DFI NS80-EA User Manual

Hide thumbs Also See for NS80-EA:

Advertisement

Quick Links

Download this manual See also: User Manual
NS80-EA
NS80-EC
NS80-EL
Rev. A+
System Board User’s Manual
Carte Mère Manuel Pour Utilisateur
System-Platine Benutzerhandbuch
Tablero Electrónico del Sistema Manual del Usuario

Advertisement

loading
Need help?

Need help?

Do you have a question about the NS80-EA and is the answer not in the manual?

Questions and answers

Related Manuals for DFI NS80-EA

Summary of Contents for DFI NS80-EA

  • Page 1 NS80-EA NS80-EC NS80-EL Rev. A+ System Board User’s Manual Carte Mère Manuel Pour Utilisateur System-Platine Benutzerhandbuch Tablero Electrónico del Sistema Manual del Usuario...
  • Page 2 Copyright Trademarks Caution...

  • Page 3: Fcc And Doc Statement On Class B

    FCC and DOC Statement on Class B...
  • Page 4 ü û ü ü û û...

  • Page 5: Chapter 1 - Quick Setup Guide

    Chapter 1 - Quick Setup Guide...
  • Page 6 CPU fan (J16) COM 1 (J4) Parallel (J6) COM 2 (J3) +12V power DIMM (ATXP1) standby power LED JUSB1 Game/MIDI DDR 3 (J9) AGP Slot IDE 2 DDR 1 AC’97 IDE 1 DDR 2 PCI Slot 1 Front audio (J2) PCI Slot 2 4CH audio (J8) CD-in (J5)
  • Page 7 CPU fan (J16) COM 1 (J4) Parallel (J6) COM 2 (J3) +12V power DIMM (ATXP1) standby power LED JUSB1 Game/MIDI DDR 3 (J9) AGP Slot IDE 2 DDR 1 AC’97 IDE 1 DDR 2 PCI Slot 1 Front audio (J2) PCI Slot 2 4CH audio (J8) CD-in (J5)
  • Page 8 CPU fan (J16) COM 1 (J4) Parallel (J6) COM 2 (J3) +12V power DIMM (ATXP1) standby power LED JUSB1 Game/MIDI DDR 3 (J9) AGP Slot IDE 2 DDR 1 AC’97 IDE 1 DDR 2 PCI Slot 1 Front audio (J2) PCI Slot 2 4CH audio (J8) CD-in (J5)
  • Page 9 Clear CMOS (JP2)
  • Page 11 JUSB1 USB 5/6 (J19)
  • Page 12 Front audio (J2)
  • Page 13 Game/MIDI (J9) CD-in (J5) AUX-in (J7)
  • Page 14 S/PDIF-in/out (J11) 3 2 1 S/PDIF-out (J11) 4CH audio (J8)
  • Page 15 1394A (J14) 1394A (J15) 1394A (J17) IDE 1 IDE 2...
  • Page 16 1 2 3 4 5 IrDA (J13) CPU fan (J16) Chassis fan (J20)
  • Page 17 DIMM standby power LED PCI standby power LED...
  • Page 18 ATX main power +12V power (ATXPWR1) (ATXP1)
  • Page 19 Front panel connectors (J18)
  • Page 20 Phoenix - AwardBIOS CMOS Setup Utility Standard CMOS Features Frequency/Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Set Supervisor Password Integrated Peripherals Power Management Setup Set User Password PnP/PCI Configurations Save & Exit Setup PC Health Status Exit Without Saving ↑↓→←...
  • Page 21 Phoenix - AwardBIOS CMOS Setup Utility Advanced BIOS Features Item Help Virus Warning Disabled CPU L1 & L2 Cache Enabled Menu Level Quick Power On Self Test Fast First Boot Device Floppy Allows you to choose Second Boot Device HDD-0 the VIRUS warning Third Boot Device LS120...
  • Page 22 Phoenix - AwardBIOS CMOS Setup Utility Integrated Peripherals Item Help SIS OnChip IDE Device Press Enter SIS OnChip PCI Device Press Enter Menu Level Onboard Super IO Device Press Enter IDE HDD Block Mode Disabled Init Display First PCI Slot IDECH0 Access Interface EDB Bus IDECH1 Access Interface...
  • Page 23 Phoenix - AwardBIOS CMOS Setup Utility PnP/PCI Configurations Item Help Reset Configuration Data Disabled Menu Level Resources Controlled By Auto(ESCD) IRQ Resources Press Enter Default is Disabled. Select Enabled to PCI/VGA Palette Snoop Disabled reset Extended System Configuration Data (ESCD) when you exit Setup if you have installed a new add-on and the system...
  • Page 24 Phoenix - AwardBIOS CMOS Setup Utility Frequency/Voltage Control Item Help CPU Clock Ratio Auto Detect DIMM/PCI Clk Enabled Menu Level Spread Spectrum Disabled CPU Frequency Default CPU:DRAM Frequency Ratio DRAM Frequency ↑↓→← Move Enter:Select +/-/PU/PD:Value F10:Save ESC:Exit F1:General Help F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults...

  • Page 25: Chapter 2 - English

    Chapter 2 - English þ þ þ þ þ...
  • Page 30 ≥...
  • Page 31 ≥ ≥ ® ® ≥...
  • Page 33 ® ® ® ® ®...
  • Page 34 ® ® ®...
  • Page 35      ®...
  • Page 36  ...
  • Page 38 ® ® ® ® ® ®      ...

  • Page 44: Chapter 3 - Français (French)

    Chapter 3 - Français (French) þ þ þ þ þ...
  • Page 50 ≥ ≥ ≥...
  • Page 51 ≥...
  • Page 54     ®...
  • Page 57 ® ® ® ® ® ®...

  • Page 64: Chapter 4 - Deutsch (German)

    " Chapter 4 - Deutsch (German) þ þ þ þ þ...
  • Page 65 "...
  • Page 66 "...
  • Page 67 "...
  • Page 68 "...
  • Page 69 "...
  • Page 70 " ≥ ≥ ≥...
  • Page 71 " ≥...
  • Page 72 "...
  • Page 73 "...
  • Page 74 "      ®...
  • Page 75 "...
  • Page 76 "...
  • Page 77 " ® ® ® ® ®...
  • Page 78 "...
  • Page 79 "...
  • Page 80 "...
  • Page 81 "...
  • Page 82 "...
  • Page 83 "...

  • Page 84: Chapter 5 - Español (Spanish)

    Chapter 5 - Español (Spanish) þ þ þ þ þ...
  • Page 90 ≥ ≥...
  • Page 91 ≥...
  • Page 92 ® ® ® ® ®...
  • Page 93 ® ® ®...
  • Page 94      ®...
  • Page 97 ® ® ® ® ®...
