Broan BDF SERIES Installation Manual

Hide thumbs Also See for BDF SERIES:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction and Installation Manual, Installation Manual
I
G
NSTALLATION
UIDE
HB0111
BDF SERIES
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 9-10.
Broan-NuTone Canada ULC; Mississauga, Ontario 1-877-896-1119
www.broan.ca
REGISTER YOUR PRODUCT ON LINE AT: www.broan.com/register
30042454 rev. B

Advertisement

Table of Contents
loading

Related Manuals for Broan BDF SERIES

Summary of Contents for Broan BDF SERIES

  • Page 1 INTENDED FOR DOMESTIC COOKING ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE INFORMATION ON PAGES 9-10. Broan-NuTone Canada ULC; Mississauga, Ontario 1-877-896-1119 www.broan.ca REGISTER YOUR PRODUCT ON LINE AT: www.broan.com/register 30042454 rev. B...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS WARNING WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR TO REDUCE THE RISK OF INJURY TO PERSON(S) INJURY TO PERSON(S), OBSERVE THE FOLLOWING: IN THE EVENT OF A RANGE TOP GREASE FIRE, OBSERVE THE FOLLOWING*: 1.
  • Page 3 ABOUT THIS MANUAL Please take note this manual uses the following symbols to emphasize particular information: WARNING Identifies an instruction which, if not followed, might cause serious personal injuries including possibility of death CAUTION Denotes an instruction which, if not followed, may severly damage the unit and/or its components. NOTE: Indicates supplementary information needed to fully complete an instruction.
  • Page 4 2. PREPARE INSTALLATION WARNING When performing installation, servicing or cleaning the unit, it is recommended to wear safety glasses and gloves. Tools needed to install the range hood: - Phillips screwdriver no. 2 - Pair of long nose pliers - Flat blade screwdriver (to open the electrical knockout hole) - Scissors (to cut metal foil duct tape) - Wire stripper Make sure the following items are included:...

  • Page 5: P Repare The Hood

    3. PREPARE THE HOOD 3.1 A NSTALLATIONS CREW OCATIONS 1. Lay the hood on its top on a table. Use a piece of cardboard to avoid damaging the table or the hood. Slide the main grease cup out and REASE set aside.

  • Page 6: I Nstall The Hood

    3. PREPARE THE HOOD ( CONT'D 3.3 H ORIZONTAL ISCHARGE 1. Remove the large shutoff plate 5 retaining screws located on the BACK of the hood. Discard the shutoff plate and its screws. HO0049 2. Remove the small shutoff plate 10 retaining screws located INSIDE the back of the hood. Set the screws aside and discard the shutoff plate.

  • Page 7: C Onnect Wiring

    5. CONNECT WIRING WARNING Risk of electrical shock. Electrical wiring must be done by qualified personnel in accordance with all applicable codes and standards. Before connecting wires, switch power off at service panel and lock service disconnecting means to prevent power from being switched on accidentally. 1.

  • Page 8: Light Bulb

    6. LIGHT BULBS WARNING Make sure power is switched off at service panel before carrying out any operation on the hood. This range hood requires two UL approved halogen bulbs (JC type, 12 V, 20 W, G4-base), included. To replace bulbs: CAUTION Take care not to damage the hood finish while using the screwdriver.

  • Page 9: C Leaning And Maintenance

    7. CLEANING AND MAINTENANCE 1. Slide out main grease cup. HO0171 2. Disengage the small grease guard cups from the metal guards by turning counterclockwise and remove. 3. Remove the screw retaining the metal guards to the hood. 4. Remove the metal guards from the hood. Then remove the bottom panel. HD0142 HD0143 HD0144...

  • Page 10: O Peration

    7. CLEANING AND MAINTENANCE ( CONT'D TAINLESS TEEL LEANING Don’t: • Regularly wash with clean cloth or rag soaked with warm water • Use any steel or stainless steel wool or any other scrapers to and mild soap or liquid dish detergent. remove stubborn dirt.

  • Page 11: Wiring Diagram

    Any third party replacement part used may cause serious damage and drastically reduce the performance level of your unit, which will result in premature failling. Broan-NuTone Canada also recommends to contact a Broan-NuTone certified service depot for all replacement parts and repair.

  • Page 12: W Arranty

    One Year Limited Warranty Broan-NuTone Canda warrants to the original purchaser of its products that such products will be free from defects in material and workmanship for a period of one (1) year from the date of original purchase. THERE ARE NO OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, IMPLIED WARRANTIES OR MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.
