Summary of Contents for APART VINCI8S
- Page 1 VINCI8S Instruction manual...
- Page 3 VINCI8S Instruction manual VINCI8S...
-
Page 4: Safety First
Reference subwoofer Safety first! • Please check the packing for any kind of damage on reception of the goods. In case of a damaged carton, please contact your dealer before opening the carton. • !!!! Danger !!!! Exposure to high sound levels may cause a permanent hearing loss. - Page 5 VINCI8S Instruction manual • Set level controls on amplifiers all the way down during power- up to prevent speaker damage if there are high signal levels at the inputs. • Do not connect the inputs / outputs of amplifiers or consoles...
- Page 6 Reference subwoofer Features • Active subwoofer with high power amplifier • Integrated variable active filter • Class AB discrete output stage • Subwoofer phase polarity switch • Bassreflex speaker design • 8 inch long throw woofer • Magnetic speaker grille assembly •...
- Page 7 VINCI8S Instruction manual • Ideal partner for the Apart Audio Vinci (4-5-7) bookshelf speakers • Easy to set up and install. Straightforward operation • Supplied with rubber feet and spikes...
- Page 8 Reference subwoofer Connections...
- Page 9 VINCI8S Instruction manual 1. Line level inputs (IN): connect the left and/or right channel line level audio signals here. The incoming signal is passed through to connectors 2 (LINK). Connectors: unbalanced RCA. The incoming audio signal on the IN input will be processed by the integrated active low pass filter.
- Page 10 Reference subwoofer 8. Clip led: this led will light up when the integrated power amplifier is being driven to its limits: lower the subwoofer level immediately to avoid any damage to the amplifier or speaker. 9. Mains power fuse: replace only with a fuse of the same rating. In case the fuse blows regularly, bring the unit to your dealer for service.
-
Page 11: Installation
VINCI8S Instruction manual Installation The Apart VINCI8S active subwoofer is designed to reproduce a fat and deep bass at moderate sound pressure levels. Due to its discrete design and small dimensions, the subwoofer is very easy to integrate even in the most demanding environments. -
Page 12: Setup And Operation
Set up and operation When available, connect the VINCI8S to the preamp out of your main audio system. Alternatively, you can connect the subwoofer to the speaker outputs from the audio system’s power amplifier. - Page 13 VINCI8S Instruction manual source and play some music at a low level. Gently turn up the subwoofer level potentiometer until the subwoofer “supports” your main speakers. Adjust the frequency potentiometer for optimal blending with the main speakers. If the bass output decreases when the subwoofer is playing along with the main speakers, flip the phase switch to the 180°...
-
Page 14: Specifications
Reference subwoofer Specifications Amplifier RMS output power (THD<1%) 90 W RMS Max output power 125 W <0.1% Signal to noise ratio >90 dB Input sensitivity stereo line in 700 mV RMS Input sensitivity mono line in 1.4 V RMS Frequency response 20 –... - Page 15 VINCI8S Instruction manual Cabinet material MDF, high gloss paint finish in black or white Dimensions (overall, including rear H x W x D: 345 x 262 x 405 controls and connectors) Dimensions (without grille, H x W x D: 345 x 262 x 385...
- Page 16 Audioprof nv Industriepark Brechtsebaan 8 bus 1 2900 Schoten - Belgium Company names, product names and trademarks are property of their respective owners. Apart-Audio specifications are subject to change without notice.
