE). • To go back to the main menu press of the MODE button again.

  • Page 44: Programming An Iris Table For Other Lenses ('Tbl Edit')

    5.5.1.2 Programming an iris table for other lenses (‘TBL EDIT’) • If ‘IRIS TBL’ flashes on the display when the WRC-1 is switched on, the MODE button must be pressed once to enter the ‘TBL LOAD’ mode. If a lens has already been selected and the T-stops...
  • Page 45 • Press the CAL button on the WMU-1 to start the calibration process before entering any values. • Turn the handwheel until ‘TBL EDIT’ is displayed. Press the SEL button to go to the input mode. • Turn the handwheel to the left until the first T-stop of the iris ring of the lens being used is shown in the second line of the display.
  • Page 46 Note: If the T-stop scale of the lens being used is linear, it is sufficient to enter just two T-stops, which must be at least four T-stops apart, in order to define the iris table. If the T-stop scale is not linear, all the T-stops must be assigned individually.

  • Page 47: Storing An Iris Table ('Tbl Store')

    5.5.1.3 Storing an iris table (‘TBL STORE’) After assigning the T-stops the resulting iris table can be stored for later use. • Press the MODE button in the submenu for assigning the T-stops to go back to the table menu (TBL LOAD, TBL DEL, TBL EDIT, TBL STORE).

  • Page 48: Loading A User-Defined Iris Table ('Tbl Load')

    5.5.1.4 Loading a user-defined iris table (‘TBL LOAD’) • If ‘IRIS TBL’ flashes on the display when the WRC-1 is switched on, the MODE button must be pressed once to enter the ‘TBL LOAD’ mode. If a lens has already been selected and the T-stops have...
  • Page 49 The WRC-1 is not able to check whether the selected user-defined iris table is actually compatible with the lens being used. An error message can only be displayed if the iris motor reaches the end-stops of the lens during cali- bration, and these had been positioned else- where while the lens was being programmed.
  • Page 50 • If the lens has been successfully calibrated, ‘ADJ’ flashes in the first line of the display. A T-stop value is shown in the second line. • Adjust the iris ring of the lens to the displayed value using the handwheel. •...

  • Page 51: Important Instructions For Programming The Iris Of The Lens

    Note: If a previously programmed iris table is re-edited, the corresponding table must first be loaded from its memory area as described above. The handwheel must then be turned in the table menu (TBL LOAD, TBL DEL, TBL EDIT, TBL STORE) until ‘EDIT’...

  • Page 52: Iris / Compensation Off

    ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 53 The OPEN button is without function while the camera is running. By pressing the SET button the currently set shutter angle (if controlled by the WRC-1) can be shown in the first display line. The currently set camera speed is shown in the second display line.
  • Page 54 • Press the MODE button to enter the next submenu. The Iris table menu has already been described under 5.5.1. comp. < ) • Press the MODE button to go back to the main menu.

  • Page 55: Iris / Compensation Shutter Angle

    ‘NO’ in the first display line indicate that the selected function is currently not available (examples: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected. The connected camera does not have an electronically adjustable mirror shutter);...
  • Page 56 With most lenses, the T-stops before the end-stops are not exact due to the tolerances involved. In order to avoid incorrect exposure, the adjusted iris range should not contain these values. With the iris wide open a lens-related reduction in brightness towards the edge of the image may occur, looking like an incorrect exposure.
  • Page 57 WRC-1. • Press the SEL button for longer than 2 seconds. Depending on the definable limit value, the first digits flash in the first or second display line.

  • Page 58: Iris / Compensation User

    Iris comp. user 5.5.4 Iris / compensation user Using the handwheel, the iris can be manually adjusted within the user-defined end-stops, simultaneously together with the values for the shutter angle and the camera speed. If appropriate values are selected, either the exposure can be kept at a constant level, or an adjustment process can be defined to change the exposure as required (e.g.
  • Page 59 The main menu shows the symbol ’ ’ in the first display line for adjusting the shutter angle (if controlled by the WRC-1) and the currently adjusted T-stop (if controlled by the WRC-1). By pressing the SET button the currently adjusted mirror shutter angle can be shown in the first line of the display.
  • Page 60 The OPEN button is without function while the camera is running. By pressing the SET button the currently adjusted shutter angle (if controlled by the WRC-1) can be shown in the first display line. With most lenses, the T-stops before the end-stops are not exact due to the tolerances involved.
  • Page 61 • Press the MODE button to go to the next submenu. To define the values for the minimum and maximum camera speed, use the SEL and SET buttons and the handwheel. The first display line shows the value for the left end-stop, the second line shows the value for the right end-stop.

  • Page 62: Ramp Iris / Compensation Off

    ramp Iris comp. off PROG PROG PROG PROG 5.5.5 Ramp iris / compensation off The iris of the lens is continuously adjusted within the pre- defined limit values over a pre-defined period of time after pressing the RAMP button (ramp, definition see Glossary). Differences in exposure are not automatically compensated for.
  • Page 63 The OPEN button is without function while the camera is running. By pressing the SET button the currently set shutter angle (if controlled by the WRC-1) can be displayed in the first display line, the currently set camera speed is shown in the second display line.
  • Page 64 • Press the MODE button to go to the next submenu. To define the fixed values for the mirror shutter angle (if controlled by the WRC-1) and the camera speed, use the SEL and SET buttons and the handwheel, as described above.
  • Page 65 • Press the MODE button to go to the next submenu. The table menu has already been described under 5.5.1. • Press the MODE button to go back to the main menu.

  • Page 66: Ramp Iris / Compensation Shutter Angle

    RAMP button (ramp, definition see Glossary). The mirror shutter angle is automatically adjusted by the WRC-1 within the pre-defined limit values, to compensate the exposure. The visible depth of field can be altered with this function.
  • Page 67 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 68 The limit values for the shutter angle can be defined. The shutter angle is automatically adjusted by the WRC-1 to compensate the exposure, while the iris is being adjusted. One of the two limit values (minimum or maximum shutter angle, depending on the adjustment direction of the iris) can be defined;...
  • Page 69 • Press the MODE button to go to the next submenu. The fixed value for the camera speed is defined using the SEL and SET buttons and the handwheel. • Press the MODE button to go to the next submenu. To enter the the ramp duration, use the SEL and SET buttons and the handwheel, as described above.

  • Page 70: Ramp Iris / Compensation User

    5.5.7 Ramp iris / compensation user The iris of the lens is continuously adjusted, together with the shutter angle (if controlled by the WRC-1) and the camera speed, within the freely definable limits over a pre-defined period of time after pressing the RAMP button in the camera run.
  • Page 71 (if controlled by the WRC-1) and the currently adjusted T-stop. The currently ad- justed mirror shutter angle (if controlled by the WRC-1) can be shown in the first display line by pressing the SET button.
  • Page 72 The handwheel is without function in the main menu. Press the RAMP button when the camera is running to start the ramp. The camera can be started, by pressing the RUN button on the WMU-1. The ramp can be reversed, by pressing the RAMP button again: the ramp then reverses its direction until it reaches the start value again.
  • Page 73 • Press the MODE button to go to the next submenu. To define the values for the minimum and maximum shutter angle (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above. The first display line shows the start value of the shutter angle, and the second line the value at the end of the ramp.
  • Page 74 • Press the MODE button to go to the next submenu. To enter the ramp duration, use the SEL and SET buttons and the handwheel, as described above. A previously set ramp duration may now exceed the technically fastest possible adjustment, if the ramp duration is simply kept from an old program.
  • Page 75 • Press the MODE button to go to the next submenu. The screen time for the selected ramp duration can be displayed. The screen time is the time (in seconds) needed for a projection at a selected standard projection speed: 24, 25 and 30 fps are available.
  • Page 76 < ) < ) comp. off comp. Iris < ) ramp < ) comp. User comp. off PROG PROG PROG PROG ramp < ) ramp < ) comp. Iris comp. User PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG...

  • Page 77: Controlling The Mirror Shutter Angle (Master Value: Shutter Angle)

    The READY LED flashes green. If the iris of the lens is not controlled by the WRC-1, the warning ‘NO IRIS’ appears in the main menu when selecting a WRC function or compensation which requires...

  • Page 78: Shutter Angle / Compensation Off

    ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 79 Correct parameters must be set before the camera is started! By pressing the SET button, the currently set T-stop (if con- trolled by the WRC-1) can be displayed in the first display line, and the currently set camera speed is shown in the second display line.

  • Page 80: Shutter Angle / Compensation Iris

    5.6.2 Shutter angle / < ) compensation iris comp. Iris The mirror shutter angle can be manually adjusted within the pre-defined end-stops of the handwheel (master value: Shutter angle). The exposure is automatically compensated for with the iris of the lens. The visible depth of field can be altered with this function.
  • Page 81 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 82 Press the SEL button for longer than 2 seconds. Depending on the definable limit value, the T-stop value flashes in the first or second display line. This can now be set using the handwheel. The automatically calculated other limit value is shown in the other display line.
  • Page 83 • Press the MODE button to go to the next submenu. To define the fixed value for the camera speed, use the SEL and SET buttons and the handwheel, as described above. • Press the MODE button to go back to the main menu.

  • Page 84: Shutter Angle / Compensation User

    (if controlled by the WRC-1). If appropriate values are selected, either the exposure can be kept at a constant level, or an adjustment process can be defined to change the exposure as required (e.g.
  • Page 85 ‘ and the currently adjusted shutter angle in the first display line. If the iris is also controlled by the WRC-1, this is indicated by an ‘F’ at the end of the first display line. The currently adjusted T-stop can be shown in the first display line by pressing the SET button.
  • Page 86 • Press the MODE button to go to the next submenu. To define the values for the minimum and maximum aperture (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above. The first display line shows the value for the left end-stop,...
  • Page 87 • Press the MODE button to go to the next submenu. To define the values for the minimum and maximum camera speed, use the SEL and SET buttons and the handwheel. The first display line shows the value for the left end-stop, the second line shows the value for the right end-stop.

  • Page 88: Ramp Shutter Angle / Compensation Off

    By pressing the SET button, the currently set T-stop can be shown in the first display line (if controlled by the WRC-1), and the currently set camera speed is shown in the second display line.
  • Page 89 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 90 • Press the MODE button to go to the next submenu. To define the fixed values for the aperture of the lens (if controlled by the WRC-1) and the camera speed, use the SEL and SET buttons and the handwheel, as described above.
  • Page 91 Note: The shortest possible ramp time is adjusted by turning the handwheel to the left end-stop. The maximum ramp time is 100 seconds. • Press the MODE button to go back to the main menu.

  • Page 92: Ramp Shutter Angle / Compensation Iris

    RAMP button in the camera run (master value: Shutter angle). The iris of the lens is automatically adjusted by the WRC-1 within the pre-defined limit values to compensate the exposure. The visible depth of field can be altered with this function.
  • Page 93 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 94 • Press the MODE button to go to the next submenu. The limit values for the aperture can be defined. The iris is automatically adjusted by the WRC-1 to compensate the exposure, while the shutter angle is ramped. One of the two limit values (minimum or maximum aperture, depending on the adjustment direction of the shutter angle) can be defined;...
  • Page 95 The maximum aperture (smallest T-stop number) corresponds to the selected minimum shutter angle. • Press the MODE button to go to the next submenu. To enter the fixed value for the camera speed, use the SEL and SET buttons and the handwheel. •...

  • Page 96: Ramp Shutter Angle / Compensation User

    5.6.6 Ramp shutter angle / compensation user The shutter angle is continuously adjusted, simultaneously together with the aperture (if controlled by the WRC-1) and the camera speed, within the freely definable limits over a pre-defined period of time after pressing the RAMP button in the camera run.
  • Page 97 ‘ and the currently adjusted shutter angle in the first display line. If the iris is controlled by the WRC-1, this is indicated by an ‘F’ at the end of the first display line. The currently adjusted T-stop can be shown in the first display line by pressing the SET button.
  • Page 98 parameter has been exceeded (example: the selected speed is not available with this camera); readings with ‘OFF’ in the first display line indicate that this function is deactivated on the camera (example: shutter angle of the 435 is set manually = ‘OFF ANGLE’). Correct parameters must be set before the camera is started! The handwheel is without function in the main menu.
  • Page 99 • Press the MODE button to go to the next submenu. To define the values for the minimum and maximum aperture (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above. The first display line shows the start value of the aperture, and the second line the value at the end of the ramp.
  • Page 100 • Press the MODE button to go to the next submenu. To enter the ramp duration, use the SEL and SET buttons and the handwheel as described above. A previously set ramp duration may now exceed the technically fastest possible adjustment, if the ramp duration is simply kept from an old program.
  • Page 101 • Press the MODE button to go to the next submenu. The screen time for the selected ramp duration can be displayed. The screen time is the time (in seconds) needed for a projection at a selected standard projection speed: 24, 25 and 30 fps are available.
  • Page 102 comp. off comp. Iris comp. < ) comp.Iris < ) 50% comp.max. Iris comp.max. < ) comp.user...
  • Page 103 ramp fps ramp fps ramp fps comp.off comp.Iris comp.< ) PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG ramp fps ramp fps comp.Iris/< ) 50% comp.max. Iris PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG...

  • Page 104: Controlling The Camera Speed (Master Value: Speed)

    By pressing the SET button, the currently set shutter angle (if controlled by the WRC-1) can be shown in the first display line and the currently set T-stop (if controlled by the WRC-1) is shown in the second display line.
  • Page 105 To define the fixed values for the mirror shutter angle (if controlled by the WRC-1) and the aperture of the lens (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above. If the aperture of the lens is controlled by the WRC-1, the display shows full T-stops followed by the tenth of a T-stop.

  • Page 106: Speed / Compensation Iris

    2.8 plus half a T-stop is shown as 2.8_5. The tenths of a T-stop are linearly divided between the two full T-stop positions. By pressing the SET button, the currently set shutter angle (if controlled by the WRC-1) can be shown in the first display line.
  • Page 107 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 108 • Press the MODE button to go to the next submenu. The limit values for the aperture of the lens can be defined. The aperture is automatically adjusted by the WRC-1 for a constant exposure, while the camera speed is adjusted with the handwheel. One of the two limit...
  • Page 109 • Press the MODE button to go to the next submenu. To define the fixed value for the mirror shutter angle (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above. • Press the MODE button to go back to the main menu.

  • Page 110: Speed

    The second line shows the currently adjusted camera speed using the handwheel. By pressing the SET button, the currently set T-stop (if controlled by the WRC-1) can be shown in the first display line.
  • Page 111 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 112 • Press the MODE button to go to the next submenu. To define the fixed value for the aperture of the lens (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above. • Press the MODE button to go back to the main menu.

  • Page 113: Compensation Iris And Shutter Angle 50

    ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 114 WRC-1. Press the SEL button for longer than 2 seconds. Depending on the definable limit value, the shutter angle display flashes in the first or second display line.
  • Page 115 If the compensation range available for the shutter angle is exceeded (e.g. the start shutter angle is at the beginning or end of the adjustment range), the READY LED flashes green and the warning ‘ANGLE RANGE’ flashes on the display after returning to the main menu.

  • Page 116: Speed

    comp.max. Iris 5.7.5 Speed / compensation max. iris The camera speed can be manually adjusted within the pre-defined end-stops of the handwheel (master value: Camera speed). The exposure is automatically compensated for by adjusting the aperture of the lens. If the adjustment range of the iris is not sufficient for the given end values, the rest will be compensated for by the mirror shutter.
  • Page 117 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 118 • Press the MODE button in the main menu to enter the first submenu. The limit values for the left and right end-stop of the handwheel (minimum and maximum camera speed) can be defined. The first display line shows the value for the left end-stop, the second line shows the value for the right end-stop.
  • Page 119 WRC-1. Press the SEL button for longer than 2 seconds. Depending on the definable limit value, the shutter angle display flashes in the first or second display line.

  • Page 120: Speed

    comp.max. < ) 5.7.6 Speed / compensation max. shutter angle The camera speed can be manually adjusted within the pre-defined end-stops of the handwheel (master value: Camera speed). The exposure is automatically compensated for by adjusting the mirror shutter angle. If the adjustment range of the shutter angle is insufficient for the given end value, the rest will be compensated for by the aperture of the lens.
  • Page 121 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 122 • Press the MODE button in the main menu to enter the first submenu. The limit values for the left and right end-stop of the handwheel (minimum and maximum camera speed) can be defined. The first display line shows the value for the left end-stop, the second line shows the value for the right end-stop.
  • Page 123 WRC-1. Press the SEL button for longer than 2 seconds. Depending on the definable limit value, the T-stop display flashes in the first or second display line.

  • Page 124: Speed / Compensation User

    Using the handwheel, the camera speed can be manually adjusted within the pre-defined end-stops, simultaneously together with the values for the shutter angle (if controlled by the WRC-1) and the iris (if controlled by the WRC-1). If appropriate values are selected, either the exposure can be kept at a constant level, or an adjustment process can be defined to change the exposure as required (e.g.
  • Page 125 The first line of the main menu shows the currently adjusted shutter angle (if controlled by the WRC-1). If the iris is controlled by the WRC-1, this is indicated by an ‘F’ at the end of the first display line. By pressing the SET button, the currently adjusted aperture can be shown in the first display.
  • Page 126 • Press the MODE button to go to the next submenu. To define the values for the minimum and maximum shutter angle (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above. The first display line shows the value for the left end-stop,...
  • Page 127 • Press the MODE button to go to the next submenu. To define the values for the minimum and maximum aperture of the lens (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above.

  • Page 128: Ramp Speed / Compensation Off

    By pressing the SET button, the currently set shutter angle (if controlled by the WRC-1) can be shown in the first display line, and the currently set aperture (if controlled by the WRC-1) in the second display line.
  • Page 129 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 130 To define the fixed values for the mirror shutter angle (if controlled by the WRC-1) and the aperture of the lens (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above. The display shows full T-stops followed by the tenth of a T-stop.
  • Page 131 • Press the MODE button to go to the next submenu. The screen time for the selected ramp duration can be displayed. The screen time is the time (in seconds) needed for a projection at a selected standard projection speed: 24, 25 and 30 fps are available.

  • Page 132: Ramp Speed / Compensation Iris

    RAMP button in the camera run (master value: Camera speed). The iris is automatically adjusted by the WRC-1 within the pre-defined limit values to compensate the exposure. If the iris control is not available, the flashing warning ‘NO IRIS’...
  • Page 133 By pressing the SET button, the currently set shutter angle (if controlled by the WRC-1) can be shown in the first display line. Note The following warnings may be displayed: ‘IRIS TBL’ – a valid iris table has not yet been activated;...
  • Page 134 • Press the MODE button to go to the next submenu. The limit values for the aperture can be defined. The aperture is automatically adjusted by the WRC-1 to compensate the exposure while the camera speed is ramped. One of the two limit values (minimum or maxi- mum aperture, depending on the adjustment direction of the camera speed) can be defined;...
  • Page 135 • Press the MODE button to go to the next submenu. To define the fixed value for the mirror shutter angle (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above. • Press the MODE button to go to the next submenu.

  • Page 136: Compensation Shutter Angle

    By pressing the SET button, the currently set T-stop (if controlled by the WRC-1) can be shown in the first display line. The display shows full T-stops followed by the tenth of a T-stop. Example: T-stop 2.8 plus half a T-stop is shown as 2.8_5.
  • Page 137 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 138 • Press the MODE button to go to the next submenu. The limit values for the shutter angle can be defined. The shutter angle is automatically adjusted by the WRC-1 to compensate the exposure while the camera speed is ramped. One of the two limit values (minimum or maximum shutter angle, depending on the adjustment direction of the camera speed) can be defined;...
  • Page 139 • Press the MODE button to go to the next submenu. To define the fixed value for the aperture of the lens (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above. • Press the MODE button to go to the next submenu.

  • Page 140: Compensation Iris And Shutter Angle 50

    (master value: Camera speed). The iris of the lens and the mirror shutter angle are auto- matically adjusted by the WRC-1 to equal proportions within the pre-defined limit values, to compensate the exposure. If the iris control is not available, the flashing warning ‘NO IRIS’...
  • Page 141 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 142 The limit values for the shutter angle can be defined. The shutter angle is automatically adjusted by the WRC-1 to compensate the exposure while the camera speed is ramped. One of the two limit values (minimum or maximum shutter angle, depending on the adjustment direction of the camera speed) can be defined;...
  • Page 143 If the compensation range available with the shutter angle is exceeded, the READY LED flashes green and the warning ‘ANGLE RANGE’ flashes on the display after returning to the main menu. The limit values for the shutter angle or the camera speed must be corrected! The camera can still be started for test purposes in spite of the flashing warning.
  • Page 144 • Press the MODE button to go to the next submenu. To enter the ramp duration, use the SEL and SET buttons and the handwheel. A previously set ramp duration may now exceed the technically fastest possible adjustment, if the ramp duration is simply kept from an old program.
  • Page 145 • Press the MODE button to go to the next submenu. The screen time for the selected ramp duration can be displayed. The screen time is the time (in seconds) needed for a projection at a selected standard projection speed: 24, 25 and 30 fps are available.

  • Page 146: Ramp Speed / Compensation Max. Iris

    RAMP button is pressed in the camera run (master value: Camera speed). The aperture of the lens is automatically adjusted by the WRC-1 within the pre-defined limit values, to compensate the exposure. If the adjustment range of the aperture is not sufficient for the given end values, the rest will be compensated for by the mirror shutter.
  • Page 147 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 148 The limit values for the aperture of the lens can be defined. Both the iris and the shutter angle (only if necessary) are automatically adjusted by the WRC-1 to compensate the exposure while the camera speed is ramped. The two limit values (minimum and maximum aperture) can be selected as required.
  • Page 149 WRC-1. Press the SEL button for longer than 2 seconds. Depending on the definable limit value, the shutter angle value flashes in the first or second display line.
  • Page 150 • Press the MODE button to go to the next submenu. To enter the ramp duration, use the SEL and SET buttons and the handwheel, as described above. A previously set ramp duration may now exceed the technically fastest possible adjustment, if the ramp duration is simply kept from an old program.
  • Page 151 • Press the MODE button to go to the next submenu. The screen time for the selected ramp duration can be displayed. The screen time is the time (in seconds) needed for a projection at a selected standard projection speed: 24, 25 and 30 fps are available.

  • Page 152: Ramp Speed / Compensation Max. Shutter Angle

    RAMP button is pressed in the camera run (master value: Camera speed). The mirror shutter angle is automatically adjusted by the WRC-1 to compensate the exposure. If the adjustment range of the shutter angle is insufficient for the given end value, the rest will be compensated for by the aperture of the lens.
  • Page 153 ‘NO’ in the first display line indicate that the selected function is currently not available (example: ‘NO IRIS’ although the iris control is activated on the WRC-1, the iris motor has not yet been connected); readings with ‘RANGE’ in the second display...
  • Page 154 • Press the MODE button in the main menu to enter the first submenu. The limit values for the minimum and maximum camera speed can be defined. The first display line shows the start value of the camera speed, and the second line the value at the end of the ramp.
  • Page 155 WRC-1. Press the SEL button for longer than 2 seconds. Depending on the definable limit value, the T-stop value flashes in the first or second display line.
  • Page 156 • Press the MODE button to go to the next submenu. To enter the ramp duration, use the SEL and SET buttons and the handwheel, as described above. A previously set ramp duration may now exceed the technically fastest possible adjustment, if the ramp duration is simply kept from an old program.
  • Page 157 • Press the MODE button to go to the next submenu. The screen time for the selected ramp duration can be displayed. The screen time is the time (in seconds) needed for a projection at a selected standard projection speed: 24, 25 and 30 fps are available.

  • Page 158: Ramp Speed / Compensation User

    5.7.14 Ramp speed / compensation user The camera speed is continuously adjusted, together with the iris (if controlled by the WRC-1) and the mirror shutter angle (if controlled by the WRC-1) within the freely definable limits over a pre-defined period of time after pressing the RAMP button in the camera run.
  • Page 159 The main menu shows the currently adjusted shutter angle in the first line. If the aperture is being controlled by the WRC-1, this is indicated by an ‘F’ at the end of the first display line. The currently adjusted T-stop can be shown in the first display line by pressing the SET button.
  • Page 160 parameter has been exceeded (example: the selected speed is not available with this camera); readings with ‘OFF’ in the first display line indicate that this function is deactivated on the camera (example: shutter angle of the 435 is set manually = ‘OFF ANGLE’). Correct parameters must be set before the camera is started! The handwheel is without function in the main menu.
  • Page 161 • Press the MODE button to go to the next submenu. To define the values for the minimum and maximum shutter angle (if controlled by the WRC-1), use the SEL and SET buttons and the handwheel, as described above. The start value of the shutter angle is shown in the first display line, and the end value is shown in the second line.
  • Page 162 • Press the MODE button to go to the next submenu. To enter the ramp duration, use the SEL and SET buttons and the handwheel, as described above. A previously set ramp duration may now exceed the technically fastest possible adjustment, if the ramp duration is simply kept from an old program.

  • Page 163: Warnings

    6. Warnings Warnings are only displayed in the WRC mode, and only in the main menu (indicated by a black bar in photo the top right of the display). In CAM mode, only warnings are displayed, which also appear on the camera display. All flashing displays (including LEDs) indicate a warning.
  • Page 164 The connected camera is in the program mode; the program activated in the camera has priority. The camera program must be deactivated if the WRC-1 is to be used for controlling (see Camera instruction manual). A single frame unit is attached to the camera.
  • Page 165 (or to CCU on the ARRIFLEX 535A). Set the camera selector switch to PS/CCU. With the ARRIFLEX 535A only a fixed reverse speed of 25 fps is available via the WRC-1. The connected camera does not have an electronically adjustable mirror shutter. The exposure cannot be compensated for using the mirror shutter.
  • Page 166 Connect a CLM-2 iris motor, or set the IRIS sliding switch to ON and then switch the WRC-1 (and WMU-1) off and on again to reset the units, or select a WRC function which does not require an iris control.
  • Page 167 The programmed camera speed values lie outside of the available range (e.g. the WRC-1 has been programmed for a high- speed camera, but a standard model is now connected). The ramp time cannot be executed for technical reasons. Set an executable (longer) ramp time.

  • Page 168: Warnings When Programming Iris Tables

    h:min TC UB sec:f A T-stop has been programmed which cannot be correct, e.g. T-stop 2.0 cannot lie between 2.8 and 4. The incorrectly positioned value must be deleted and reset. The adjustment range of the iris ring is not compatible filter with the selected lens even though it has been re-calibrated.
  • Page 169 The T-stop value set on the lens lies outside of the permitted range. Reset the T-stop on the lens. The loaded table contains an error, or it is not compatible with the lens mounted on the camera. Re-program the T-stops.
  • Page 170 BAT RDY WMU-1 + WRC-1 CLM-2 UC-C1 LENS CONTROL SYSTEM UC-R1 UMC-1 + URM-1 535, 535B, 435, 16 SR3...

  • Page 171: Quick Guide

    ... K2.52035.0 Note: CLM-1 motors cannot be used as iris motors for the WRC-1. • In order to operate the WRC-1 the following EPROM versions must be used: WMU: ... 01.50 or higher UMC: ... 01.50 or higher ARRIFLEX 435 ...

  • Page 172: Basic Operating Modes

    7.2.1 CAM mode Set the WRC/CAM sliding switch to CAM. In this operating mode the display on the WRC-1 is identical to the camera display. The settings on the camera can be adjusted by IRIS pressing the MODE, SEL and SET buttons. The OPEN button serves as the PHASE button on the camera.

  • Page 173: Operation

    Changes in exposure can be compensated for by auto- matically adjusting one or two of the other controllable parameters. The WRC-1 does not have its own ON/OFF switch. It is activated via the devices to which it is connected (e.g. the WMU-1).

  • Page 174: Iris Control

    ‘IRIS TBL’ appears when the WRC-1 is switched on with the IRIS sliding switch set to the position ‘IRIS ON’. Press the MODE button to switch to the input mode.
  • Page 175 Display: Lens set: ARRI Zeiss Ultra Primes VAr P ARRI Zeiss Variable Primes HS 35 ARRI Zeiss High-speed set for 35mm film Std35 ARRI Zeiss Standard set for 35mm film HS 16 ARRI Zeiss High-speed set for 16mm film User lenses previously defined by the user Confirm the selection by pressing the SEL button.
  • Page 176 however be at least four T-stops apart, in order to define the iris table. If the iris scale is not linear, all the T-stops must be programmed. After programming the iris table, the T-stops on the iris ring of the lens must be controlled by adjusting with the handwheel and visually checking the lens.

  • Page 177: Entering Values

    – the limit values for the camera speed are defined in the first submenu. • The remaining exposure-related parameters are defined in the following submenus, if the corresponding functions are controlled by the WRC-1. black indicator bar for main menu...
  • Page 178 The ramp duration is set, the screen time is displayed when a corresponding function is selected, and the reading ‘CONST LIGHT’ confirms a constant exposure resulting from the values set in the user-defined mode. The corresponding submenus for each adjustable combination of master values and compensations can be seen in the following illustrations or chapter 5 of this instruction manual.
  • Page 179 Iris Iris comp. off comp. < ) Iris ramp Iris comp. user comp. off PROG PROG PROG PROG ramp Iris ramp Iris comp. < ) comp. user PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG...
  • Page 180 < ) comp. off comp. Iris < ) < ) comp. User ramp < ) ramp < ) comp. off comp. Iris PROG PROG PROG PROG PROG PROG PROG PROG PROG ramp < ) comp. User PROG PROG PROG PROG PROG PROG PROG...
  • Page 181 comp. off comp. Iris comp. < ) comp.Iris < ) 50% comp.max. Iris comp.max. < ) comp.user...
  • Page 182 ramp fps ramp fps comp.off comp.Iris PROG PROG PROG PROG PROG ramp fps ramp fps comp.< ) comp.Iris/< ) 50% PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG PROG ramp fps ramp fps ramp fps comp.max.

  • Page 183: Glossary

    Slave value: Adjusting the master value alters the film exposure. This difference in exposure can be automatically compensated for by the WRC-1. To do this, the WRC-1 adjusts the other parameters, e.g. altering the camera speed can be compensated for by the iris of the lens or by the shutter angle as required.

  • Page 185: Arri Service

    600 North Victory Blvd. Burbank, California 91502 phone: (818) 841 70 70 fax: (818) 848 40 28 E-mail: arriflex@arri.com GB ... ARRI (GB) Ltd. The Movie House 1-3 Airlinks, Spitfire Way phone: (0208) 848 88 81 fax: (0208) 561 13 12 E-mail: sales@arri-gb.com...

  • Page 187: Index

    10.Index ADJ ... 42, 45, 50, 175 adjustments ... 13, 183 under 6 fps ... 30 ANGLE RANGE ... 29, 56, 68, 112, 115, 118, 138, 143, 149, 167 angle symbol ...14, 59, 71 antenna ... 19 applications ... 10 ARRIFLEX 535A ...
  • Page 188 iris / angle 50 % ... 15 max. angle ...15 max. iris ... 15 off ...15 rotary switch... 13, 15, 25, 165, 173 user ... 15 CONST LIGHT ... 61, 73, 87, 99, 127, 161, 178 dark phase ... 30 decimal positions ...
  • Page 189 electronically adjustable mirror shutter ... 77, 165 elements for operating ... 25 end value ... 33 end-stops ... 33 calibrating ... 49, 174 entering values ... 177 EPROM versions ... 17, 30, 171 ERR ...168 ESU-1 ... 164 exposure compensation ... 10 exposure fluctuations ...
  • Page 190 IRIS RANGE ... 29, 82, 94, 109, 115, IRIS sliding switch ... 13, 26, 37, 38, 166 iris socket ... 23 iris table ...38, 166, 174 checking ... 42, 46, 50, 175 CLOSE position ...46, 51 deleting an old table ... 44 end-stops programming ...
  • Page 191 main menu ...163 master values ... 13, 173, 178, 183 memory area ...39, 47, 48 number ... 47 selection ... 48 mirror shutter angle on the camera ... 28 electronically adjustable ... 77 mode CAM ...12, 163 program ...164 WRC ... 13 MODE button ...
  • Page 192 radio link ... 17 ramp ...13, 183 angle ... 14 duration ... 178 fps ...14 iris ...14 reversing ... 63, 67, 72, 89, 93, 98, 129, 133, 137, 141, 147, 153, 160 time ... 13, 59, 71, 85, 97, 125, 159 under 6 fps ...30 RAMP button ...
  • Page 193 speed settings ... 25 on the camera ... 28 standard lenses ... 41, 175 standard t-stop range ... 45, 46 start value ... 33 STORE ... 47, 176 storing of programs and values ... 28 stroboscopic effects ... 11 SU OR ESU ...164 submenu ...
  • Page 194 ... 19 WMU-1 ... 17, 171 WRC mode ... 13, 26, 28 WRC rotary switch ... 13, 14, 25, 173 WRC-1 ... 17, 24, 171 WRC/CAM sliding switch ...12, 25, 26, 172 Zeiss High-speed lenses ... 175 Zeiss standard lenses... 175 88, 93, 98, 107, 114, Zeiss Ultra Primes ...
  • Page 195 MODE press SEL press SEL to confirm to confirm tabel is deleted USEr donE handwheel 1-10 1 second… Main Menu WRC-1: Iris Table Editing active lens-table active lens-table editing storing Edit StorE load press SEL press SEL coming from edit...
  • Page 196 © ARRI 2000 available languages: Deutsch K 5.43660.0 English K 5.43668.0 ARNOLD & RICHTER TÜRKENSTR. 89 D-80799 MÜNCHEN • FAX (089) 3809 - 1244 • CINE TECHNIK TEL. (089) 3809-0 • http://www.arri.de...

Table of Contents
