Summary of Contents for APART SUB2400
- Page 1 SUB2400 Instruction manual...
- Page 3 SUB2400 Instruction manual SUB2400 subwoofer...
- Page 4 18” subwoofers and the results were astonishing in favour of the SUB2400! SUB2400 can be driven at 4 ohms or 16 ohms. Selection is done by the large switch at the back of the subwoofer. Especially with long cable runs, the 16 ohms mode is advised. Less power is lost and the bass response will be a lot better.
-
Page 5: Safety Instructions
SUB2400 Instruction manual Safety instructions • Keep this manual for future reference. • Take care of your speaker wires, they should be free of damage. Damaged speaker wires may result in poor sound quality and can damage amplifiers. • No main power shall be connected to the speakers, doing so will damage the speaker. -
Page 6: Features And Benefits
Smooth punchy bass Installation The two speakon connectors are wired in parallel. The rocker switch gives you the possibility to turn your SUB2400 into a 4 or 16 ohm version. To get the best result in producing low frequencies, you should keep the minimal impedance of your subwoofer system as high as possible, certainly when cables of more than 10 meters are used. - Page 7 SUB2400 Instruction manual...
- Page 8 Passive professional subwoofer Subwoofer configuration The SUB2400 is a perfect match with the CHAMP-3D and the MASK8 in the combination shown below.
- Page 9 SUB2400 Instruction manual Please note that the SUB2400 has a 35 mm pole mounting hole to mount the STSUB pole and one MASK8 loudspeaker or 2 MASK8 loudspeakers if you add the STT bracket to the STSUB pole.
-
Page 10: Technical Drawing
Passive professional subwoofer Technical drawing (mounting hole for STSUB only available on the black model) -
Page 11: Technical Specifications
SUB2400 Instruction manual Technical specifications model name SUB2400 woofer size 2 x 10 inch loudspeaker system dual coil woofer cone material paper nominal impedance 4 or 16 ohms frequency range 45 – 150 Hz program power 600 watts SPL at 1 W / 1 m... - Page 12 Passive professional subwoofer Notes...
- Page 13 SUB2400 Instruction manual Notes...
-
Page 14: Warranty Info
The product must be returned in the original packaging with the proof of purchase by an Apart Audio authorized reseller. The general terms and conditions can be found here: http://www.apart-audio.com/conditions/General_Terms_and_Conditions_... - Page 16 Apart Audio nv Industriepark Brechtsebaan 8 bus 1 2900 Schoten - Belgium Company names, product names and trademarks are property of their respective owners. Apart-Audio specifications are subject to change without notice.
