Amana AGR5712BD Series Service Manual

30” freestanding gas ranges
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
Service
This manual is to be used by qualified appliance
technicians only. Maytag does not assume any
responsibility for property damage or personal
injury for improper service procedures done by
an unqualified person.
30" Freestanding
Gas Ranges
This Base Manual covers general information
Refer to individual Technical Sheet
for information on specific models
This manual includes, but is
not limited to the following:
AGR5712BD*
MGR4451BD*
MGR4452BD*
MGR5751BD*
MGR5752BD*
MGRH752BD*
MGRH752CD*
MGRL752BD*
MGRL753BD*
MGRM752BD*
MGRS752BD*
16026785
December 2005
©
2005 Maytag Services

Advertisement

Table of Contents
loading

Related Manuals for Amana AGR5712BD Series

Summary of Contents for Amana AGR5712BD Series

  • Page 1 Service This manual is to be used by qualified appliance technicians only. Maytag does not assume any This Base Manual covers general information responsibility for property damage or personal Refer to individual Technical Sheet injury for improper service procedures done by an unqualified person.

  • Page 2: Important Information

    Web Site Telephone Number WWW.AMANA.COM ..........1-800-843-0304 WWW.MAYTAG.COM ..........1-800-688-9900 CAIR Center in Canada .......... 1-800-688-2002 Amana Canada Product ........... 1-866-587-2002 Recognize Safety Symbols, Words, and Labels DANGER DANGER—Immediate hazards which WILL result in severe personal injury or death. WARNING WARNING—Hazards or unsafe practices which COULD result in severe personal injury or death.

  • Page 3: Table Of Contents

    Table of Contents Important Information ........... 2 Disassembly Procedures Important Safety Information Accessing Range ........... 22 Safety Practices for Servicer ........4 Maintop Assembly ..........22 Servicing ..............4 Manifold Panel ............22 Receiving Oven ............5 Control Panel ............22 Using the Oven ............

  • Page 4: Important Safety Information

    Important Safety Information Recognize this symbol as a safety precaution. W A R NIN G Due to the nature of cooking, fires can occur as a result of overcooking or excessive grease. Although a fire is unlikely, if one occurs proceed as follows: WARNING If the information in this manual is not followed exactly, a fire or explosion may result causing property...

  • Page 5: Receiving Oven

    Important Safety Information 4. Using lights—Use a hand flashlight when servicing • Never use range for warming or heating a room. This ranges or checking for gas leaks. Electric switches may cause burns, injuries, or a fire. should not be operated where leaks are suspected. •...

  • Page 6: Baking, Broiling, And Roasting

    Important Safety Information Universal orifices are Baking, Broiling, and Roasting Gas Burner Orifices used on most valves. • Do not use oven area for storage. They must be adjusted • Stand back from range when opening door of a hot or set for the type of gas oven.

  • Page 7: General Information

    A unit in proper operating order ensures the consumer all the benefits provided by clean, modern gas cooking. Cooking Nomenclature Color Almond on Almond Black Brand Brushed Chrome Amana Traditional White Magic Chef Traditional Almond Graffer & Prostyle Sattler Monochromatic Bisque Hardwick...

  • Page 8: Specifications

    Refer to individual Technical Sheet for specification Complete enclosed registration card and promptly return. information. If registration card is missing: • For Amana product call 1-800-843-0304 or visit the web site at www.amana.com Placement of the Oven • For Maytag product call 1-800-688-9900 or visit the This freestanding range must be placed in the kitchen or web site at www.maytag.com...

  • Page 9: Grounding

    General Information Grounding W ARNIN G NOTE: This appliance must be properly grounded, for Attaching adapter ground terminal to wall receptacle personal safety. cover screw does not ground appliance unless the Power cord on this appliance is equipped with a three- cover screw is metal and not insulated, and wall prong grounding plug.

  • Page 10: Range Description

    Range Description Control Oven Light Switch Surface Surface Burners Burners Surface Burner Surface Burner Control Knobs Control Knobs Door Handle Broil Burner Oven Door Oven Light and Sensor Oven Racks Door Hinge Door Hinge Bake Burner Model Number Rating Label Service/ Warming Drawer...

  • Page 11: Troubleshooting Procedures

    Troubleshooting Procedures WARNING To avoid risk of electrical shock, personal injury or death; disconnect power and gas to range before servicing, unless testing requires power and/or gas. Problem Possible Cause Correction Poor ground on burner cap ......• Clean burner cap. Weak or failed spark module ......
  • Page 12 Troubleshooting Procedures WARNING To avoid risk of electrical shock, personal injury or death; disconnect power and gas to range before servicing, unless testing requires power and/or gas. Problem Possible Cause Correction Failed ignitor..........• Check ignitor current draw, 3.2 – 3.6 Amps.
  • Page 13 Troubleshooting Procedures WARNING To avoid risk of electrical shock, personal injury or death; disconnect power and gas to range before servicing, unless testing requires power and/or gas. Problem Possible Cause Correction Failed oven lamp........• Check lamp and replace is necessary. Failed wiring ..........

  • Page 14: Testing Procedures

    Testing Procedures WARNING To avoid risk of electrical shock, personal injury or death; disconnect power and gas to range before servicing, unless testing requires power and/or gas. Component Testing Procedures Illustration Component Test Procedure Results Oven light socket Measure voltage at oven light ....120 VAC, see wiring diagram for terminal Remove one wire from receptacle and identification.
  • Page 15 Testing Procedures WARNING To avoid risk of electrical shock, personal injury or death; disconnect power and gas to range before servicing, unless testing requires power and/or gas. Illustration Component Test Procedure Results Spark module 4 + 0 Test for voltage at terminals (select models) L and N ...........

  • Page 16: M1 Control Testing Procedures

    Testing Procedures WARNING To avoid risk of electrical shock, personal injury or death; disconnect power and gas to range before servicing, unless testing requires power and/or gas. M1 Control Testing Procedures Control Feature Test Procedure Results Oven temperature Press BAKE pad. Increasing or decreasing oven adjustment temperature does not affect self-cleaning...

  • Page 17: Quick Test Mode For The M1 Electronic Range Control

    Testing Procedures WARNING To avoid risk of electrical shock, personal injury or death; disconnect power and gas to range before servicing, unless testing requires power and/or gas. "Quick Test" Mode for M1 Electronic Range Control Follow the procedure below to access the quick test mode. Entries must be made within 32 seconds of each other or the control will exit the quick test mode.
  • Page 18 Testing Procedures WARNING To avoid risk of electrical shock, personal injury or death; disconnect power and gas to range before servicing, unless testing requires power and/or gas. M1 Diagnostic Code Checking Code Description When Checked Detection 1c1c Shorted key Always 1 minute 1c31 Cancel key circuit problem...

  • Page 19: Nsc Control Testing Procedures

    Testing Procedures WARNING To avoid risk of electrical shock, personal injury or death; disconnect power and gas to range before servicing, unless testing requires power and/or gas. M1 CONTROL TESTING NOTES: "Action Taken" applies as long as the condition exists. If the condition goes away, the control recovers. Flash rate: 0.2 seconds on, 0.1 second off.

  • Page 20: "Quick Test" Mode For Nsc Control

    Testing Procedures WARNING To avoid risk of electrical shock, personal injury or death; disconnect power and gas to range before servicing, unless testing requires power and/or gas. Control Feature Test Procedure Results Twelve Hour Off Control will automatically cancel any See Sabbath mode to disable.
  • Page 21 Testing Procedures WARNING To avoid risk of electrical shock, personal injury or death; disconnect power and gas to range before servicing, unless testing requires power and/or gas. NSC Control Diagnostic Code Checking Code Description When Checked Detection 1c1c Shorted key Always 1 minute 1c31...

  • Page 22: Disassembly Procedures

    Disassembly Procedures To avoid risk of electrical shock, personal injury, or death: WARNING disconnect power and gas supply before servicing. 4. Reverse procedure to reinstall control board Accessing Range assembly. 1. Turn off power to the range at the circuit breaker. 2.

  • Page 23: Oven Sensor

    Disassembly Procedures To avoid risk of electrical shock, personal injury, or death: WARNING disconnect power and gas supply before servicing. 9. Remove screws securing ignitor to broiler. Oven Sensor 10. Remove wing nut securing flame spreader to broiler. 1. Disconnect power before servicing. 11.

  • Page 24: Oven Door Hinge

    Disassembly Procedures To avoid risk of electrical shock, personal injury, or death: WARNING disconnect power and gas supply before servicing. 3. To replace: Oven Door Hinge a. Place the set of rollers on the drawer behind the 1. Turn off power to unit. set of rollers on the oven.

  • Page 25: Oven Lamp Assembly Removal

    Disassembly Procedures To avoid risk of electrical shock, personal injury, or death: WARNING disconnect power and gas supply before servicing. 5. Detach right and left door trim pieces. Convenience Outlet/Circuit Breaker 6. Remove screws securing top door trim to oven door (Canadian Models) chassis.

  • Page 26: Door Disassembly (No Window)

    Disassembly Procedures To avoid risk of electrical shock, personal injury, or death: WARNING disconnect power and gas supply before servicing. 4. Remove screws securing door panel to door lining Door Disassembly (No Window) and remove door liner. 1. Remove oven door, see "Oven Door Removal" 5.
  • Page 27 Appendix A 16026785 A–1 © 2005 Maytag Services...
  • Page 28 Installation Instructions (all except RV’s) fkpq^iiboW ib^sb qebpb fkpqor`qflkp tfqe qeb ^mmif^k`b fkpq^ii^qflk j^kr^i *DV LQFK :LGH )UHHVWDQGLQJ 5DQJH mib^pb hbbm qefp j^kr^i clo crqrob obcbobk`b qeb j^kr^i fp fkqbkaba ql ^ppfpq fk qeb fkfqf^i fkpq^ii^qflk ^ka ^agrpqjbkqp lc qeb o^kdbK `ib^o^k`b afjbkpflkp pmb`f^i t^okfkd Range may be installed with zero inches clearance...
  • Page 29 Installation Instructions (all except RV’s) fkpq^ii^qflk ao^tfkdp cobbJpq^kafkd 16026785 A–3 © 2005 Maytag Services...

  • Page 30: Installation Instructions (All Except Rv's

    Installation Instructions (all except RV’s) afjbkpflk ¥^³ pfab `ib^o^k`b ^_lsb `llhfkd proc^`b qlm _rokbo o^qb clo k^qro^i d^p Epbb o^qfkd mi^qbF `lksbkqflk^i lsbk pbicJ`ib^k lsbk 9,200 BTU/HR OR LESS 0 INCHES 3 INCHES (7.6 CM) MORE THAN 9,200 BTU/HR 1 INCH (2.5 CM) 3 INCHES (7.6 CM) ob`ob^qflk^i m^oh qo^fibop Check the range model number plate to see if the range is...
  • Page 31 Installation Instructions (all except RV’s) ^kqfJqfm absf`b fkpq^ii^qflk fkpqor`qflkp klqbW as shown in figure 2. (A nail or awl may be used if A risk of range tip over exists if the appliance is a drill is not available). Secure the ANTI-TIP not installed in accordance with the installation bracket to the wall with the two screws provided instructions provided.
  • Page 32 Installation Instructions (all except RV’s) `lkkb`qfkd qeb o^kdb bib`qof` prmmiv d^p prmmiv `lkkb`qflkW (See figure 4) The appliance, when installed, must be electrically ^ nr^ifcfba pbosf`bj^k lo d^p ^mmif^k`b grounded in accordance with local codes or, in the fkpq^iibo jrpq j^hb qeb d^p prmmiv absence of local codes, with the National Electrical Code, `lkkb`qflkK i‚~ˆ...
  • Page 33 Installation Instructions (all except RV’s) h. Apply a non-corrosive leak detection fluid to all joints *DV 6XSSO\ &RQQHFWLRQV )RU 5DQJHV :LWK and fittings in the gas connection between the supply $SSOLDQFH 3UHVVXUH 5HJXODWRU line shut-off valve and the range. Include gas fittings /RFDWHG ,Q 7KH %RWWRP 2I 5DQJH and joints in the range if connections were disturbed during installation.
  • Page 34 Installation Instructions (all except RV’s) o^kdb ^agrpqjbkqp qŒ p‚€‘†Œ‹ J d~ qŒ m†‰Œ‘ ^‡’‘Š‚‹‘ qŒ _’‹‚ ^‡’‘Š‚‹‘ ^‰‰ qŒ _’‹‚ s~‰“‚W The approximate height of the (See figure 6) flame at the high or full-on position is shown below. Purge all air from supply system by turning on one top Adjust burner air shutter to the widest opening that will not burner valve.
  • Page 35 Installation Instructions (all except RV’s) ^† p…’‘‘‚ J l“‚‹ _’‹‚ o‚ŠŒ“†‹„ p‚~‰‚ _’‹‚ cŒ ^‡’‘Š‚‹‘ l p‚“†€‚W a. The approximate length of the flame of oven burner is Mark ignitor location relative to main top with pencil. This a 1/2 inch distinct inner blue flame, figure 8. mark on the main top is used as a reference point when replacing the burner assembly to insure that the burner is tightened to its original position.
  • Page 36 Installation Instructions (all except RV’s) *$6 &219(56,21 ql obmi^`b t^ojfkd ao^tboW To access the regulator from front of range, remove the storage drawer or warming drawer. a. Pull the bearing glides to the front of the chassis glide. (See picture below). To remove storage drawer: Pull out to the first stop position.

  • Page 37: Installation Instructions (Rv's Only

    Installation Instructions (RV’s only) 16026785 A–11 © 2005 Maytag Services...
  • Page 38 Installation Instructions (RV’s only) A– 12 16026785 © 2005 Maytag Services...
  • Page 39 Appendix B The Use and Care information provided in this service manual is representative of a limited num- ber of models. Reference the customer’s Use and Care literature included with the product, order a copy (if needed), or consult Maytag’s website for the specific model. www.maytag.com 16026785 B–1...
  • Page 40 Use and Care Use & Care Guide Table of Contents Important Safety Care & Cleaning ....19-22 Instructions ....... 1-4 Self-Clean Oven Cleaning Procedures Surface Cooking ...... 5-6 Surface Controls Sealed Gas Burners Oven Cooking ......7-18 Manual Clean Oven Controls Clock Baking Timer...
  • Page 41 Use and Care cian. Do not attempt to adjust, repair, service, or replace Installer: Please leave this guide with this appliance. any part of your appliance unless it is specifically recom- Consumer: Please read and keep this guide for future mended in this guide.

  • Page 42: Important Safety Instructions

    Use and Care Important Safety Instructions To check if device is properly installed, look underneath Do not use water on grease fires. Use baking soda, a range with a flashlight to make sure one of the rear dry chemical or foam-type extinguisher to smother fire leveling legs is properly engaged in the bracket slot.
  • Page 43 Use and Care Important Safety Instructions Other potentially hot surfaces include cooktop, areas Always place oven racks in the desired positions while facing the cooktop, oven vent, surfaces near the vent oven is cool. Slide oven rack out to add or remove food, opening, oven door, areas around the oven door and using dry, sturdy potholders.
  • Page 44 Use and Care Important Safety Instructions This appliance has been tested for safe performance It is normal for the cooktop of the range to become hot using conventional cookware. Do not use any devices during a self-clean cycle. Therefore, touching the or accessories that are not specifically recommended in cooktop during a clean cycle should be avoided.

  • Page 45: Appendix B Use And Care

    Use and Care Surface Cooking HI: Use to bring liquid to a boil, or reach pressure in a pressure cooker. Always LO: Use to simmer foods, keep foods reduce setting to a lower heat when liquids warm and melt chocolate or butter. Some begin to boil or foods begin to cook.

  • Page 46: Burner Grates

    Use and Care Surface Cooking Cooktop Do not operate the burners without a pan on the grate. The grate’s porcelain finish may chip without To prevent the cooktop from discoloring or a pan to absorb the heat from the burner staining: flame.

  • Page 47: Oven Cooking

    Use and Care Oven Cooking Manual Clean Oven Control (select models) NOTE: The display will show 12:00 when the appliance is first connected to power or if power is interrupted. The Bake and Broil indicators light when function is pressed. 2.
  • Page 48 Use and Care Oven Cooking Baking, Roasting and Broiling • To change oven temperature during cooking, press the Bake pad, then press the More+ or Less- pad until the desired temperature is displayed. For additional baking, roasting and broiling times and tips, see “Cooking Made Simple”...
  • Page 49 Use and Care Oven Cooking 4. Follow the suggested times in the broil chart below. Meat 2. Place food in the center of oven. Check food for should be turned once about halfway through cooking doneness at minimum time in recipe. Cook longer if time.
  • Page 50 Use and Care Oven Cooking Oven Control (select models) The control panel is designed for ease in programming. The display window on the control shows time of day, timer and oven functions. Control panel shown includes model specific features. (Styling may vary depending on model.) Clock Broil Use for broiling and top browning.
  • Page 51 Use and Care Oven Cooking Locking the Controls To cancel the Clock display: If you do not want the time of day to display: The touchpad controls can be locked for safety, cleaning, or to prevent unwanted use. They will not function when locked. Press and hold the CANCEL and Clock pads for three seconds.
  • Page 52 Use and Care Oven Cooking Baking Baking Differences Between Your Old and New Ovens To set Bake: It is normal to notice some baking time differences between a 1. Press the Bake pad. new oven and an old one. See “Adjusting the Oven Temperature” •...
  • Page 53 Use and Care Oven Cooking Delay Bake When the Delay time has expired: • “DELAY” will turn off. CAUTION • Baking time is displayed. • “BAKE” and “HOLD” are displayed. Do not use delayed baking for highly perishable foods such as dairy products, pork, poultry, or seafood.

  • Page 54: Keep Warm

    Use and Care Oven Cooking Keep Warm Keep Warm Notes: For safely keeping foods warm or for warming breads and • For optimal food quality, oven cooked foods should be kept plates. warm for no longer than 1 to 2 hours. To set Keep Warm: •...

  • Page 55: Adjusting The Oven Temperature

    Use and Care Oven Cooking Automatic Shut-Off/Sabbath Adjusting the Oven Temperature Mode Oven temperatures are carefully tested for accuracy at the factory. It is normal to notice some baking or browning The oven will automatically turn off after 12 hours if you differences between a new oven and an old one.
  • Page 56 Use and Care Oven Cooking Broiling (select models) 5. Place food in the oven. Close oven door. 6. Turn meat once about halfway through cooking. To set Broil: 1. Press the Broil pad. 7. When food is cooked, press the CANCEL pad.

  • Page 57: Oven Racks

    Use and Care Oven Cooking Oven Racks Pilotless Ignition Your range is equipped with pilotless ignition. With this type of CAUTION ignition system, the gas automatically shuts off and the oven will not operate during a power failure. • Do not attempt to change the rack position when the oven A lighted match will not light the oven burner.
  • Page 58 Use and Care Oven Cooking RACK 2: Used for roasting small cuts of meat, casseroles, MULTIPLE RACK COOKING: baking loaves of bread, bundt cakes, custard pies or two-rack Two rack: Use rack positions 2 and 4, or 1 and 4. baking.

  • Page 59: Care & Cleaning

    Care & Cleaning Care & Cleaning Self-Clean Oven 6. Wipe up sugary and acidic spillovers such as sweet (select models) potatoes, tomato, or milk-based sauces. Porcelain enamel is acid-resistant, not acid-proof. The porcelain finish may Note: For manual clean oven, see page 22. discolor if acidic spills are not wiped up before a self- clean cycle.
  • Page 60 Care & Cleaning Care & Cleaning During the Self-Clean Cycle 3. Press the Clean pad. When LOCK shows in the display, the door cannot be opened. • “CLEAN” will flash. To prevent damage to the door, do not force the door open 4.
  • Page 61 Care & Cleaning Care & Cleaning Cleaning Procedures CAUTION • Be sure appliance is off and all parts are cool before handling or cleaning. This is to avoid damage and possible burns. * Brand names are registered trademarks of the •...
  • Page 62 Care & Cleaning Care & Cleaning PART PROCEDURE Oven Window • Avoid using excessive amounts of water which may seep under or behind glass causing staining. and Door - Glass • Wash with soap and water. Rinse with clear water and dry. Glass cleaner can be used if sprayed on a cloth first.
  • Page 63 Appendix C 16026785 C–1 © 2005 Maytag Services...

  • Page 64: Conversion Instructions, Self-Clean Models

    Conversion Instructions, Self-Clean Models d‚‹‚~‰ All ranges are equipped with fixed orifices and with a Reinstall cap nut to appliance pressure regulator and replace dust cover. convertible appliance pressure regulator. The unit model number plate states which gas it is adjusted for at the `^rqflkW Be sure marking for the type of gas to which factory.
  • Page 65 Conversion Instructions, Self-Clean Models 2ULILFH &RQYHUVLRQ To convert this unit to LP gas from Natural gas will require the exchange of orifice hoods. fjmloq^kq: Save all natural orifice hoods that are SCREW removed. l“‚‹ _’‹‚ `Œ‹“‚†Œ‹ Remove all oven racks. cfdrob Q NK _~ˆ‚...
  • Page 66 Conversion Instructions, Self-Clean Models ^† p…’‘‘‚ J l“‚‹ _’‹‚ 4. Remove the surface burner orifice hood with a ò² (12.7 mm) socket wrench counter-clockwise. a. The approximate length of the flame of oven burner is fjmloq^kq: Save all natural orifice hoods that are a 1/2 inch distinct inner blue flame, figure 8.

  • Page 67: Conversion Instructions, Non Self-Clean Models

    Conversion Instructions, Non Self-Clean Models *DV &RQYHUVLRQ d‚‹‚~‰ ^‰†~‹€‚ m‚’‚ o‚„’‰~‘Œ `Œ‹“‚†Œ‹ All ranges are equipped with fixed orifices and with a The unit appliance pressure regulator must be set to convertible appliance pressure regulator. The unit model match the type gas supply used. If converting from number plate states which gas it is adjusted for at the natural gas to LP gas, the appliance pressure regulator factory.
  • Page 68 Conversion Instructions, Non Self-Clean Models 2ULILFH &RQYHUVLRQ To convert this unit to LP gas from Natural gas will require the exchange of orifice hoods. fjmloq^kq: Save all natural orifice hoods that are removed. l“‚‹ _’‹‚ `Œ‹“‚†Œ‹ p’ƒ~€‚ _’‹‚ `Œ‹“‚†Œ‹ Remove all oven racks. 1.
  • Page 69 Conversion Instructions, Non Self-Clean Models ^† p…’‘‘‚ 5. Place the corresponding orifice hood on the burner fitting according to figure 4. Turn the orifice hood a. The approximate length of the flame of oven burner is clockwise by hand approximately one turn. Tighten the a 1/2 inch distinct inner blue flame, figure 6.
