SmartAVI SMCCV2DVI Installation Manual

What's in the Box?
PART NO. QTY DESCRIPTION
SMCCV2DVIS 1 NTSC/PAL to DVI/VGA active Converter
Power Supply 1 PS5VDC2A
User Manual 1

Technical Specifications

VIDEO
Input Format NTSC/PAL/SECAM
Output Formats (1) NTSC/PAL/SECAM, (1) VGA, (1) DVI-D
Resolution 800 x 600, 1024 x 768,
up to 1280 x 1024@60Hz
Input Interface (1) BNC Female
Output Interface (1) BNC Female, (1) HD-15 Female, (1) DVI-D
Single-link Female
OTHER
Power External 5VDC2A
Dimensions 5.25"W x 1.375"H x 3.375"D
Weight 0.45 lbs.
Approvals Device: CE, ROHS
Power Supply: C-UL US, CE
© Copyright 2010 Smart-AVI, All Rights Reserved
T h e i n f o r m a t i o n c o n t a i n e d i n t h i s d o c u m e n t
is subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular purpose.
Smart-AVI will not be liable for errors contained herein or for
incidental or consequential damages in connection with the
furnishing, performance or use of this material.
No part of this document may be photocopied, reproduced or
translated into another language without prior written consent
from Smart-AVI.
SMCCV2DVI Front
SMCCV2DVI Rear
