ABM32-42
TECHNICAL
DATA
Refrigerated
compartment
Dimensions
(HxWxD)
Voltage
Power
consumption
Net weight
Classification
of climate
1. Top
2. Hinge
3. Retainer
4. Lock (optional)
5. Thermostat
6. Lamp
7. Ice tray
8. Shelves
9. Water tray
10. Feet

GENERAL INfORMATION

All the minibars in the ABM range work on the absorption system guaranteeing absolute silence and relia-
bility with no moving mechanical parts.

INSTRUCTIONS

The minibars cannot be installed in the open, even if they are covered by a canopy.
When connecting the minibar do not to use multi-socket extensions and make sure that the cable does
not kink or become compressed if the minibar is being fitted between other elements of furniture. Avoid
contact with the back of the minibar, as there is a residual risk of burns if you touch hot parts and injuries
if you touch metal elements.
Remember that any cleaning or maintenance work should only be carried out after the minibar has been
disconnected from the mains.
Only if the appliance is correctly installed will it give the best possible performance and reliability. If the mi-
nibar is to work satisfactorily, it must be installed on a completely level surface and properly ventilated.
The Manufacturer shall not be responsible for any injuries to persons or damage to property and/or the
minibar itself, which are the result of any installation not complying with the installation procedure shown
in this manual.
ABM32-42_10-10-2008
ABM 32
30 L
490 x 400 x 420
mm
230 V - 50 Hz
70 W
16 Kg
SN, N
MODEL
ABM 42
557 x 400 x 440
230 V - 50 Hz
17.5 Kg
ENGLISH
40 L
mm
70 W
SN, N
