Models with "N" after the model number use natural gas; models with "P" after the model number use propane (LP) gas.
This appliance operates as an unvented room heat-
er certified under ANSI Z21.11.2a-2001 when fitted
to a solid fuel burning masonry or factory built fire-
place with the flue damper closed. It also operates
as a decorative appliance under ANSI Z21.60b-2001.
CSA 2.26b-2001, when fitted to a solid fuel burning
masonry or factory built fireplace with the flue
damper open. When used as a decorative appli-
ance, the use of a thermostat is not allowed. State
or local codes may only allow operation of this ap-
pliance in a vented configuration. Check your state
or local codes.
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
—
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
•
Do not try to light any appliance.
•
Do not touch any electric switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instruc-
tions.
•
If you cannot reach your gas supplier, call the fire department.
—
Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
This is an unvented gas-fired heater. It uses air (oxygen) from the room in which it is installed. Provisions
for adequate combustion and ventilation air must be provided. Refer to Section Provisions For Adequate
Combustion and Ventilation Air - Page 6.
Installation and Operating Instructions for
Unvented Gas Log Heaters
Models: UVHK23RP, UVHK29RN,
UVHK31RP, UVHK36RN
WARNING
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
READ AND SAVE THESE INSTRUCTIONS
Charred Oak Logs
US
Split Bark Logs
20008055 3/06 Rev. 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Majestic fireplaces UVHK23RP
Summary of Contents for Majestic fireplaces UVHK23RP
- Page 1 Installation and Operating Instructions for Unvented Gas Log Heaters Models: UVHK23RP, UVHK29RN, UVHK31RP, UVHK36RN Models with “N” after the model number use natural gas; models with “P” after the model number use propane (LP) gas. This appliance operates as an unvented room heat- er certified under ANSI Z21.11.2a-2001 when fitted...
-
Page 2: Table Of Contents
Table of Contents Minimum Dimensions for Existing Solid Fuel Burning Fireplaces ..........3 Important Information ........................ 4 Important Safeguards ....................... 5 Provisions For Adequate Combustion Air ................. 6 Installation Unpacking ..........................8 Fireplace Preparation ........................ 8 Location ............................ 8 Clearances ..........................8 Installation of WRST or WRD Wireless Remote ............... -
Page 3: Minimum Dimensions For Existing Solid Fuel Burning Fireplaces
14¹⁄₂” 15" UVHK31RP 17” 28” 18” 14¹⁄₂” Min. UVHK29RN 17” 23” 16” 14¹⁄₂” Opening Height = H UVHK23RP 17” 23” 16” 14¹⁄₂” 26¹⁄₂" MIn. Vent Free or Decorative Appliance Log Set BTU/hr T104 Model Nominal Size Fuel High min. dims UVHK36RN 24”... -
Page 4: Important Information
Important Information operate the vent-free heater if the fuel level in the propane INSTALLER: Please leave these instructions with the tank is below 1/4 full. Use only with two-stage regulator. owner. • DO NOT use this heater if any part of it has been under OWNER: Please retain these instructions for future water. -
Page 5: Important Safeguards
WARNING: During manufacturing, fabricating and The National Fuel Gas Code, ANSI Z223.1/NFPA 54 shipping, various components of this appliance are defines a confined space as a space whose volume treated with certain oils, films or bonding agents. is less than 50 cubic feet per 1,000 Btu per hour These chemicals are not harmful but may produce (4.8m per kw) of the aggregate input rating of all... -
Page 6: Provisions For Adequate Combustion Air
Provisions for Adequate Combustion and Ventilation Air 4. Compare the maximum BTU/Hr the space can support with WARNING: This heater shall not be installed in the actual amount of BTU/Hr used. a confined space or unusually tight construction __________ BTU/Hr (maximum the space can support) unless provisions are provided for adequate com- __________ BTU/Hr (actual amount of BTU/Hr used) bustion and ventilation air. - Page 7 Flue Damper Closed for Unvented Operation and Maximum Heat Output Flue Damper Locked Open to a Minimum Venting Area of 34 sq. in. (for areas where unvented products are not permitted) NOTE: For round flue opening minimum flue diameter (D) - 7”. For square or rectangular flue opening, length x width (L x W) must equal 30 sq.
-
Page 8: Installation
Installation Unpacking However, it is recommended that these instructions be followed even when the appliance will be used as a vented decorative Open the cartons and remove the logs and the chassis. Re- appliance in case local codes change to allow unvented space move each of the logs by gripping at either end of the log while heaters or in the event that the flue damper is inadvertently avoiding any undue pressure. -
Page 9: Installation Of Wrst Or Wrd Wireless Remote
No Canopy Used 10" 8" 27" 6" Min. 42" 23" Heat Resistant 1¹⁄₈" Min. Material 19" Min. 15" Min. 16" 10" Min. Fireplace Opening Fig. 4A Minimum clearance to wall and ceiling. Fig. 4B Mantel clearances for existing fireplaces. 10" Combustible Mantel 8"... -
Page 10: Installation Of Millivolt Wall Switch
Installation of Millivolt Wall Switch To install your millivolt wall switch, an approved wall box should be installed in a location suitable to you. The thermostat wire should be routed from the wall box to the log set and should be routed underneath the log set as shown in Figure 7 and pulled up to the valve’s wiring terminal as shown in Figure 8. -
Page 11: Gas Connection
Typical Gas Line Connection for staller should perform the pressure test to ensure that the unit is not damaged by high pressures! UVHK23RP, UVHK29RN, UVHK31RP, UVHK36RN MODELS (Figs. 13A and 13B) WARNING: Be sure that the gas type indicated on the gas log rating plate concurs with the gas system in your Step 1: With the engine assembly free from the fireplace, check... -
Page 12: Typical Gas Line Connection
Check the tags on the unit to verify the gas type of the log set. If you connect natural gas to an LP gas unit, you may be un- able to ignite the pilot. If the pilot does ignite, the front burner flame on the low setting will be bright blue but only 1/4”... -
Page 13: Gas Line Pipe Sizing
Gas Line Pipe Sizing NOTE: To determine the size of the branch gas line from the main gas line to the fireplace, enter the tables below (for iron pipe or copper tubing) using the distance from the gas meter or second stage regulator to the furthest appliance on the gas system. -
Page 14: Lighting Instructions For Wrst
For Your Safety, Read Before Lighting WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by hand. C. -
Page 15: Lighting Instructions For Millivolt Wall Switch
For Your Safety, Read Before Lighting WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. C. Use only your hand to push in or turn the gas control knob. A. -
Page 16: Match Lighting
Match Lighting If the pilot cannot be ignited with the piezo, it can be manually 2. Take the lighter rod and lighted match and ignite the pilot. lit with the use of a match and lighter rod. (Fig. 16) 1. Place the match in the holder and light. With the right 3. -
Page 17: Positioning Logs
Positioning Logs • The left and right twigs are to be placed into the appropriate The logs must be positioned ONLY as illustrated in Figures 26, notches provided in the front and rear logs as shown. (Figs. 27, 28. 26, 27, 28) •... - Page 18 Charred Oak Logset Fig. 27 Charred oak logset positions. WARNING: Failure to position the parts in accordance with this diagram or failure to use only parts specifically ap- proved with this heater, may result in property damage or personal injury. Do not alter the logs! Charred Oak Logset LG448 Fig.
-
Page 19: Troubleshooting
Log Spacer All Other Control Bracket Logsets Cover Valve Cover Charred Oak Only Rear Log Bracket T100 Fig. 29 Position log so notch fits securely and rests on valve cover. T100 T124 Front Log log notch Fig. 31 When using Charred Oak logsets, the rear log spacer on valve cover bracket must be cut for the rear log to sit properly. -
Page 20: Servicing
Use manufacturer’s authorized parts only. If you desire to Canada L5N 8A3 communicate with the factory, write to Customer Service at: Description UVHK29RN UVHK23RP UVHK36RN UVHK31RP Logs Replacement logs may only be ordered in sets. Refer to Page 3 for correct log set number. -
Page 21: Warranty
LIMITED 2/20 YEAR WARRANTY For VERMONT CASTINGS Vent-Free Gas Appliances ® CFM Corporation (Company) extends the warranties speci- A PARTICULAR PURPOSE), ALL OF WHICH ARE HEREBY fied in paragraphs A and B below with respect to its VERMONT EXPRESSLY INCLUDED. IN NO EVENT SHALL ANY IMPLIED CASTINGS Decorative Gas Appliances (the “Gas Appliance”), WARRANTY PRESCRIBED BY LAW (NOTWITHSTANDING including the CFM Corporation supplied accessories and com-... - Page 22 CFM Corporation 2695 Meadowvale Blvd. • Mississauga, Ontario, Canada L5N 8A3 800-668-5323 • www.cfmcorp.com...
