What's in the Box?
PART NO.
QTY
DESCRIPTION
SMCVG2DVIS
1
VGA to DVI Active Converter. Includes: [SMCVG2DVI &
(PS5VD2A)
Power Supply
1
PS5VDC2A
User Manual
1
Technical Specifications
VIDEO
Format
VGA, DVI-D Single-link
Resolution
WUXGA (1920x1200), UXGA (1600x1200), SXGA
(1280x1024), XGA (1024x768), SVGA (800x600), VGA
(640x480)
Input Interface
(1) HD-15 Female
Output Interface
(1) DVI-D Single-link Female, (1) HD-15 Female
Connector
HD-15, DVI-D
OTHER
DDC Signal
5 Volts [peak-to-peak], TTL
TDMS Signal
1.2 Volts[peak-to-peak], TTL
Power
External 5VDC2A @ 10W
Dimensions
5"W x 1.375"H x 4"D
Weight
0.6 lbs.
Approvals
Device: CE, ROHS
Power Supply: C-UL US, CE
© Copyright 2010 Smart-AVI, All Rights Reserved
NOTICE
T h e i n f o r m a t i o n c o n t a i n e d i n t h i s d o c u m e n t
is subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance or use of this material.
No part of this document may be photocopied, reproduced or
translated into another language without prior written consent
from Smart-AVI.
For more information, visit www.smartavi.com.
SmartAVI, Inc. / Twitter: smartavi
2840 N. Naomi Ave. Burbank, CA 91504
Tel: (818) 565-0011 Fax: (818) 565-0020
http://www.SmartAVI.com
Installation
Manual
SMCV G 2DVI
VGA to DVI Active Converter
Converts VGA input to DVI-D output
with local VGA display
www.smartavi.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SmartAVI SMCVG2DVI
Summary of Contents for SmartAVI SMCVG2DVI
-
Page 1: Technical Specifications
What’s in the Box? © Copyright 2010 Smart-AVI, All Rights Reserved PART NO. DESCRIPTION SMCVG2DVIS VGA to DVI Active Converter. Includes: [SMCVG2DVI & (PS5VD2A) NOTICE Power Supply PS5VDC2A User Manual T h e i n f o r m a t i o n c o n t a i n e d i n t h i s d o c u m e n t is subject to change without notice. - Page 2 • Sync Tuning for better signal conversion Connect a VGA cable to the computer and to the VGA IN port on the rear of the SMCVG2DVI. Connect the local VGA display to the VGA OUT Applications port on the rear SMCVG2DVI.
