Summary of Contents for DRIFT HD Ghost

  • Page 1 follow us facebook.com/driftinnovation vimeo.com/driftinnovation twitter.com/driftinnovation DRIFTINNOVATION.COM...
  • Page 2 quick guide...
  • Page 3 Thank you for purchasing the Drift HD Ghost CUSTOMER SUPPORT Check our official website for firmware updates, customer support, news about our products and videos from our users. If you have any suggestions, comments or concerns, please contact our customer support team at: support@driftinnovation.com...
  • Page 4: Table Of Contents

    contents about your camera | initial setup 3—4 package contents | getting started 5—6 mode selection & settings 7—8 playback & camera settings 9—10 using the two-way remote | mounting the camera 11—12 wifi | connecting the camera 13—14 specifications 15—16 disclosures 17—18...
  • Page 5: About Your Camera | Initial Setup

    about your camera MENU / Tag / Back Button LEFT Button / Zoom Out RIGHT Button / Zoom In ACTION Button (On/Off/Rec/Stop) Status LED Rear Hatch 2.0” LCD Screen 300° Rotating Lens USB Port (Mini-B) HDMI Port (Mini-C) 3.5mm Microphone Input Micro SD Card Slot Battery Slot Cover...
  • Page 6: About Your Camera | Initial Setup

    initial setup 1. Unscrew and remove the 4. Connect the camera rear hatch via mini USB cable to a powered USB port and 2. Insert a Class 6 or higher charge the battery for 4 micro SD card hours before first use 3.
  • Page 7: Package Contents | Getting Started

    package contents Remote Control Rechargeable Battery Connector Hatch Universal Clip Mount Kit Goggle Mount...
  • Page 8: Package Contents | Getting Started

    getting started Wrist Strap POWER ON AND OFF MAIN MENU Press the MENU button to 1. Press and hold the enter the Main Menu. The ACTION button to screen will display the icons power on of the four menu options. 2.
  • Page 9: Mode Selection & Settings

    mode selection & settings Video Photo MODE SELECTION MENU VIDEO MODE The Mode Selection menu (Green LED) The camera displays the icons for the will record video when four camera modes. ACTION is pressed on the Highlight the desired mode camera or remote.
  • Page 10 PHOTO MODE TIMELAPSE MODE PHOTOBURST MODE (Yellow LED) The camera (Purple LED) The camera (Cyan LED) The camera will capture still images will capture a series of still will capture a burst of still when ACTION is pressed images at a specified rate images for an allotted on the camera or remote.
  • Page 11: Playback & Camera Settings

    playback & camera settings PLAYBACK CAMERA SETTINGS Playback Selecting the Playback • WiFi On / Off icon will open the Mode • Mic Sensitivity Off / 1 / 2 / 3 Selection menu, and display • Speaker Volume Off / 1 / 2 / 3 the four camera mode icons.
  • Page 12 new features SETTING PROFILES VIDEO TAGGING The Video Tagging feature requires a micro SD card All camera settings can be When activated, this feature with 4GB of free space to saved by selecting Save allows the camera to function correctly. Settings from the Camera continuously record video, Settings menu and choosing...
  • Page 13: Using The Two-Way Remote | Mounting The Camera

    using the two-way remote POWER ON AND OFF ACTION will begin recording video, capture a photo, start 1. Hold the ACTION timelapse or photoburst, button to power on depending on the camera 2. The colour of the remote mode. Pressing STOP will end control’s LED indicator video or timelapse recording.
  • Page 14: Using The Two-Way Remote | Mounting The Camera

    mounting the camera 1. Attach the Universal Clip 2. Slide the Universal Clip 3. Check screen alignment, to the camera in any 360° into your chosen mount, rotating the lens by hand orientation as needed— ensuring that it ‘clicks’ as necessary to realign first position the clip in into place your shot, using the...
  • Page 15: Wifi | Connecting The Camera

    NOTE - The WiFi setting will be activated by firmware update on and, from the Main menu, once the Drift App for Apple® and Android® is available. open the Camera Settings Please check the Drift website for more information and menu and select ‘Version’...
  • Page 16: Wifi | Connecting The Camera

    USB screen will show a USB HDMI (Type C) to full icon icon HDMI cable, available from Drift retailers. 2. The camera’s folder may 2. The camera’s folder may open automatically; if open automatically; if 2. Power on the camera...
  • Page 17: Specifications

    specifications Video resolution: 1080p, 720p and WVGA (16:9); 960p (4:3) File format: .MP4 / .MOV (H.264 codec) Sensor type: CMOS Frame rate:- 1080p: 25 / 30 fps 960p: 25 / 30 / 48 fps 720p: 25 / 30 / 50 / 60 fps WVGA: 25 / 30 / 50 / 60 / 100 / 120 fps Field of view:-...
  • Page 18 Waterproof 3m (9.84ft) Microphone: Built-in, noise reducing microphone Built-in memory: 256MB (not user accessible) Memory capacity: Micro SD memory cards up to 32GB Inputs: 3.5mm external microphone (extension included) Outputs: HDMI connector type C (cable not included) Connectivity: USB Plug and Play, mini-B USB connector Compatibility: Windows XP and up / Mac OS 10.2 and up Remote range:...
  • Page 19: Disclosures

    disclosures FCC Information The equipment has been harmful interference to radio or tested and found to comply television reception, which can This device complies with Part with the limits for a Class B be determined by powering the 15 of the FCC Rules. digital device, pursuant to Part equipment on and off, the user 15 of the FCC Rules.
  • Page 20 This device complies with de l’intervention, y compris This transmitter must not be Industry Canada license- l’intervention qui peut causer co-located or operating in exempt RSS standard(s). l’opération non désirée de. conjunction with any other antenna or transmitter. Operation is subject to the Cet appareil numérique de la following two conditions: classe [B] est conforme à...
