Alcatel IP70H User Manual

Alcatel IP70H
USER'S GUIDE
PLEASE READ THIS USER'S GUIDE BEFORE USING THE HEADSET

Install the battery

Connect and charge the battery

NOTE NOTES
• The battery is permanently attached to the battery • Use only the supplied adaptor.
compartment cover (known as the battery pack). Do
• Charge the battery provided with or identified for
not try to separate them from each other.
use with this product only in accordance with the
Install the battery as shown below.
instructions and limitations specified in this manual.
Connect the charger
Charge the battery
NOTES
• Use only the supplied battery.
• Remove any headset attachment (earbud excluded)
before battery replacement.
• If the headset will not be used for a long time,
remove the battery to prevent possible leakage.
• To purchase a replacement battery pack, contact
your Alcatel home & business phones partner. Use
only battery pack recommended by Alcatel home &
business phones.
The light turns on when the headset is
charging.
NOTES
• For best performance, keep the headset in the
charger when not in use.
• The battery is fully charged after three hours of
continuous charging.
• When fully charged, the headset battery provides
approximately 12 hours of talk time or 5 days of
standby time.

Parts checklist

Your headset package contains the following
items. Save your sales receipt and original
• Cordless headset
with medium-sized
earbud attached
• Battery pack
(with battery
compartment cover
attached)
• Earbud x5
•

Over the head band

User's manual
• User's manual
The light flashes slowly in red and blue when

Before use

the deregistration process is successful.

Add and register a headset

Position the headset

You can register Alcatel IP70 onto the following
phones : Alcatel Temporis IP300 and Alcatel
Temporis IP700G. Both phones support one
Earbud
headset only.
There are three sizes of earbuds provided. The
Register the headset with the telephone base
medium-sized earbud is already attached to the
before use. After charged, the light on headset
headset.
flashes in red and blue slowly and alternately.
To remove the earbud from the headset
NOTE
earpiece:
• Charge the new headset without interruption for
• Hold both sides of the earbud. Twist and
at least 30 minutes before registering it to the
pull the earbud until it separates from the
telephone base.
earpiece.
To register a headset:
To attach the earbud to the headset
1. Remove the headset from the charger.
earpiece:
2. Press Menu at the telephone base when idle.
1. Choose an appropriate earbud.
3. Press q to highlight User Settings, and then
2. Position the earbud on the earpiece.
press SELECT.
3. Press the earbud down on the earpiece until
4. Press q to highlight DECT headset, and
it clicks into place. Move the earbud around
then press SELECT.
so that the protruding bump on the earbud is
5. With Register highlighted, press SELECT on
pointing towards your mouth when placed in
the telephone base.
your ear.
6. Place the headset back to the charger. The
light flashes quickly in red and blue.
The light turns red when the headset is
registered but not fully charged, or turns blue
when it is registered and fully charged.
To verify the registration, press the button on the
headset and check for a dial tone. If the
registration fails, the light on the headset flashes
slowly in red and blue.

Over the ear hook

To reset the headset, remove it from the headset
There are two sizes of ear hooks. You can
charger and repeat the registration process
choose the suitable ear hook to attach to the
again.
headset.
To adjust the headset to wear on the left or

Deregister a headset

right ear:
To replace a headset or register the headset to
another telephone base, you must deregister
• To wear on the
all devices, and then register each device left ear
individually.
To deregister all devices:
1. Press Menu at the telephone base when idle.
2. Press q to highlight User Settings, and then
press SELECT.
3. Press q to highlight DECT headset, and
then press SELECT.
4. Press q to highlight Deregister, and then
SELECT
press .

Headset overview

6
5
• Headset charger
4
1 – VOL+/VOL-
• Push to right or left to adjust the ringer volume
while in idle mode, or the listening volume while on
a call.
2 – MUTE/FLASH
• Press to mute the ringer in the earpiece when
there is an incoming call.
• Press to mute the microphone during a call.
• Headset charger
• Press and hold for two seconds to answer an
power adapter incoming call when you receive a call waiting
alert during a call.
3 –
• Press to make, answer or end a call.
4 – Microphone
5 – Battery pack
• Open to replace the battery pack.
• Over the ear hook
x2 6 – Earpiece
Charger overview
1
• Behind the neck
band
1 – Magnetic charging mount
• Place the headset here for charging.
2 – Power cord slot
3 – Power jack
To attach the ear hook to the headset:
1. Remove any headset attachment (earbud
excluded) currently connected to the headset.
2. Insert the earpiece into the ear hook ring.
3. Press the edge of the ear hook ring towards
the earpiece until it clicks into place.
4. Hook the headset onto the desired ear.
Adjust the angle of the headset until the
microphone is pointing towards your mouth.
• To wear on the
right ear
To remove the ear hook from the headset:
• Hold the headset with one hand. Twist and
pull the ear hook with your other hand until it
separates from the earpiece.

Light and alert tones overview

Light:
1
light status
2 Red • On when the headset is charging in the
headset charger.
• Flashes every 10 seconds to indicate
the battery is low when the headset is
not in the headset charger.
3
• Flashes three times to indicate the
headset is powering off.
Blue • On when a fully charged and registered
headset is in the headset charger.
• Flashes three times to indicate the
headset is powering on.
• Flashes twice every three seconds
when the headset is in use.
• Flashes four times every four seconds
when there is an incoming call.
• Flashes every 10 seconds when a fully
charged and registered headset in idle
mode is out of the headset charger.
Red • Flashes slowly when the headset is not
and registered.
blue
• Flashes quickly when the headset is
trying to register to a telephone base.
Off • No battery is installed or out of battery.
• The headset is powered off.
Alert tones:
One short beep Headset key tone.
One short beep Muted headset microphone
every 30 seconds alert tone.
Two beeps • Error alert tone.
• The ringer volume is at its
lowest setting.
• The listening volume is at
its highest or lowest setting.
• Any key is pressed while
the headset is out of range
Two low beeps Call Waiting alert tone.
Two rapid beeps Low battery warning.
2
every 20 seconds
Three rising beeps A conference call starts.
3
Three rapid beeps • The headset is out of range.
every 20 seconds
• The headset is not yet
registered.
Ring tone • Incoming call alert tone.
• Ring back tone.
Three rapid beeps The headset is powering on
or off.
Over the head band
To attach the head band to the headset:
1. Remove any headset attachment (earbud
excluded) currently connected to the headset.
2. Insert the earpiece into the loop of the ear pad.
3. Push the earpiece towards the loop of the
ear pad until it clicks into place.
4. Adjust the head band to fit your head. Adjust
and rotate the angle of the headset until the
microphone is pointing towards your mouth.
To remove the head band from the
headset:
• Hold the headset with one hand and the ear
pad with your other hand. Twist and pull the
headset until it separates from the loop of the
ear pad.
