Maintenance and cleaning

Your record player requires little or no regular maintenance. Remove dust with a slightly moistened antistatic
cloth. Never use a dry cloth because this will create static electricity which attract more dust! Antistatic
cleaning fluids are available at specialist stores but must be applied sparingly to avoid damage to rubber
parts. It is recommended to fit the needle cover before cleaning or maintenance is carried out to avoid damage.
If the player is not used over a long period of time the drive belt can be removed to prevent unequal stretching.
Always disconnect the record player from the mains power supply as a precaution before maintenance!
Technical specifications PRO-JECT 2 Xperience SB DC / Pro-Ject 9cc Evolution
Nominal speeds
Speed variance
Wow and flutter
Signal to noise
Effective tonearm mass
Effective tonearm length
Overhang
Power consumption
Outboard power supply
Dimensions (W x H x D)
Weight
Technical specifications MM-Cartridge Ortofon 2M Silver
Frequency range
Channel separation
Output voltage
Recommended load impedance
Compliance/stylus type
Recommended tracking force
Weight
© Pro-Ject Audio Systems · Pro-Ject 2 Xperience SB DC / Ortofon 2M Silver · Revision 2015.02.10
33/45 r.p.m.
33: ±0,12 % 45: ±0,28 %
33: ±0,12 % 45: ±0,11 %
70dB
8g
9 " (230mm)
18mm
4W/ >0,5W standby mode
15V/ 800mA DC, universal power supply
460 x 145 x 360mm, dust cover open 460 x 400 x 445mm
8 kg
20-22.000Hz
23dB/1kHz
4mV
47kohms / amplifier connection – MM-input
20µm/mN – elliptical
18mN
7,2g
