Legacy Harmony Center Owner's Manual page 11

Speaker Installation
4. Remove the cabinet from wall to expose the hanger blocks.
5. Drill a 1/8" pilot hole, 1 ½" to 2" at each marked location.
6. Connect the wires to the terminal plate located at the bottom of the cabinet and re-
place the cabinet in the hanger blocks as before.
a) Strip and terminate speaker cable with spade lugs, banana plugs or twisted bare
wire.
b) Connect each Harmony to the appropriate +, - output terminals of your amplifier
or receiver. Harmony should not be connected in parallel with another speaker to
same amplifier channel.
7. Drive the two 1 ½" screws through the rubber grommets into the cabinet mounting
hole and into the hanger blocks. Do not over tighten and be careful no to dislodge the
rubber grommets. Their function is to prevent cabinet vibrations from being transmitted
to the wall.
11
