ABM32-2 ABM42-2
TECHNICAL DATA
Product classification
Dimensions
HxWxD
Voltage
Power
consumption
Net weight
NOTE: Further information is provided on the technical data label inside the product.
1. Top
2. Hinge
3. Retainer
4. Lock
5. Thermostat
6. Lamp
7. Shelf
8. Water tray
9. Foot
GENERAL INFORMATION
WARNING!
This product is designed to serve professional purposes (hotels, cruise ships or similar).
All the minibars in the ABM range work on the absorption system guaranteeing absolute silence and relia-
bility with no moving mechanical parts.
INSTRUCTIONS
The minibars cannot be installed in the open, even if they are covered by a canopy.
When connecting the minibar do not to use multi-socket extensions and make sure that the cable does
not kink or become compressed if the minibar is being fitted between other elements of furniture. Avoid
contact with the back of the minibar, as there is a residual risk of burns if you touch hot parts and injuries
if you touch metal elements.
Remember that any cleaning or maintenance work should only be carried out after the minibar has been
disconnected from the mains.
Only if the appliance is correctly installed will it give the best possible performance and reliability. If the
minibar is to work satisfactorily, it must be installed on a completely level surface and properly ventilated.
Indel "B" shall not be responsible for any injuries to persons or damage to property and/or the minibar itself,
which are the result of any installation not complying with the installation procedure shown in this manual.
SMEG ABMXX-2_07-2016
ABM32-2
30 L
490 x 400 x 420 mm
220V-240V, 50Hz/60Hz
60 W
14.7 Kg
5
6
7
8
7
9
MODEL
ABM42-2
40 L
557 x 400 x 440 mm
220V-240V, 50Hz/60Hz
60 W
15.8 Kg
ENGLISH
1
2
4
3
7
