Armstrong TechZone TZ5 Specification Sheet

CEILING SYSTEMS

TECHZONE

Recessed Fixtures

Armstrong

TZ5

48" and 60" Lay-in and Tegular Fixtures for 9/16" and 15/16" Grid
The TZ5 applies the Volumetric Lighting principal to the Tech Zone. It creates shadow-less lighting with
controlled high angle brightness. The result makes spaces more attractive and facial features more
well-defined and lively. The diffuser is an extruded flat lens backed with an optical overlay designed to
control brightness in both perpendicular and parallel views. The TZ5 is available in lay-in or tegular ceiling
versions engineered to complement the TechZone ceiling system.
15/16" Lay-in
4.03
9/16" Lay-in
15/16" Tegular
4.39
0.32
9/16" Tegular
Acuity Lighting Group, Inc.
Fluorescent
One Lithonia Way
Conyers, GA 30012
Technical Support: 800-858-7763
www.lithonia.com/techzone
CS-3735-0107
™ Ceiling System
® TechZone ™ Compatible
TZ5 Lay-in
TZ5 Tegular
